AEON Lab, University of Illinois Chicago
Abstract:We present a novel statistical approach to incorporating uncertainty awareness in model-free distributional reinforcement learning involving quantile regression-based deep Q networks. The proposed algorithm, $\textit{Calibrated Evidential Quantile Regression in Deep Q Networks (CEQR-DQN)}$, aims to address key challenges associated with separately estimating aleatoric and epistemic uncertainty in stochastic environments. It combines deep evidential learning with quantile calibration based on principles of conformal inference to provide explicit, sample-free computations of $\textit{global}$ uncertainty as opposed to $\textit{local}$ estimates based on simple variance, overcoming limitations of traditional methods in computational and statistical efficiency and handling of out-of-distribution (OOD) observations. Tested on a suite of miniaturized Atari games (i.e., MinAtar), CEQR-DQN is shown to surpass similar existing frameworks in scores and learning speed. Its ability to rigorously evaluate uncertainty improves exploration strategies and can serve as a blueprint for other algorithms requiring uncertainty awareness.
Abstract:This paper addresses the challenging problem of energy-efficient and uncertainty-aware pose estimation in insect-scale drones, which is crucial for tasks such as surveillance in constricted spaces and for enabling non-intrusive spatial intelligence in smart homes. Since tiny drones operate in highly dynamic environments, where factors like lighting and human movement impact their predictive accuracy, it is crucial to deploy uncertainty-aware prediction algorithms that can account for environmental variations and express not only the prediction but also confidence in the prediction. We address both of these challenges with Compute-in-Memory (CIM) which has become a pivotal technology for deep learning acceleration at the edge. While traditional CIM techniques are promising for energy-efficient deep learning, to bring in the robustness of uncertainty-aware predictions at the edge, we introduce a suite of novel techniques: First, we discuss CIM-based acceleration of Bayesian filtering methods uniquely by leveraging the Gaussian-like switching current of CMOS inverters along with co-design of kernel functions to operate with extreme parallelism and with extreme energy efficiency. Secondly, we discuss the CIM-based acceleration of variational inference of deep learning models through probabilistic processing while unfolding iterative computations of the method with a compute reuse strategy to significantly minimize the workload. Overall, our co-design methodologies demonstrate the potential of CIM to improve the processing efficiency of uncertainty-aware algorithms by orders of magnitude, thereby enabling edge robotics to access the robustness of sophisticated prediction frameworks within their extremely stringent area/power resources.
Abstract:This paper introduces a lightweight uncertainty estimator capable of predicting multimodal (disjoint) uncertainty bounds by integrating conformal prediction with a deep-learning regressor. We specifically discuss its application for visual odometry (VO), where environmental features such as flying domain symmetries and sensor measurements under ambiguities and occlusion can result in multimodal uncertainties. Our simulation results show that uncertainty estimates in our framework adapt sample-wise against challenging operating conditions such as pronounced noise, limited training data, and limited parametric size of the prediction model. We also develop a reasoning framework that leverages these robust uncertainty estimates and incorporates optical flow-based reasoning to improve prediction prediction accuracy. Thus, by appropriately accounting for predictive uncertainties of data-driven learning and closing their estimation loop via rule-based reasoning, our methodology consistently surpasses conventional deep learning approaches on all these challenging scenarios--pronounced noise, limited training data, and limited model size-reducing the prediction error by 2-3x.
Abstract:In the expanding landscape of AI-enabled robotics, robust quantification of predictive uncertainties is of great importance. Three-dimensional (3D) object detection, a critical robotics operation, has seen significant advancements; however, the majority of current works focus only on accuracy and ignore uncertainty quantification. Addressing this gap, our novel study integrates the principles of conformal inference (CI) with information theoretic measures to perform lightweight, Monte Carlo-free uncertainty estimation within a multimodal framework. Through a multivariate Gaussian product of the latent variables in a Variational Autoencoder (VAE), features from RGB camera and LiDAR sensor data are fused to improve the prediction accuracy. Normalized mutual information (NMI) is leveraged as a modulator for calibrating uncertainty bounds derived from CI based on a weighted loss function. Our simulation results show an inverse correlation between inherent predictive uncertainty and NMI throughout the model's training. The framework demonstrates comparable or better performance in KITTI 3D object detection benchmarks to similar methods that are not uncertainty-aware, making it suitable for real-time edge robotics.
Abstract:The edge processing of deep neural networks (DNNs) is becoming increasingly important due to its ability to extract valuable information directly at the data source to minimize latency and energy consumption. Frequency-domain model compression, such as with the Walsh-Hadamard transform (WHT), has been identified as an efficient alternative. However, the benefits of frequency-domain processing are often offset by the increased multiply-accumulate (MAC) operations required. This paper proposes a novel approach to an energy-efficient acceleration of frequency-domain neural networks by utilizing analog-domain frequency-based tensor transformations. Our approach offers unique opportunities to enhance computational efficiency, resulting in several high-level advantages, including array micro-architecture with parallelism, ADC/DAC-free analog computations, and increased output sparsity. Our approach achieves more compact cells by eliminating the need for trainable parameters in the transformation matrix. Moreover, our novel array micro-architecture enables adaptive stitching of cells column-wise and row-wise, thereby facilitating perfect parallelism in computations. Additionally, our scheme enables ADC/DAC-free computations by training against highly quantized matrix-vector products, leveraging the parameter-free nature of matrix multiplications. Another crucial aspect of our design is its ability to handle signed-bit processing for frequency-based transformations. This leads to increased output sparsity and reduced digitization workload. On a 16$\times$16 crossbars, for 8-bit input processing, the proposed approach achieves the energy efficiency of 1602 tera operations per second per Watt (TOPS/W) without early termination strategy and 5311 TOPS/W with early termination strategy at VDD = 0.8 V.
Abstract:The rapid advancement of deep neural networks has significantly improved various tasks, such as image and speech recognition. However, as the complexity of these models increases, so does the computational cost and the number of parameters, making it difficult to deploy them on resource-constrained devices. This paper proposes a novel memorization-based inference (MBI) that is compute free and only requires lookups. Specifically, our work capitalizes on the inference mechanism of the recurrent attention model (RAM), where only a small window of input domain (glimpse) is processed in a one time step, and the outputs from multiple glimpses are combined through a hidden vector to determine the overall classification output of the problem. By leveraging the low-dimensionality of glimpse, our inference procedure stores key value pairs comprising of glimpse location, patch vector, etc. in a table. The computations are obviated during inference by utilizing the table to read out key-value pairs and performing compute-free inference by memorization. By exploiting Bayesian optimization and clustering, the necessary lookups are reduced, and accuracy is improved. We also present in-memory computing circuits to quickly look up the matching key vector to an input query. Compared to competitive compute-in-memory (CIM) approaches, MBI improves energy efficiency by almost 2.7 times than multilayer perceptions (MLP)-CIM and by almost 83 times than ResNet20-CIM for MNIST character recognition.
Abstract:This work discusses memory-immersed collaborative digitization among compute-in-memory (CiM) arrays to minimize the area overheads of a conventional analog-to-digital converter (ADC) for deep learning inference. Thereby, using the proposed scheme, significantly more CiM arrays can be accommodated within limited footprint designs to improve parallelism and minimize external memory accesses. Under the digitization scheme, CiM arrays exploit their parasitic bit lines to form a within-memory capacitive digital-to-analog converter (DAC) that facilitates area-efficient successive approximation (SA) digitization. CiM arrays collaborate where a proximal array digitizes the analog-domain product-sums when an array computes the scalar product of input and weights. We discuss various networking configurations among CiM arrays where Flash, SA, and their hybrid digitization steps can be efficiently implemented using the proposed memory-immersed scheme. The results are demonstrated using a 65 nm CMOS test chip. Compared to a 40 nm-node 5-bit SAR ADC, our 65 nm design requires $\sim$25$\times$ less area and $\sim$1.4$\times$ less energy by leveraging in-memory computing structures. Compared to a 40 nm-node 5-bit Flash ADC, our design requires $\sim$51$\times$ less area and $\sim$13$\times$ less energy.
Abstract:Data-driven visual odometry (VO) is a critical subroutine for autonomous edge robotics, and recent progress in the field has produced highly accurate point predictions in complex environments. However, emerging autonomous edge robotics devices like insect-scale drones and surgical robots lack a computationally efficient framework to estimate VO's predictive uncertainties. Meanwhile, as edge robotics continue to proliferate into mission-critical application spaces, awareness of model's the predictive uncertainties has become crucial for risk-aware decision-making. This paper addresses this challenge by presenting a novel, lightweight, and statistically robust framework that leverages conformal inference (CI) to extract VO's uncertainty bands. Our approach represents the uncertainties using flexible, adaptable, and adjustable prediction intervals that, on average, guarantee the inclusion of the ground truth across all degrees of freedom (DOF) of pose estimation. We discuss the architectures of generative deep neural networks for estimating multivariate uncertainty bands along with point (mean) prediction. We also present techniques to improve the uncertainty estimation accuracy, such as leveraging Monte Carlo dropout (MC-dropout) for data augmentation. Finally, we propose a novel training loss function that combines interval scoring and calibration loss with traditional training metrics--mean-squared error and KL-divergence--to improve uncertainty-aware learning. Our simulation results demonstrate that the presented framework consistently captures true uncertainty in pose estimations across different datasets, estimation models, and applied noise types, indicating its wide applicability.
Abstract:We propose MC-CIM, a compute-in-memory (CIM) framework for robust, yet low power, Bayesian edge intelligence. Deep neural networks (DNN) with deterministic weights cannot express their prediction uncertainties, thereby pose critical risks for applications where the consequences of mispredictions are fatal such as surgical robotics. To address this limitation, Bayesian inference of a DNN has gained attention. Using Bayesian inference, not only the prediction itself, but the prediction confidence can also be extracted for planning risk-aware actions. However, Bayesian inference of a DNN is computationally expensive, ill-suited for real-time and/or edge deployment. An approximation to Bayesian DNN using Monte Carlo Dropout (MC-Dropout) has shown high robustness along with low computational complexity. Enhancing the computational efficiency of the method, we discuss a novel CIM module that can perform in-memory probabilistic dropout in addition to in-memory weight-input scalar product to support the method. We also propose a compute-reuse reformulation of MC-Dropout where each successive instance can utilize the product-sum computations from the previous iteration. Even more, we discuss how the random instances can be optimally ordered to minimize the overall MC-Dropout workload by exploiting combinatorial optimization methods. Application of the proposed CIM-based MC-Dropout execution is discussed for MNIST character recognition and visual odometry (VO) of autonomous drones. The framework reliably gives prediction confidence amidst non-idealities imposed by MC-CIM to a good extent. Proposed MC-CIM with 16x31 SRAM array, 0.85 V supply, 16nm low-standby power (LSTP) technology consumes 27.8 pJ for 30 MC-Dropout instances of probabilistic inference in its most optimal computing and peripheral configuration, saving 43% energy compared to typical execution.
Abstract:This work proposes a novel Energy-Aware Network Operator Search (ENOS) approach to address the energy-accuracy trade-offs of a deep neural network (DNN) accelerator. In recent years, novel inference operators have been proposed to improve the computational efficiency of a DNN. Augmenting the operators, their corresponding novel computing modes have also been explored. However, simplification of DNN operators invariably comes at the cost of lower accuracy, especially on complex processing tasks. Our proposed ENOS framework allows an optimal layer-wise integration of inference operators and computing modes to achieve the desired balance of energy and accuracy. The search in ENOS is formulated as a continuous optimization problem, solvable using typical gradient descent methods, thereby scalable to larger DNNs with minimal increase in training cost. We characterize ENOS under two settings. In the first setting, for digital accelerators, we discuss ENOS on multiply-accumulate (MAC) cores that can be reconfigured to different operators. ENOS training methods with single and bi-level optimization objectives are discussed and compared. We also discuss a sequential operator assignment strategy in ENOS that only learns the assignment for one layer in one training step, enabling greater flexibility in converging towards the optimal operator allocations. Furthermore, following Bayesian principles, a sampling-based variational mode of ENOS is also presented. ENOS is characterized on popular DNNs ShuffleNet and SqueezeNet on CIFAR10 and CIFAR100.
