Variational Signal Separation for Automotive Radar Interference Mitigation

Algorithms for joint mutual interference mitigation and object parameter estimation are a key enabler for automotive applications of frequency-modulated continuous wave (FMCW) radar. The underlying signal model poses a challenge for signal separation, since both the coherent radar echo and the non-coherent interference influenced by individual multipath propagation channels must be considered. In particular, under certain assumptions, the model is described as a superposition of multipath channels weighted by parametric chirp envelopes in the case of interference. In this paper, we introduce a method inspired by sparse Bayesian learning (SBL) to detect and estimate radar object parameters while also estimating and successively canceling the interference signal. An augmented probabilistic model is employed that uses hierarchical Gamma-Gaussian prior model for each multipath channel separately. Based on this model an iterative inference algorithm is derived using the variational expectation-maximization (EM) methodology. The algorithm is statistically evaluated in terms of object parameter estimation accuracy and robustness, indicating that it is fundamentally capable of achieving the Cramer-Rao lower bound (CRLB) with respect to the accuracy of object estimates and it closely follows the radar performance achieved when no interference is present.

Multipath-based SLAM with Cooperation and Map Fusion

Multipath-based simultaneous localization and mapping (MP-SLAM) is a promising approach in wireless networks for obtaining position information of transmitters and receivers as well as information on the propagation environment. MP-SLAM models specular reflections of radio frequency (RF) signals at flat surfaces as virtual anchors (VAs), the mirror images of base stations (BSs). Conventional methods for MP-SLAM consider a single mobile terminal (MT) which has to be localized. The availability of additional MTs paves the way for utilizing additional information in the scenario. Specifically enabling MTs to exchange information allows for data fusion over different observations of VAs made by different MTs. Furthermore, cooperative localization becomes possible in addition to multipath-based localization. Utilizing this additional information enables more robust mapping and higher localization accuracy.

MIMO Multipath-based SLAM for Non-Ideal Reflective Surfaces

Multipath-based simultaneous localization and mapping (MP-SLAM) is a well established approach to obtain position information of transmitters and receivers as well as information regarding the propagation environments in future multiple input multiple output (MIMO) communication systems. Conventional methods for MP-SLAM consider specular reflections of the radio signals occurring at smooth, flat surfaces, which are modeled by virtual anchors (VAs) that are mirror images of the physical anchors (PAs), with each VA generating a single multipath component (MPC). However, non-ideal reflective surfaces (such as walls covered by shelves or cupboards) cause dispersion effects that violate the VA model and lead to multiple MPCs that are associated to a single VA. In this paper, we introduce a Bayesian particle-based sum-product algorithm (SPA) for MP-SLAM in MIMO communications systems. Our method considers non-ideal reflective surfaces by jointly estimating the parameters of individual dispersion models for each detected surface in delay and angle domain leveraging multiple-measurement-to-feature data association. We demonstrate that the proposed SLAM method can robustly and jointly estimate the positions and dispersion extents of ideal and non-ideal reflective surfaces using numerical simulation.

Fusion of Active and Passive Measurements for Robust and Scalable Positioning

This paper addresses the challenge of achieving reliable and robust positioning of a mobile agent, such as a radio device carried by a person, in scenarios where direct line-of-sight (LOS) links are obstructed or unavailable. The human body is considered as an extended object that scatters, attenuates and blocks the radio signals. We propose a novel particle-based sum-product algorithm (SPA) that fuses active measurements between the agent and anchors with passive measurements from pairs of anchors reflected off the body. We first formulate radio signal models for both active and passive measurements. Then, a joint tracking algorithm that utilizes both active and passive measurements is developed for the extended object. The algorithm exploits the probabilistic data association (PDA) for multiple object-related measurements. The results demonstrate superior accuracy during and after the obstructed line-of-sight (OLOS) situation, outperforming conventional methods that solely rely on active measurements. The proposed joint estimation approach significantly enhances the localization robustness via radio sensing.

"UWBCarGraz" Dataset for Car Occupancy Detection using Ultra-Wideband Radar

We present a data-driven car occupancy detection algorithm using ultra-wideband radar based on the ResNet architecture. The algorithm is trained on a dataset of channel impulse responses obtained from measurements at three different activity levels of the occupants (i.e. breathing, talking, moving). We compare the presented algorithm against a state-of-the-art car occupancy detection algorithm based on variational message passing (VMP). Our presented ResNet architecture is able to outperform the VMP algorithm in terms of the area under the receiver operating curve (AUC) at low signal-to-noise ratios (SNRs) for all three activity levels of the target. Specifically, for an SNR of -20 dB the VMP detector achieves an AUC of 0.87 while the ResNet architecture achieves an AUC of 0.91 if the target is sitting still and breathing naturally. The difference in performance for the other activities is similar. To facilitate the implementation in the onboard computer of a car we perform an ablation study to optimize the tradeoff between performance and computational complexity for several ResNet architectures. The dataset used to train and evaluate the algorithm is openly accessible. This facilitates an easy comparison in future works.

Graph-based Simultaneous Localization and Bias Tracking

We present a factor graph formulation and particle-based sum-product algorithm for robust localization and tracking in multipath-prone environments. The proposed sequential algorithm jointly estimates the mobile agent's position together with a time-varying number of multipath components (MPCs). The MPCs are represented by "delay biases" corresponding to the offset between line-of-sight (LOS) component delay and the respective delays of all detectable MPCs. The delay biases of the MPCs capture the geometric features of the propagation environment with respect to the mobile agent. Therefore, they can provide position-related information contained in the MPCs without explicitly building a map of the environment. We demonstrate that the position-related information enables the algorithm to provide high-accuracy position estimates even in fully obstructed line-of-sight (OLOS) situations. Using simulated and real measurements in different scenarios we demonstrate the proposed algorithm to significantly outperform state-of-the-art multipath-aided tracking algorithms and show that the performance of our algorithm constantly attains the posterior Cramer-Rao lower bound (P-CRLB). Furthermore, we demonstrate the implicit capability of the proposed method to identify unreliable measurements and, thus, to mitigate lost tracks.

A Neural-enhanced Factor Graph-based Algorithm for Robust Positioning in Obstructed LOS Situations

This paper presents a neural-enhanced probabilistic model and corresponding factor graph-based sum-product algorithm for robust localization and tracking in multipath-prone environments. The introduced hybrid probabilistic model consists of physics-based and data-driven measurement models capturing the information contained in both, the line-of-sight (LOS) component as well as in multipath components (NLOS components). The physics-based and data-driven models are embedded in a joint Bayesian framework allowing to derive from first principles a factor graph-based algorithm that fuses the information of these models. The proposed algorithm uses radio signal measurements from multiple base stations to robustly estimate the mobile agent's position together with all model parameters. It provides high localization accuracy by exploiting the position-related information of the LOS component via the physics-based model and robustness by exploiting the geometric imprint of multipath components independent of the propagation channel via the data-driven model. In a challenging numerical experiment involving obstructed LOS situations to all anchors, we show that the proposed sequential algorithm significantly outperforms state-of-the-art methods and attains the posterior Cramer-Rao lower bound even with training data limited to local regions.

Super-Resolution Estimation of UWB Channels including the Diffuse Component -- An SBL-Inspired Approach

In this paper, we present an iterative algorithm that detects and estimates the specular components and estimates the diffuse component of single-input-multiple-output (SIMO) ultra-wide-band (UWB) multipath channels. Specifically, the algorithm super-resolves the specular components in the delay-angle-of-arrival domain and estimates the parameters of a parametric model of the delay-angle power spectrum characterizing the diffuse component. Channel noise is also estimated. In essence, the algorithm solves the problem of estimating spectral lines (the specular components) in colored noise (generated by the diffuse component and channel noise). Its design is inspired by the sparse Bayesian learning (SBL) framework. As a result the iteration process contains a threshold condition that determines whether a candidate specular component shall be retained or pruned. By relying to results from extreme-value analysis the threshold of this condition is suitably adapted to ensure a prescribed probability of detecting spurious specular components. Studies using synthetic and real channel measurement data demonstrate the virtues of the algorithm: it is able to still detect and accurately estimate specular components, even when their separation in delay and angle is down to half the Rayleigh resolution limit (RRL) of the equipment; it is robust in the sense that it tends to return no more specular components than the actual ones. Finally, the algorithm is shown to outperform a state-of-the-art super-resolution channel estimator.

Fast Variational Block-Sparse Bayesian Learning

We present a fast update rule for variational block-sparse Bayesian learning (SBL) methods. Using a variational Bayesian framework, we show how repeated updates of probability density functions (PDFs) of the prior variances and weights can be expressed as a nonlinear first-order recurrence from one estimate of the parameters of the proxy PDFs to the next. Specifically, the recurrent relation turns out to be a strictly increasing rational function for many commonly used prior PDFs of the variances, such as Jeffrey's prior. Hence, the fixed points of this recurrent relation can be obtained by solving for the roots of a polynomial. This scheme allows to check for convergence/divergence of individual prior variances in a single step. Thereby, the the computational complexity of the variational block-SBL algorithm is reduced and the convergence speed is improved by two orders of magnitude in our simulations. Furthermore, the solution allows insights into the sparsity of the estimators obtained by choosing different priors.

Propagation Modeling for Physically Large Arrays: Measurements and Multipath Component Visibility

This paper deals with propagation and channel modeling for physically large arrays. The focus lies on acquiring a spatially consistent model, which is essential, especially for positioning and sensing applications. Ultra-wideband, synthetic array measurement data have been acquired with large positioning devices to support this research. We present a modified multipath channel model that accounts for a varying visibility of multipath components along a large array. Based on a geometric model of the measurement environment, we analyze the visibility of specular components. We show that, depending on the size of the reflecting surface, geometric visibility and amplitude estimates obtained with a super-resolution channel estimation algorithm show a strong correspondence. Furthermore, we highlight the capabilities of the developed synthetic array measurement system.
