An Overview on IRS-Enabled Sensing and Communications for 6G: Architectures, Fundamental Limits, and Joint Beamforming Designs

This paper presents an overview on intelligent reflecting surface (IRS)-enabled sensing and communication for the forthcoming sixth-generation (6G) wireless networks, in which IRSs are strategically deployed to proactively reconfigure wireless environments to improve both sensing and communication (S&C) performance. First, we exploit a single IRS to enable wireless sensing in the base station's (BS's) non-line-of-sight (NLoS) area. In particular, we present three IRS-enabled NLoS target sensing architectures with fully-passive, semi-passive, and active IRSs, respectively. We compare their pros and cons by analyzing the fundamental sensing performance limits for target detection and parameter estimation. Next, we consider a single IRS to facilitate integrated sensing and communication (ISAC), in which the transmit signals at the BS are used for achieving both S&C functionalities, aided by the IRS through reflective beamforming. We present joint transmit signal and receiver processing designs for realizing efficient ISAC, and jointly optimize the transmit beamforming at the BS and reflective beamforming at the IRS to balance the fundamental performance tradeoff between S&C. Furthermore, we discuss multi-IRS networked ISAC, by particularly focusing on multi-IRS-enabled multi-link ISAC, multi-region ISAC, and ISAC signal routing, respectively. Finally, we highlight various promising research topics in this area to motivate future work.

Networked ISAC for Low-Altitude Economy: Transmit Beamforming and UAV Trajectory Design

This paper studies the exploitation of networked integrated sensing and communications (ISAC) to support low-altitude economy (LAE), in which a set of networked ground base stations (GBSs) transmit wireless signals to cooperatively communicate with multiple authorized unmanned aerial vehicles (UAVs) and concurrently use the echo signals to detect the invasion of unauthorized objects in interested airspace. Under this setup, we jointly design the cooperative transmit beamforming at multiple GBSs together with the trajectory control of authorized UAVs and their GBS associations, for enhancing the authorized UAVs' communication performance while ensuring the sensing requirements for airspace monitoring. In particular, our objective is to maximize the average sum rate of authorized UAVs over a particular flight period, subject to the minimum illumination power constraints for sensing over the interested airspace, the maximum transmit power constraints at individual GBSs, and the flight constraints at UAVs. This problem is non-convex and challenging to solve, due to the involvement of integer variables and the coupling of optimization variables. To solve this non-convex problem, we propose an efficient algorithm by using the techniques of alternating optimization (AO), successive convex approximation (SCA), and semi-definite relaxation (SDR). Numerical results show that the obtained transmit beamforming and UAV trajectory designs in the proposed algorithm efficiently balance the tradeoff between the sensing and communication performances, thus significantly outperforming various benchmarks.

Fully-Passive versus Semi-Passive IRS-Enabled Sensing: SNR and CRB Comparison

This paper investigates the sensing performance of two intelligent reflecting surface (IRS)-enabled non-line-of-sight (NLoS) sensing systems with fully-passive and semi-passive IRSs, respectively. In particular, we consider a fundamental setup with one base station (BS), one uniform linear array (ULA) IRS, and one point target in the NLoS region of the BS. Accordingly, we analyze the sensing signal-to-noise ratio (SNR) performance for a target detection scenario and the estimation Cram\'er-Rao bound (CRB) performance for a target's direction-of-arrival (DoA) estimation scenario, in cases where the transmit beamforming at the BS and the reflective beamforming at the IRS are jointly optimized. First, for the target detection scenario, we characterize the maximum sensing SNR when the BS-IRS channels are line-of-sight (LoS) and Rayleigh fading, respectively. It is revealed that when the number of reflecting elements $N$ equipped at the IRS becomes sufficiently large, the maximum sensing SNR increases proportionally to $N^2$ for the semi-passive-IRS sensing system, but proportionally to $N^4$ for the fully-passive-IRS counterpart. Then, for the target's DoA estimation scenario, we analyze the minimum CRB performance when the BS-IRS channel follows Rayleigh fading. Specifically, when $N$ grows, the minimum CRB decreases inversely proportionally to $N^4$ and $N^6$ for the semi-passive and fully-passive-IRS sensing systems, respectively. Finally, numerical results are presented to corroborate our analysis across various transmit and reflective beamforming design schemes under general channel setups. It is shown that the fully-passive-IRS sensing system outperforms the semi-passive counterpart when $N$ exceeds a certain threshold. This advantage is attributed to the additional reflective beamforming gain in the IRS-BS path, which efficiently compensates for the path loss for a large $N$.

An Overview on IEEE 802.11bf: WLAN Sensing

With recent advancements, the wireless local area network (WLAN) or wireless fidelity (Wi-Fi) technology has been successfully utilized to realize sensing functionalities such as detection, localization, and recognition. However, the WLANs standards are developed mainly for the purpose of communication, and thus may not be able to meet the stringent requirements for emerging sensing applications. To resolve this issue, a new Task Group (TG), namely IEEE 802.11bf, has been established by the IEEE 802.11 working group, with the objective of creating a new amendment to the WLAN standard to meet advanced sensing requirements while minimizing the effect on communications. This paper provides a comprehensive overview on the up-to-date efforts in the IEEE 802.11bf TG. First, we introduce the definition of the 802.11bf amendment and its formation and standardization timeline. Next, we discuss the WLAN sensing use cases with the corresponding key performance indicator (KPI) requirements. After reviewing previous WLAN sensing research based on communication-oriented WLAN standards, we identify their limitations and underscore the practical need for the new sensing-oriented amendment in 802.11bf. Furthermore, we discuss the WLAN sensing framework and procedure used for measurement acquisition, by considering both sensing at sub-7GHz and directional multi-gigabit (DMG) sensing at 60 GHz, respectively, and address their shared features, similarities, and differences. In addition, we present various candidate technical features for IEEE 802.11bf, including waveform/sequence design, feedback types, as well as quantization and compression techniques. We also describe the methodologies and the channel modeling used by the IEEE 802.11bf TG for evaluation. Finally, we discuss the challenges and future research directions to motivate more research endeavors towards this field in details.

Fully-Passive versus Semi-Passive IRS-Enabled Sensing: SNR Analysis

This paper compares the signal-to-noise ratio (SNR) performance between the fully-passive intelligent reflecting surface (IRS)-enabled non-line-of-sight (NLoS) sensing versus its semi-passive counterpart. In particular, we consider a basic setup with one base station (BS), one uniform linear array (ULA) IRS, and one point target at the BS's NLoS region, in which the BS and the IRS jointly design the transmit and reflective beamforming for performance optimization. By considering two special cases with the BS-IRS channels being line-of-sight (LoS) and Rayleigh fading, respectively, we derive the corresponding asymptotic sensing SNR when the number of reflecting elements $N$ at the IRS becomes sufficiently large. It is revealed that in the two special cases, the sensing SNR increases proportional to $N^2$ for the semi-passive IRS sensing system, but proportional to $N^4$ for the fully-passive IRS sensing system. As such, the fully-passive IRS sensing system is shown to outperform the semi-passive counterpart when $N$ becomes large, which is due to the fact that the fully-passive IRS sensing enjoys additional reflective beamforming gain from the IRS to the BS that outweighs the resultant path loss in this case. Finally, numerical results are presented to validate our analysis under different transmit and reflective beamforming design schemes.

Fundamental CRB-Rate Tradeoff in Multi-Antenna ISAC Systems with Information Multicasting and Multi-Target Sensing

This paper investigates the performance tradeoff for a multi-antenna integrated sensing and communication (ISAC) system with simultaneous information multicasting and multi-target sensing, in which a multi-antenna base station (BS) sends the common information messages to a set of single-antenna communication users (CUs) and estimates the parameters of multiple sensing targets based on the echo signals concurrently. We consider two target sensing scenarios without and with prior target knowledge at the BS, in which the BS is interested in estimating the complete multi-target response matrix and the target reflection coefficients/angles, respectively. First, we consider the capacity-achieving transmission and characterize the fundamental tradeoff between the achievable rate and the multi-target estimation Cram\'er-Rao bound (CRB) accordingly.

Cramér-Rao Bound Minimization for IRS-Enabled Multiuser Integrated Sensing and Communications

This paper investigates an intelligent reflecting surface (IRS) enabled multiuser integrated sensing and communications (ISAC) system, which consists of one multi-antenna base station (BS), one IRS, multiple single-antenna communication users (CUs), and one target at the non-line-of-sight (NLoS) region of the BS. The IRS is deployed to not only assist the communication from the BS to the CUs, but also enable the BS's NLoS target sensing based on the echo signals from the BS-IRS-target-IRS-BS link. We consider two types of targets, namely the extended and point targets, for which the BS aims to estimate the complete target response matrix and the target direction-of-arrival (DoA) with respect to the IRS, respectively. To provide full degrees of freedom for sensing, we consider that the BS sends dedicated sensing signals in addition to the communication signals. Accordingly, we model two types of CU receivers, namely Type-I and Type-II CU receivers, which do not have and have the capability of canceling the interference from the sensing signals, respectively. Under each setup, we jointly optimize the transmit beamforming at the BS and the reflective beamforming at the IRS to minimize the Cram\'er-Rao bound (CRB) for target estimation, subject to the minimum signal-to-interference-plus-noise ratio (SINR) constraints at the CUs and the maximum transmit power constraint at the BS. We present efficient algorithms to solve the highly non-convex SINR-constrained CRB minimization problems, by using the techniques of alternating optimization, semi-definite relaxation, and successive convex approximation. Numerical results show that the proposed design achieves lower estimation CRB than other benchmark schemes, and the sensing signal interference cancellation at Type-II CU receivers is beneficial when the number of CUs is greater than one.

Cramér-Rao Bound Minimization for IRS-Enabled Multiuser Integrated Sensing and Communication with Extended Target

This paper investigates an intelligent reflecting surface (IRS) enabled multiuser integrated sensing and communication (ISAC) system, which consists of one multi-antenna base station (BS), one IRS, multiple single-antenna communication users (CUs), and one extended target at the non-line-of-sight (NLoS) region of the BS. The IRS is deployed to not only assist the communication from the BS to the CUs, but also enable the BS's NLoS target sensing based on the echo signals from the BS-IRS-target-IRS-BS link. To provide full degrees of freedom for sensing, we suppose that the BS sends additional dedicated sensing signals combined with the information signals. Accordingly, we consider two types of CU receivers, namely Type-I and Type-II receivers, which do not have and have the capability of cancelling the interference from the sensing signals, respectively. Under this setup, we jointly optimize the transmit beamforming at the BS and the reflective beamforming at the IRS to minimize the Cram\'er-Rao bound (CRB) for estimating the target response matrix with respect to the IRS, subject to the minimum signal-to-interference-plus-noise ratio (SINR) constraints at the CUs and the maximum transmit power constraint at the BS. We present efficient algorithms to solve the highly non-convex SINR-constrained CRB minimization problems, by using the techniques of alternating optimization and semi-definite relaxation. Numerical results show that the proposed design achieves lower estimation CRB than other benchmark schemes, and the sensing signal interference pre-cancellation is beneficial when the number of CUs is greater than one.

Intelligent Reflecting Surface Enabled Sensing: Cramér-Rao Bound Optimization

This paper investigates intelligent reflecting surface (IRS) enabled non-line-of-sight (NLoS) wireless sensing, in which an IRS is dedicatedly deployed to assist an access point (AP) to sense a target at its NLoS region. It is assumed that the AP is equipped with multiple antennas and the IRS is equipped with a uniform linear array. We consider two types of target models, namely the point and extended targets, for which the AP aims to estimate the target's direction-of-arrival (DoA) and the target response matrix with respect to the IRS, respectively, based on the echo signals from the AP-IRS-target-IRS-AP link. Under this setup, we jointly design the transmit beamforming at the AP and the reflective beamforming at the IRS to minimize the Cram\'er-Rao bound (CRB) on the estimation error. Towards this end, we first obtain the CRB expressions for the two target models in closed form. It is shown that in the point target case, the CRB for estimating the DoA depends on both the transmit and reflective beamformers; while in the extended target case, the CRB for estimating the target response matrix only depends on the transmit beamformers. Next, for the point target case, we optimize the joint beamforming design to minimize the CRB, via alternating optimization, semi-definite relaxation, and successive convex approximation. For the extended target case, we obtain the optimal transmit beamforming solution to minimize the CRB in closed form. Finally, numerical results show that for both cases, the proposed designs based on CRB minimization achieve improved sensing performance in terms of mean squared error, as compared to other traditional schemes.

Fundamental CRB-Rate Tradeoff in Multi-antenna Multicast Channel with ISAC

This paper studies the multi-antenna multicast channel with integrated sensing and communication (ISAC), in which a multi-antenna base station (BS) sends common messages to a set of single-antenna communication users (CUs) and simultaneously estimates the parameters of an extended target via radar sensing. We investigate the fundamental performance limits of this ISAC system, in terms of the achievable rate for communication and the estimation Cram\'er-Rao bound (CRB) for sensing. First, we derive the optimal transmit covariance in semi-closed form to balance the CRB-rate (C-R) tradeoff, and accordingly characterize the outer bound of a so-called C-R region. It is shown that the optimal transmit covariance should be of full rank, consisting of both information-carrying and dedicated sensing signals in general. Next, we consider a practical joint information and sensing beamforming design, and propose an efficient approach to optimize the joint beamforming for balancing the C-R tradeoff. Numerical results are presented to show the C-R region achieved by the optimal transmit covariance and the joint beamforming, as compared to other benchmark schemes.
