Power Allocation and Beamforming Design for IRS-aided Secure Directional Modulation Network

With the aim of boosting the security of the conventional directional modulation (DM) network, a secure DM network assisted by intelligent reflecting surface (IRS) is investigated in this paper. To maximize the security rate (SR), we jointly optimize the power allocation (PA) factor, confidential message (CM) beamforming, artificial noise (AN) beamforming, and IRS reflected beamforming. To tackle the formulated problem, a maximizing SR with high-performance (Max-SR-HP) scheme is proposed, where the PA factor, CM beamforming, AN beamforming, and IRS phase shift matrix are derived by the derivative operation, generalized Rayleigh-Rize, generalized power iteration, and semidefinite relaxation criteria, respectively. Given that the high complexity of the above scheme, a maximizing SR with low-complexity (Max-SR-LC) scheme is proposed, which employs the generalized leakage and successive convex approximation algorithms to derive the variables. Simulation results show that both the proposed schemes can significantly boost the SR performance, and are better than the equal PA, no IRS and random phase shift IRS schemes.

Two Enhanced-rate Power Allocation Strategies for Active IRS-assisted Wireless Network

Due to its ability of overcoming the impact of double-fading effect, active intelligent reflecting surface (IRS) has attracted a lot of attention. Unlike passive IRS, active IRS should be supplied by power, thus adjusting power between base station (BS) and IRS having a direct impact on the system rate performance. In this paper, the active IRS-aided network under a total power constraint is modeled with an ability of adjusting power between BS and IRS. Given the transmit beamforming at BS and reflecting beamforming at IRS, the SNR expression is derived to be a function of power allocation (PA) factor, and the optimization of maximizing the SNR is given. Subsequently, two high-performance PA strategies, enhanced multiple random initialization Newton's (EMRIN) and Taylor polynomial approximation (TPA), are proposed. The former is to improve the rate performance of classic Netwon's method to avoid involving a local optimal point by using multiple random initializations. To reduce its high computational complexity, the latter provides a closed-form solution by making use of the first-order Taylor polynomial approximation to the original SNR function. Actually, using TPA, the original optimization problem is transformed into a problem of finding a root for a third-order polynomial.Simulation results are as follows: the first-order TPA of SNR fit its exact expression well, the proposed two PA methods performs much better than fixed PA in accordance with rate, and appoaches exhaustive search as the number of IRS reflecting elements goes to large-scale.

Asymptotic Performance Analysis of Large-Scale Active IRS-Aided Wireless Network

In this paper, the dominant factor affecting the performance of active intelligent reflecting surface (IRS) aided wireless communication networks in Rayleigh fading channel, namely the average signal-to-noise ratio (SNR) $\gamma_0$ at IRS, is studied. Making use of the weak law of large numbers, its simple asymptotic expression is derived as the number $N$ of IRS elements goes to medium-scale and large-scale. When $N$ tends to large-scale, the asymptotic received SNR at user is proved to be a linear increasing function of a product of $\gamma_0$ and $N$. Subsequently, when the BS transmit power is fixed, there exists an optimal limited reflective power at IRS. At this point, more IRS reflect power will degrade the SNR performance. Additionally, under the total power sum constraint of the BS transmit power and the power reflected by the IRS, an optimal power allocation (PA) strategy is derived and shown to achieve 0.83 bit rate gain over equal PA. Finally, an IRS with finite phase shifters being taken into account, generates phase quantization errors, and further leads to a degradation of receive performance. The corresponding closed-form performance loss expressions for user's asymptotic SNR, achievable rate (AR), and bit error rate (BER) are derived for active IRS. Numerical simulation results show that a 3-bit discrete phase shifter is required to achieve a trivial performance loss for a large-scale active IRS.

Beamforming and Phase Shift Design for HR-IRS-aided Directional Modulation Network with a Malicious Attacker

In this paper, we propose to use hybrid relay-intelligent reflecting surface (HR-IRS) to improve the security performance of directional modulation (DM) system. In particular, the eavesdropper in this system works in full-duplex (FD) mode and he will eavesdrop on the confidential message (CM) as well as send malicious jamming. We aim to maximize the secrecy rate (SR) by jointly optimizing the receive beamforming, transmit beamforming and phase shift matrix (PSM) of HR-IRS. Since the optimization problem is un-convex and the variables are coupled to each other, we solve this problem by iteratively optimizing these variables. The receive beamforming and transmit beamforming are obtained based on generalized Rayleigh-Ritz theorem and Dinkelbach's Transform respectively. And for PSM, two methods, called separate optimization of PSM (SO-PSM) and joint optimization of PSM (JO-PSM) are proposed. Thus, two iterative algorithms are proposed accordingly, namely maximizing SR based on SO-PSM (Max-SR-SOP) and maximizing SR based on JO-PSM (Max-SR-JOP). The former has better performance and the latter has lower complexity. The simulation results show that when HR-IRS has sufficient power budget, the proposed Max-SR-SOP and Max-SR-JOP can enable HR-IRS-aided DM network to obtain higher SR than passive IRS-aided DM network.

Enhanced-rate Iterative Beamformers for Active IRS-assisted Wireless Communications

Compared to passive intelligent reflecting surface (IRS), active IRS is viewed as a more efficient promising technique to combat the double-fading impact in IRS-aided wireless network. In this paper, in order to boost the achievable rate of user in such a wireless network, three enhanced-rate iterative beamforming methods are proposed by designing the amplifying factors and the corresponding phases at active IRS. The first method, called generalized maximum ratio reflection (GMRR), is presented with a closed-form expression, which is motivated by the maximum ratio combing. To further improve rate, maximize the simplified signal-to-noise ratio (Max-SSNR) is designed by omitting the cross-term in the definition of rate. Using the Rayleigh-Ritz (RR) theorem and the fractional programming (FP), two enhanced methods, Max-SSNR-RR and Max-SSNR-FP are proposed to iteratively optimize the norm of beamforming vector and its associated normalized vector. Simulation results indicate that the proposed three methods make an obvious rate enhancement over Max-reflecting signal-to-noise ratio (RSNR) and passive IRS, and are in increasing order of rate performance as follows: GMRR, Max-SSNR-RR, and Max-SSNR-FP.

Three High-rate Beamforming Methods for Active IRS-aided Wireless Network

Due to its ability of breaking the double-fading effect faced by passive intelligent reflecting surface (IRS), active IRS is evolving a potential technique for future 6G wireless network. To fully exploit the amplifying gain achieved by active IRS, two high-rate methods, maximum ratio reflecting (MRR) and selective ratio reflecting (SRR) are presented, which are motivated by maximum ratio combining and selective ratio combining. Moreover, both MRR and SRR are in closed-form. To further improve the rate, a maximum reflected-signal-to-noise ratio (Max-RSNR) is first proposed with an alternately iterative infrastructure between adjusting the norm of beamforming vector and its normalized vector. This may make a substantial rate enhancement over existing equal-gain reflecting (EGR). Simulation results show the proposed three methods perform much better than existing method EGR in terms of rate. They are in decreasing order of rate performance: Max-RSNR, MRR, SRR, and EGR.

Two Low-complexity Efficient Beamformers for IRS-aided Directional Modulation Networks

As an excellent tool for aiding communication, intelligent reflecting surface (IRS) can extend the coverage area, remove blind area, and achieve a dramatic rate improvement. In this paper, we improve the secret rate (SR) performance at directional modulation (DM) networks using IRS. To fully explore the benefits of IRS, two efficient methods are proposed to enhance SR performance. The first approach computes the confidential message (CM) beamforming vector by maximizing the SR, and the signal-to-leakage-noise ratio (SLNR) method is used to optimize the IRS phase shift matrix, which is called Max-SR-SLNR. Here, Eve is maximally interfered by transmiting artificial noise (AN) along the direct path and null-space projection (NSP) on the remaining two channels. To reduce the computational complexity, the CM, AN beamforming and IRS phase shift design are independently designed in the following methods. The CM beamforming vector is constructed based on maximum ratio transmission (MRT) criteria along the channel from Alice-to-IRS, and phase shift matrix of IRS is directly given by phase alignment (PA) method. This method is called MRT-NSP-PA. Simulation results show that the SR performance of the Max-SR-SLNR method outperforms the MRT-NSP-PA method in the cases of small-scale and medium-scale IRSs, and the latter approaches the former as IRS tends to lager-scale.

Enhanced Secure Wireless Transmission Using IRS-aided Directional Modulation

As an excellent aided communication tool, intelligent reflecting surface (IRS) can make a significant rate enhancement and coverage extension. In this paper, we present an investigation on beamforming in an IRS-aided directional modulation (DM) network. To fully explore the advantages of IRS, two beamforming methods with enhanced secrecy rate (SR) performance are proposed. The first method of maximizing secrecy rate (Max-SR) alternately optimizes confidential message (CM) beamforming vector, artificial noise (AN) beamforming vector and phase shift matrix. The first optimization vector is directly computed by the Rayleigh ratio and the last two are solved with generalized power iteration (GPI). This method is called Max-SR-GPI. To reduce the computational complexity, a new method of maximizing receive power with zero-forcing constraint (Max-RP-ZFC) of only reflecting CM and no AN is proposed. Simulation results show that the proposed two methods harvest about 30 percent rate gains over the cases of random-phase IRS and no IRS, and the proposed Max-SR-GPI performs slightly better than the Max-RP-ZFC in terms of SR, particularly in the small-large IRS.

Low-complexity Joint Phase Adjustment and Receive Beamforming for Directional Modulation Networks via IRS

Intelligent reflecting surface (IRS) is a revolutionary and low-cost technology for boosting the spectrum and energy efficiencies in future wireless communication network. In order to create controllable multipath transmission in the conventional line-of-sight (LOS) wireless communication environment, an IRS-aided directional modulation (DM) network is considered. In this paper, to improve the transmission security of the system and maximize the receive power sum (Max-RPS), two alternately optimizing schemes of jointly designing receive beamforming (RBF) vectors and IRS phase shift matrix (PSM) are proposed: Max-RPS using general alternating optimization (Max-RPS-GAO) algorithm and Max-RPS using zero-forcing (Max-RPS-ZF) algorithm. Simulation results show that, compared with the no-IRS-assisted scheme and the no-PSM optimization scheme, the proposed IRS-assisted Max-RPS-GAO method and Max-RPS-ZF method can significantly improve the secrecy rate (SR) performance of the DM system. Moreover, compared with the Max-RPS-GAO method, the proposed Max-RPS-ZF method has a faster convergence speed and a certain lower computational complexity.

Performance Analysis of Wireless Network Aided by Discrete-Phase-Shifter IRS

Discrete phase shifters of intelligent reflecting surface (IRS) generates phase quantization error (QE) and degrades the receive performance at the receiver. To make an analysis of the performance loss caused by IRS with phase QE, based on the law of large numbers, the closed-form expressions of signal-to-noise ratio (SNR) performance loss (PL), achievable rate (AR), and bit error rate (BER) are successively derived under line-of-sight (LoS) channels and Rayleigh channels. Moreover, based on the Taylor series expansion, the approximate simple closed form of PL of IRS with approximate QE is also given. The simulation results show that the performance losses of SNR and AR decrease as the number of quantization bits increase, while they gradually increase with the number of IRS phase shifter elements increase. Regardless of LoS channels or Rayleigh channels, when the number of quantization bits is larger than or equal to 3, the performance losses of SNR and AR are less than 0.23dB and 0.08bits/s/Hz, respectively, and the BER performance degradation is trivial. In particular, the performance loss difference between IRS with QE and IRS with approximate QE is negligible when the number of quantization bits is not less than 2.
