Integrated Long-range Sensing and Communications in Multi Target Scenarios using CP-OFDM

6G communication systems promise to deliver sensing capabilities by utilizing the orthogonal frequency division multiplexing (OFDM) communication signal for sensing. However, the cyclic prefix inherent in OFDM systems limits the sensing range, necessitating compensation techniques to detect small, distant targets like drones. In this paper, we show that state-of-the-art coherent compensation methods fail in scenarios involving multiple targets, resulting in an increased noise floor in the radar image. Our contributions include a novel multi target coherent compensation algorithm and a generalized signal-to-interference-and-noise ratio for multiple targets to evaluate the performance. Our algorithm achieves the same detection performance at long distances requiring only 3.6% of the radio resources compared to classical OFDM radar processing. This enables resource efficient sensing at long distances in multi target scenarios with legacy communications-only networks.

Bistatic Information Fusion for Positioning and Tracking in Integrated Sensing and Communication

The distributed nature of cellular networks is one of the main enablers for integrated sensing and communication (ISAC). For target positioning and tracking, making use of bistatic measurements is non-trivial due to their non-linear relationship with Cartesian coordinates. Most of the literature proposes geometric-based methods to determine the target's location by solving a well-defined set of equations stemming from the available measurements. The error covariance to be used for Bayesian tracking is then derived from local Taylor expansions. In our work we adaptively fuse any subset of bistatic measurements using a maximum likelihood (ML) framework, allowing to incorporate every possible combination of available measurements, i.e., transmitter angle, receiver angle and bistatic range. Moreover, our ML approach is intrinsically flexible, as it can be extended to fuse an arbitrary number of measurements by multistatic setups. Finally, we propose both a fixed and dynamic way to compute the covariance matrix for the position error to be fed to Bayesian tracking techniques, like a Kalman filter. Numerical evaluations with realistic cellular communications parameters at mmWave frequencies show that our proposal outperforms the considered baselines, achieving a location and velocity root mean square error of 0.25 m and 0.83 m/s, respectively.

Pilot-Based SFO Estimation for Bistatic Integrated Sensing and Communication

Enabling bistatic radar sensing within the context of integrated sensing and communication (ISAC) for future sixth generation mobile networks demands strict synchronization accuracy, which is particularly challenging to be achieved with over-the-air synchronization. Existing algorithms handle time and frequency offsets adequately, but provide insufficiently accurate sampling frequency offset (SFO) estimates that result in degradation of obtained radar images in the form of signal-to-noise ratio loss and migration of range and Doppler shift. This article introduces an SFO estimation algorithm named tilt inference of time offset (TITO) for orthogonal frequency-division multiplexing (OFDM)-based ISAC. Using available pilot subcarriers, TITO obtains channel impulse response estimates and extracts information on the SFO-induced delay migration to a dominant reference path with constant range, Doppler shift, and angle between transmit and receive ISAC nodes. TITO then adaptively selects the delay estimates that are only negligibly impaired by SFO-induced intersymbol interference, ultimately employing them to estimate the SFO. Assuming a scenario without a direct line-of-sight (LoS) between the aforementioned transmitting and receiving ISAC nodes, a system concept with a relay reflective intelligent surface (RIS) is used to create the aforementioned reference path is proposed. Besides a mathematical derivation of accuracy bounds, simulation and measurements at 26.2 GHz are presented to demonstrate TITO's superiority over existing methods in terms of SFO estimation accuracy and robustness.

Feasibility of Non-Line-of-Sight Integrated Sensing and Communication at mmWave

One rarely addressed direction in the context of Integrated Sensing and Communication (ISAC) is non-line-of-sight (NLOS) sensing, with the potential to enable use cases like intrusion detection and to increase the value that wireless networks can bring. However, ISAC networks impose challenges for sensing due to their communication-oriented design. For instance, time division duplex transmission creates spectral holes in time, resulting in spectral replicas in the radar image. To counteract this, we evaluate different channel state information processing strategies and discuss their tradeoffs. We further propose an ensemble of techniques to detect targets in NLOS conditions. Our approaches are validated with experiments using a millimeter wave ISAC proof of concept in a factory-like environment. The results show that target detection in NLOS is generally possible with ISAC.

Bistatic OFDM-based ISAC with Over-the-Air Synchronization: System Concept and Performance Analysis

Integrated sensing and communication (ISAC) has been defined as one goal for 6G mobile communication systems. In this context, this article introduces a bistatic ISAC system based on orthogonal frequency-division multiplexing (OFDM). While the bistatic architecture brings advantages such as not demanding full duplex operation with respect to the monostatic one, the need for synchronizing transmitter and receiver is imposed. In this context, this article introuces a bistatic ISAC signal processing framework where an incoming OFDM-based ISAC signal undergoes over-the-air synchronization based on preamble symbols and pilots. Afterwards, bistatic radar processing is performed using either only pilot subcarriers or the full OFDM frame. The latter approach requires estimation of the originally transmitted frame based on communication processing and therefore error-free communication, which can be achieved via appropriate channel coding. The performance and limitations of the introduced system based on both aforementioned approaches are assessed via an analysis of the impact of residual synchronization mismatches and data decoding failures on both communication and radar performances. Finally, the performed analyses are validated by proof-of-concept measurement results.

GAN-based Massive MIMO Channel Model Trained on Measured Data

Wireless channel models are a commonly used tool for the development of wireless telecommunication systems and standards. The currently prevailing geometry-based stochastic channel models (GSCMs) were manually specified for certain environments in a manual process requiring extensive domain knowledge, on the basis of channel measurement campaigns. By taking into account the stochastic distribution of certain channel properties like Rician k-factor, path loss or delay spread, they model the distribution of channel realizations. Instead of this manual process, a generative machine learning model like a generative adversarial network (GAN) may be used to automatically learn the distribution of channel statistics. Subsequently, the GAN's generator may be viewed as a channel model that can replace conventional stochastic or raytracer-based models. We propose a GAN architecture for a massive MIMO channel model, and train it on measurement data produced by a distributed massive MIMO channel sounder.

CRAP Part II: Clutter Removal with Continuous Acquisitions Under Phase Noise

The mitigation of clutter is an important research branch in Integrated Sensing and Communication (ISAC), one of the emerging technologies of future cellular networks. In this work, we extend our previously introduced method Clutter Removal with Acquisitions Under Phase Noise (CRAP) by means to track clutter over time. This is necessary in scenarios that require high reliability but can change dynamically, like safety applications in factory floors. To that end, exponential smoothing is leveraged to process new measurements and previous clutter information in a unique matrix using the singular value decomposition, allowing adaptation to changing environments in an efficient way.We further propose a singular value threshold based on the Marchenko-Pastur distribution to select the meaningful clutter components. Results from both simulations and measurements show that continuously updating the clutter components with new acquisitions according to our proposed algorithm Smoothed CRAP (SCRAP) enables coping with dynamic clutter environments and facilitates the detection of sensing targets.

Antenna Array Design for Mono-Static ISAC

Mono-static sensing operations in Integrated Sensing and Communications (ISAC) require joint beamforming operations between transmitter and receiver, according to all the considerations already done in the radar literature about coarray theory. In contrast to pure radar systems, ISAC requires to fulfill communications tasks and to retain the corresponding design constraints for at least one half-duplex array. This shifts the available degrees of freedom to the design of the second half-duplex array, that completes the mono-static sensing setup of the ISAC system. Therefore, it is necessary to translate the analysis from the radar literature for the design of sparse arrays to the new ISAC paradigm in order to provision such systems. Accordingly, we propose a model to evaluate the angular capabilities of an ISAC setup, constrained to the shape of the communications array and its topology requirements. Our analysis is validated by simulation experiments, confirming the value of our model in providing system designers with a tool to drastically improve the trade-off between angular capabilities for sensing and the cost of the deployed hardware. Finally, we discuss possible enhancements to the cellular standards to fully leverage the angular capabilities of such mono-static ISAC systems.

Multi-Target Localization in Multi-Static Integrated Sensing and Communication Deployments

In future wireless communication networks, existing active localization will gradually evolve into more sophisticated (passive) sensing functionalities. One main enabler for this process is the merging of information collected from the network's nodes, sensing the environment in a multi-static deployment. The current literature considers single sensing node systems and/or single target scenarios, mainly focusing on specific issues pertaining to hardware impairments or algorithmic challenges. In contrast, in this work we propose an ensemble of techniques for processing the information gathered from multiple sensing nodes, jointly observing an environment with multiple targets. A scattering model is used within a flexibly configurable framework to highlight the challenges and issues with algorithms used in this distributed sensing task. We validate our approach by supporting it with detailed link budget evaluations, considering practical millimeter-wave systems' capabilities. Our numerical evaluations are performed in an indoor scenario, sweeping a variety of parameter to analyze the KPIs sensitivity with respect to each of them. The proposed algorithms to fuse information by multiple nodes show significant gains in terms of targets' localization performance, with up to 35\% for the probability of detection, compared to the baseline with a mono-static setup.

CRAP: Clutter Removal with Acquisitions Under Phase Noise

The emergence of Integrated Sensing and Communication (ISAC) in future 6G networks comes with a variety of challenges to be solved. One of those is clutter removal, which should be applied to remove the influence of unwanted components, scattered by the environment, in the acquired sensing signal. While legacy radar systems already implement different clutter removal algorithms, ISAC requires techniques that are tailored to the envisioned use cases and the specific challenges that communications deployments bring along, like phase noise due to clock errors between transmitter and receiver. To that end, in this work we introduce Clutter Removal with Acquisitions Under Phase Noise (CRAP). We propose to vectorize the time-frequency channel acquired in a radio frame in a high-dimensional space. In an offline clutter acquisition step, singular value decomposition is used to determine the major clutter components. At runtime, the clutter is then estimated and removed by a subspace projection of the acquired radio frame onto the clutter components. Simulation results prove that CRAP offers benefits over prior art techniques robust to phase noise. In particular, our proposal does not suppress zero Doppler information, thereby enabling the detection of slow targets. Moreover, we show CRAP's real-time applicability in a millimeter-wave ISAC proof of concept, where a pedestrian is tracked in a cluttered lab environment.
