Vlimb: A Wire-Driven Wearable Robot for Bodily Extension, Balancing Powerfulness and Reachability

Numerous wearable robots have been developed to meet the demands of physical assistance and entertainment. These wearable robots range from body-enhancing types that assist human arms and legs to body-extending types that have extra arms. This study focuses specifically on wearable robots of the latter category, aimed at bodily extension. However, they have not yet achieved the level of powerfulness and reachability equivalent to that of human limbs, limiting their application to entertainment and manipulation tasks involving lightweight objects. Therefore, in this study, we develop an body-extending wearable robot, Vlimb, which has enough powerfulness to lift a human and can perform manipulation. Leveraging the advantages of tendon-driven mechanisms, Vlimb incorporates a wire routing mechanism capable of accommodating both delicate manipulations and robust lifting tasks. Moreover, by introducing a passive ring structure to overcome the limited reachability inherent in tendon-driven mechanisms, Vlimb achieves both the powerfulness and reachability comparable to that of humans. This paper outlines the design methodology of Vlimb, conducts preliminary manipulation and lifting tasks, and verifies its effectiveness.

Integrative Wrapping System for a Dual-Arm Humanoid Robot

Flexible object manipulation of paper and cloth is a major research challenge in robot manipulation. Although there have been efforts to develop hardware that enables specific actions and to realize a single action of paper folding using sim-to-real and learning, there have been few proposals for humanoid robots and systems that enable continuous, multi-step actions of flexible materials. Wrapping an object with paper and tape is more complex and diverse than traditional manipulation research due to the increased number of objects that need to be handled, as well as the three-dimensionality of the operation. In this research, necessary information is organized and coded based on the characteristics of each object handled in wrapping. We also generalize the hardware configuration, manipulation method, and recognition system that enable humanoid wrapping operations. The system will include manipulation with admittance control focusing on paper tension and state evaluation using point clouds to handle three-dimensional flexible objects. Finally, wrapping objects with different shapes is experimented with to show the generality and effectiveness of the proposed system.

Fundamental Three-Dimensional Configuration of Wire-Wound Muscle-Tendon Complex Drive

For robots to become more versatile and expand their areas of application, their bodies need to be suitable for contact with the environment. When the human body comes into contact with the environment, it is possible for it to continue to move even if the positional relationship between muscles or the shape of the muscles changes. We have already focused on the effect of geometric deformation of muscles and proposed a drive system called wire-wound Muscle-Tendon Complex (ww-MTC), an extension of the wire drive system. Our previous study using a robot with a two-dimensional configuration demonstrated several advantages: reduced wire loosening, interference, and wear; improved robustness during environmental contact; and a muscular appearance. However, this design had some problems, such as excessive muscle expansion that hindered inter-muscle movement, and confinement to planar motion. In this study, we develop the ww-MTC into a three-dimensional shape. We present a fundamental construction method for a muscle exterior that expands gently and can be contacted over its entire surface. We also apply the three-dimensional ww-MTC to a 2-axis 3-muscle robot, and confirm that the robot can continue to move while adapting to its environment.

CubiXMusashi: Fusion of Wire-Driven CubiX and Musculoskeletal Humanoid Musashi toward Unlimited Performance

Humanoids exhibit a wide variety in terms of joint configuration, actuators, and degrees of freedom, resulting in different achievable movements and tasks for each type. Particularly, musculoskeletal humanoids are developed to closely emulate human body structure and movement functions, consisting of a skeletal framework driven by numerous muscle actuators. The redundant arrangement of muscles relative to the skeletal degrees of freedom has been used to represent the flexible and complex body movements observed in humans. However, due to this flexible body and high degrees of freedom, modeling, simulation, and control become extremely challenging, limiting the feasible movements and tasks. In this study, we integrate the musculoskeletal humanoid Musashi with the wire-driven robot CubiX, capable of connecting to the environment, to form CubiXMusashi. This combination addresses the shortcomings of traditional musculoskeletal humanoids and enables movements beyond the capabilities of other humanoids. CubiXMusashi connects to the environment with wires and drives by winding them, successfully achieving movements such as pull-up, rising from a lying pose, and mid-air kicking, which are difficult for Musashi alone. This concept demonstrates that various humanoids, not limited to musculoskeletal humanoids, can mitigate their physical constraints and acquire new abilities by connecting to the environment and driving through wires.

Robotic State Recognition with Image-to-Text Retrieval Task of Pre-Trained Vision-Language Model and Black-Box Optimization

State recognition of the environment and objects, such as the open/closed state of doors and the on/off of lights, is indispensable for robots that perform daily life support and security tasks. Until now, state recognition methods have been based on training neural networks from manual annotations, preparing special sensors for the recognition, or manually programming to extract features from point clouds or raw images. In contrast, we propose a robotic state recognition method using a pre-trained vision-language model, which is capable of Image-to-Text Retrieval (ITR) tasks. We prepare several kinds of language prompts in advance, calculate the similarity between these prompts and the current image by ITR, and perform state recognition. By applying the optimal weighting to each prompt using black-box optimization, state recognition can be performed with higher accuracy. Experiments show that this theory enables a variety of state recognitions by simply preparing multiple prompts without retraining neural networks or manual programming. In addition, since only prompts and their weights need to be prepared for each recognizer, there is no need to prepare multiple models, which facilitates resource management. It is possible to recognize the open/closed state of transparent doors, the state of whether water is running or not from a faucet, and even the qualitative state of whether a kitchen is clean or not, which have been challenging so far, through language.

Component Modularized Design of Musculoskeletal Humanoid Platform Musashi to Investigate Learning Control Systems

To develop Musashi as a musculoskeletal humanoid platform to investigate learning control systems, we aimed for a body with flexible musculoskeletal structure, redundant sensors, and easily reconfigurable structure. For this purpose, we develop joint modules that can directly measure joint angles, muscle modules that can realize various muscle routes, and nonlinear elastic units with soft structures, etc. Next, we develop MusashiLarm, a musculoskeletal platform composed of only joint modules, muscle modules, generic bone frames, muscle wire units, and a few attachments. Finally, we develop Musashi, a musculoskeletal humanoid platform which extends MusashiLarm to the whole body design, and conduct several basic experiments and learning control experiments to verify the effectiveness of its concept.

Patterned Structure Muscle : Arbitrary Shaped Wire-driven Artificial Muscle Utilizing Anisotropic Flexible Structure for Musculoskeletal Robots

Muscles of the human body are composed of tiny actuators made up of myosin and actin filaments. They can exert force in various shapes such as curved or flat, under contact forces and deformations from the environment. On the other hand, muscles in musculoskeletal robots so far have faced challenges in generating force in such shapes and environments. To address this issue, we propose Patterned Structure Muscle (PSM), artificial muscles for musculoskeletal robots. PSM utilizes patterned structures with anisotropic characteristics, wire-driven mechanisms, and is made of flexible material Thermoplastic Polyurethane (TPU) using FDM 3D printing. This method enables the creation of various shapes of muscles, such as simple 1 degree-of-freedom (DOF) muscles, Multi-DOF wide area muscles, joint-covering muscles, and branched muscles. We created an upper arm structure using these muscles to demonstrate wide range of motion, lifting heavy objects, and movements through environmental contact. These experiments show that the proposed PSM is capable of operating in various shapes and environments, and is suitable for the muscles of musculoskeletal robots.

Design Method of a Kangaroo Robot with High Power Legs and an Articulated Soft Tail

In this paper, we focus on the kangaroo, which has powerful legs capable of jumping and a soft and strong tail. To incorporate these unique structure into a robot for utilization, we propose a design method that takes into account both the feasibility as a robot and the kangaroo-mimetic structure. Based on the kangaroo's musculoskeletal structure, we determine the structure of the robot that enables it to jump by analyzing the muscle arrangement and prior verification in simulation. Also, to realize a tail capable of body support, we use an articulated, elastic structure as a tail. In order to achieve both softness and high power output, the robot is driven by a direct-drive, high-power wire-winding mechanism, and weight of legs and the tail is reduced by placing motors in the torso. The developed kangaroo robot can jump with its hind legs, moving its tail, and supporting its body using its hind legs and tail.

Construction of Musculoskeletal Simulation for Shoulder Complex with Ligaments and Its Validation via Model Predictive Control

The complex ways in which humans utilize their bodies in sports and martial arts are remarkable, and human motion analysis is one of the most effective tools for robot body design and control. On the other hand, motion analysis is not easy, and it is difficult to measure complex body motions in detail due to the influence of numerous muscles and soft tissues, mainly ligaments. In response, various musculoskeletal simulators have been developed and applied to motion analysis and robotics. However, none of them reproduce the ligaments but only the muscles, nor do they focus on the shoulder complex, including the clavicle and scapula, which is one of the most complex parts of the body. Therefore, in this study, a detailed simulation model of the shoulder complex including ligaments is constructed. The model will mimic not only the skeletal structure and muscle arrangement but also the ligament arrangement and maximum muscle strength. Through model predictive control based on the constructed simulation, we confirmed that the ligaments contribute to joint stabilization in the first movement and that the proper distribution of maximum muscle force contributes to the equalization of the load on each muscle, demonstrating the effectiveness of this simulation.

CubiX: Portable Wire-Driven Parallel Robot Connecting to and Utilizing the Environment

A wire-driven parallel robot is a type of robotic system where multiple wires are used to control the movement of a end-effector. The wires are attached to the end-effector and anchored to fixed points on external structures. This configuration allows for the separation of actuators and end-effectors, enabling lightweight and simplified movable parts in the robot. However, its range of motion remains confined within the space formed by the wires, limiting the wire-driven capability to only within the pre-designed operational range. Here, in this study, we develop a wire-driven robot, CubiX, capable of connecting to and utilizing the environment. CubiX connects itself to the environment using up to 8 wires and drives itself by winding these wires. By integrating actuators for winding the wires into CubiX, a portable wire-driven parallel robot is realized without limitations on its workspace. Consequently, the robot can form parallel wire-driven structures by connecting wires to the environment at any operational location.
