Physically Large Apertures for Wireless Power Transfer: Performance and Regulatory Aspects

Wireless power transfer (WPT) is a promising service for the Internet of Things, providing a cost-effective and sustainable solution to deploy so-called energy-neutral devices on a massive scale. The power received at the device side decays rapidly with the distance from a conventional transmit antenna with a physically small aperture. New opportunities arise from the transition from conventional far-field beamforming to near-field beam focusing. We argue that a "physically large" aperture, i.e., large w.r.t. the distance to the receiver, enables a power budget that remains practically independent of distance. Distance-dependent array gain patterns allow focusing the power density maximum precisely at the device location, while reducing the power density near the infrastructure. The physical aperture size is a key resource in enabling efficient yet regulatory-compliant WPT. We use real-world measurements to demonstrate that a regulatory-compliant system operating at sub-10GHz frequencies can increase the power received at the device into the milliwatt range. Our empirical demonstration shows that power-optimal near-field beam focusing inherently exploits multipath propagation, yielding both increased WPT efficiency and improved human exposure safety in real-world scenarios.

Statistical Modeling of the Human Body as an Extended Antenna

In this paper we investigate the possibility of modeling a single antenna alone and in close proximity to a physical object by means of discrete point source scatterers. The scatter point model allows joint modeling of a physical antenna and the human body as a single extended object with direction dependent scattering coefficients for the scatter points. We introduce the term extended antenna describing antenna and human body together. To investigate the identifiability of the model parameters we make use of ultrawideband channel measurements and accurate ground truth position and orientation measurements obtained with an optical tracking system. By comparing measurements of the antenna attached directly to the user with measurements for the antenna without the user nearby, we show the shadowing and scattering effects of the human body and the antenna.
