Tri-Hybrid Holographic Beamforming for Integrated Sensing and Communication

Integrated sensing and communication (ISAC) can perform both communication and sensing tasks using the same frequency band and hardware, making it a key technology for 6G. As a low-cost implementation for large-scale antenna arrays, reconfigurable holographic surfaces (RHSs) can be integrated into ISAC systems to realize the holographic ISAC paradigm, where enlarged radiation apertures achieve significant beamforming gains. In this paper, we investigate the tri-hybrid holographic ISAC framework, where the beamformer comprises digital, analog, and RHS-based electromagnetic (EM) layers. The analog layer employs a small number of phase shifters (PSs) to provide subarray-level phase control for the amplitude-modulated RHSs. Tri-hybrid beamforming provides a pathway for low-cost large-scale holographic ISAC. However, compared to conventional ISAC systems, it is challenging to achieve joint subarray-level phase control via PSs and element-level radiation amplitude control via RHSs for holographic ISAC. To address this, we present a tri-hybrid holographic ISAC scheme that minimizes sensing waveform error while satisfying the minimum user rate requirement. A joint optimization approach for PS phases and RHS amplitude responses is designed to address inter-layer coupling and distinct feasible regions. Theoretical analyses reveal that the optimized amplitude responses cluster near boundary values, i.e., 1-bit amplitude control, to reduce hardware and algorithmic complexity. Simulation results show that the proposed scheme achieves a controllable performance trade-off between communication and sensing tasks. Measured RHS beam gain validates the enhancement of holographic beamforming through subarray-level phase shifting. Moreover, as the number of RHS elements increases, the proposed approach exceeds the performance of conventional hybrid beamforming while significantly reducing the number of PSs.

Achievable Degrees of Freedom Analysis and Optimization in Massive MIMO via Characteristic Mode Analysis

Massive multiple-input multiple-output (MIMO) is esteemed as a critical technology in 6G communications, providing large degrees of freedom (DoF) to improve multiplexing gain. This paper introduces characteristic mode analysis (CMA) to derive the achievable DoF. Unlike existing works primarily focusing on the DoF of the wireless channel,the excitation and radiation properties of antennas are also involved in our DoF analysis, which influences the number of independent data streams for communication of a MIMO system. Specifically, we model the excitation and radiation properties of transceiver antennas using CMA to analyze the excitation and radiation properties of antennas. The CMA-based DoF analysis framework is established and the achievable DoF is derived. A characteristic mode optimization problem of antennas is then formulated to maximize the achievable DoF. A case study where the reconfigurable holographic surface (RHS) antennas are deployed at the transceiver is investigated, and a CMA-based genetic algorithm is later proposed to solve the above problem. By changing the characteristic modes electric field and surface current distribution of RHS, the achievable DoF is enhanced. Full-wave simulation verifies the theoretical analysis on the the achievable DoF and shows that, via the reconfiguration of RHS based on the proposed algorithm, the achievable DoF is improved.

Simultaneous Beamforming and Anti-Jamming With Intelligent Omni-Surfaces

Wireless transmission is vulnerable to malicious jamming attacks due to the openness of wireless channels, posing a severe threat to wireless communications. Current anti-jamming studies primarily focus on either enhancing desired signals or mitigating jamming, resulting in limited performance. To address this issue, intelligent omni-surface (IOS) is a promising solution. By jointly designing its reflective and refractive properties, the IOS can simultaneously nullify jamming and enhance desired signals. In this paper, we consider an IOS-aided multi-user anti-jamming communication system, aiming to improve desired signals and nullify jamming by optimizing IOS phase shifts and transmit beamforming. However, this is challenging due to the coupled and discrete IOS reflection and refraction phase shifts, the unknown jammer's beamformer, and imperfect jammer-related channel state information. To tackle this, we relax IOS phase shifts to continuous states and optimize with a coupling-aware algorithm using the Cauchy-Schwarz inequality and S-procedure, followed by a local search to recover discrete states. Simulation results show that the proposed scheme significantly improves the sum rate amid jamming attacks.

Beamforming Design for Wideband Near-Field Communications With Reconfigurable Refractive Surfaces

To meet the growing demand for high data rates, cellular systems are expected to evolve towards higher carrier frequencies and larger antenna arrays, but conventional phased arrays face challenges in supporting such a prospection due to their excessive power consumption induced by numerous phase shifters required. Reconfigurable Refractive Surface (RRS) is an energy efficient solution to address this issue without relying on phase shifters. However, the increased radiation aperture size extends the range of the Fresnel region, leading the users to lie in the near-field zone. Moreover, given the wideband communications in higher frequency bands, we cannot ignore the frequency selectivity of the RRS. These two effects collectively exacerbate the beam-split issue, where different frequency components fail to converge on the user simultaneously, and finally result in a degradation of the data rate. In this paper, we investigate an RRS-based wideband near-field multi-user communication system. Unlike most existing studies on wideband communications, which consider the beam-split effect only with the near-field condition, we study the beam-split effect under the influence of both the near-field condition and the frequency selectivity of the RRS. To mitigate the beam-split effect, we propose a Delayed-RRS structure, based on which a beamforming scheme is proposed to optimize the user's data rate. Through theoretical analysis and simulation results, we analyze the influence of the RRS's frequency selectivity, demonstrate the effectiveness of the proposed beamforming scheme, and reveal the importance of jointly considering the near-field condition and the frequency selectivity of RRS.

Hybrid Near-Far Field Channel Estimation for Holographic MIMO Communications

Holographic MIMO communications, enabled by large-scale antenna arrays with quasi-continuous apertures, is a potential technology for spectrum efficiency improvement. However, the increased antenna aperture size extends the range of the Fresnel region, leading to a hybrid near-far field communication mode. The users and scatterers randomly lie in near-field and far-field zones, and thus, conventional far-field-only and near-field-only channel estimation methods may not work. To tackle this challenge, we demonstrate the existence of the power diffusion (PD) effect, which leads to a mismatch between the hybrid-field channel and existing channel estimation methods. Specifically, in far-field and near-field transform domains, the power gain of one channel path may diffuse to other positions, thus generating fake paths. This renders the conventional techniques unable to detect those real paths. We propose a PD-aware orthogonal matching pursuit algorithm to eliminate the influence of the PD effect by identifying the PD range within which paths diffuse to other positions. PD-OMP fits a general case without prior knowledge of near-field and far-field path numbers and the user's location. The computational complexity of PD-OMP and the Cramer-Rao Lower Bound for the sparse-signal-recovery-based channel estimation are also derived. Simulation results show that PD-OMP outperforms state-of-the-art hybrid-field channel estimation methods.

Channel Estimation for Holographic Communications in Hybrid Near-Far Field

To realize holographic communications, a potential technology for spectrum efficiency improvement in the future sixth-generation (6G) network, antenna arrays inlaid with numerous antenna elements will be deployed. However, the increase in antenna aperture size makes some users lie in the Fresnel region, leading to the hybrid near-field and far-field communication mode, where the conventional far-field channel estimation methods no longer work well. To tackle the above challenge, this paper considers channel estimation in a hybrid-field multipath environment, where each user and each scatterer can be in either the far-field or the near-field region. First, a joint angular-polar domain channel transform is designed to capture the hybrid-field channel's near-field and far-field features. We then analyze the power diffusion effect in the hybrid-field channel, which indicates that the power corresponding to one near-field (far-field) path component of the multipath channel may spread to far-field (near-field) paths and causes estimation error. We design a novel power-diffusion-based orthogonal matching pursuit channel estimation algorithm (PD-OMP). It can eliminate the prior knowledge requirement of path numbers in the far field and near field, which is a must in other OMP-based channel estimation algorithms. Simulation results show that PD-OMP outperforms current hybrid-field channel estimation methods.

Near-Far Field Channel Modeling for Holographic MIMO Using Expectation-Maximization Methods

Holographic Multiple-Input Multiple-Output (HMIMO), which densely integrates numerous antennas into a limited space, is anticipated to provide higher rates for future 6G wireless communications. The increase in antenna aperture size makes the near-field region enlarge, causing some users to be located in the near-field region. Thus, we are facing a hybrid near-field and far-field communication problem, where conventional far-field modeling methods may not work well. In this paper, we propose a near-far field channel model that does not presuppose whether each path is near-field or far-field, different from the existing work requiring the ratio of the number of near-field paths to that of far-field paths as prior knowledge. However, this gives rise to a new challenge for accurately modeling the channel, as conventional methods of obtaining channel model parameters are not applicable to this model. Therefore, we propose a new method, Expectation-Maximization (EM)-based Near-Far Field Channel Modeling, to obtain channel model parameters, which considers whether each path is near-field or far-field as a hidden variable, and optimizes the hidden variables and channel model parameters through an alternating iteration method. Simulation results show that our method is superior to conventional near-field and far-field algorithms in fitting the near-far field channel in terms of outage probability.

Intelligent Omni-Surfaces Aided Wireless Communications: Does the Reciprocity Hold?

Intelligent omni-surfaces (IOS) have attracted great attention recently due to its potential to achieve full-dimensional communications by simultaneously reflecting and refracting signals toward both sides of the surface. However, it still remains an open question whether the reciprocity holds between the uplink and downlink channels in the IOS-aided wireless communications. In this work, we first present a physics-compliant IOS related channel model, based on which the channel reciprocity is investigated. We then demonstrate the angle-dependent electromagnetic response of the IOS element in terms of both incident and departure angles. This serves as the key feature of IOS that drives our analytical results on beam non-reciprocity. Finally, simulation and experimental results are provided to verify our theoretical analyses.

Reconfigurable Refractive Surfaces: An Energy-Efficient Way to Holographic MIMO

Holographic Multiple Input Multiple Output (HMIMO), which integrates massive antenna elements into a compact space to achieve a spatially continuous aperture, plays an important role in future wireless networks. With numerous antenna elements, it is hard to implement the HMIMO via phased arrays due to unacceptable power consumption. To address this issue, reconfigurable refractive surface (RRS) is an energy efficient enabler of HMIMO since the surface is free of expensive phase shifters. Unlike traditional metasurfaces working as passive relays, the RRS is used as transmit antennas, where the far-field approximation does not hold anymore, urging a new performance analysis framework. In this letter, we first derive the data rate of an RRS-based single-user downlink system, and then compare its power consumption with the phased array. Simulation results verify our analysis and show that the RRS is an energy-efficient way to HMIMO.

Trajectory Optimization and Resource Allocation for OFDMA UAV Relay Networks

In this paper, we consider a single-cell multi-user orthogonal frequency division multiple access (OFDMA) network with one unmanned aerial vehicle (UAV), which works as an amplify-and-forward relay to improve the quality-of-service (QoS) of the user equipments (UEs) in the cell edge. Aiming to improve the throughput while guaranteeing the user fairness, we jointly optimize the communication mode, subchannel allocation, power allocation, and UAV trajectory, which is an NP-hard problem. To design the UAV trajectory and resource allocation efficiently, we first decompose the problem into three subproblems, i.e., mode selection and subchannel allocation, trajectory optimization, and power allocation, and then solve these subproblems iteratively. Simulation results show that the proposed algorithm outperforms the random algorithm and the cellular scheme.
