Temperature Driven Multi-modal/Single-actuated Soft Finger

Soft pneumatic fingers are of great research interest. However, their significant potential is limited as most of them can generate only one motion, mostly bending. The conventional design of soft fingers does not allow them to switch to another motion mode. In this paper, we developed a novel multi-modal and single-actuated soft finger where its motion mode is switched by changing the finger's temperature. Our soft finger is capable of switching between three distinctive motion modes: bending, twisting, and extension-in approximately five seconds. We carried out a detailed experimental study of the soft finger and evaluated its repeatability and range of motion. It exhibited repeatability of around one millimeter and a fifty percent larger range of motion than a standard bending actuator. We developed an analytical model for a fiber-reinforced soft actuator for twisting motion. This helped us relate the input pressure to the output twist radius of the twisting motion. This model was validated by experimental verification. Further, a soft robotic gripper with multiple grasp modes was developed using three actuators. This gripper can adapt to and grasp objects of a large range of size, shape, and stiffness. We showcased its grasping capabilities by successfully grasping a small berry, a large roll, and a delicate tofu cube.

Dexterous Manipulation of Deformable Objects via Pneumatic Gripping: Lifting by One End

Manipulating deformable objects in robotic cells is often costly and not widely accessible. However, the use of localized pneumatic gripping systems can enhance accessibility. Current methods that use pneumatic grippers to handle deformable objects struggle with effective lifting. This paper introduces a method for the dexterous lifting of textile deformable objects from one edge, utilizing a previously developed gripper designed for flexible and porous materials. By precisely adjusting the orientation and position of the gripper during the lifting process, we were able to significantly reduce necessary gripping force and minimize object vibration caused by airflow. This method was tested and validated on four materials with varying mass, friction, and flexibility. The proposed approach facilitates the lifting of deformable objects from a conveyor or automated line, even when only one edge is accessible for grasping. Future work will involve integrating a vision system to optimize the manipulation of deformable objects with more complex shapes.

Task-Difficulty-Aware Efficient Object Arrangement Leveraging Tossing Motions

This study explores a pick-and-toss (PT) as an alternative to pick-and-place (PP), allowing a robot to extend its range and improve task efficiency. Although PT boosts efficiency in object arrangement, the placement environment critically affects the success of tossing. To achieve accurate and efficient object arrangement, we suggest choosing between PP and PT based on task difficulty estimated from the placement environment. Our method simultaneously learns the tossing motion through self-supervised learning and the task determination policy via brute-force search. Experimental results validate the proposed method through simulations and real-world tests on various rectangular object arrangements.

Direction-Constrained Control for Efficient Physical Human-Robot Interaction under Hierarchical Tasks

This paper proposes a control method to address the physical Human-Robot Interaction (pHRI) challenge in the context of hierarchical tasks. A common approach to managing hierarchical tasks is Hierarchical Quadratic Programming (HQP), which, however, cannot be directly applied to human interaction due to its allowance of arbitrary velocity direction adjustments. To resolve this limitation, we introduce the concept of directional constraints and develop a direction-constrained optimization algorithm to handle the nonlinearities induced by these constraints. The algorithm solves two sub-problems, minimizing the error and minimizing the deviation angle, in parallel, and combines the results of the two sub-problems to produce a final optimal outcome. The mutual influence between these two sub-problems is analyzed to determine the best parameter for combination. Additionally, the velocity objective in our control framework is computed using a variable admittance controller. Traditional admittance control does not account for constraints. To address this issue, we propose a variable admittance control method to adjust control objectives dynamically. The method helps reduce the deviation between robot velocity and human intention at the constraint boundaries, thereby enhancing interaction efficiency. We evaluate the proposed method in scenarios where a human operator physically interacts with a 7-degree-of-freedom robotic arm. The results highlight the importance of incorporating directional constraints in pHRI for hierarchical tasks. Compared to existing methods, our approach generates smoother robotic trajectories during interaction while avoiding interaction delays at the constraint boundaries.

Component Selection for Craft Assembly Tasks

Inspired by traditional handmade crafts, where a person improvises assemblies based on the available objects, we formally introduce the Craft Assembly Task. It is a robotic assembly task that involves building an accurate representation of a given target object using the available objects, which do not directly correspond to its parts. In this work, we focus on selecting the subset of available objects for the final craft, when the given input is an RGB image of the target in the wild. We use a mask segmentation neural network to identify visible parts, followed by retrieving labelled template meshes. These meshes undergo pose optimization to determine the most suitable template. Then, we propose to simplify the parts of the transformed template mesh to primitive shapes like cuboids or cylinders. Finally, we design a search algorithm to find correspondences in the scene based on local and global proportions. We develop baselines for comparison that consider all possible combinations, and choose the highest scoring combination for common metrics used in foreground maps and mask accuracy. Our approach achieves comparable results to the baselines for two different scenes, and we show qualitative results for an implementation in a real-world scenario.

Functional Eigen-Grasping Using Approach Heatmaps

This work presents a framework for a robot with a multi-fingered hand to freely utilize daily tools, including functional parts like buttons and triggers. An approach heatmap is generated by selecting a functional finger, indicating optimal palm positions on the object's surface that enable the functional finger to contact the tool's functional part. Once the palm position is identified through the heatmap, achieving the functional grasp becomes a straightforward process where the fingers stably grasp the object with low-dimensional inputs using the eigengrasp. As our approach does not need human demonstrations, it can easily adapt to various sizes and designs, extending its applicability to different objects. In our approach, we use directional manipulability to obtain the approach heatmap. In addition, we add two kinds of energy functions, i.e., palm energy and functional energy functions, to realize the eigengrasp. Using this method, each robotic gripper can autonomously identify its optimal workspace for functional grasping, extending its applicability to non-anthropomorphic robotic hands. We show that several daily tools like spray, drill, and remotes can be efficiently used by not only an anthropomorphic Shadow hand but also a non-anthropomorphic Barrett hand.

Robotic Test Tube Rearrangement Using Combined Reinforcement Learning and Motion Planning

A combined task-level reinforcement learning and motion planning framework is proposed in this paper to address a multi-class in-rack test tube rearrangement problem. At the task level, the framework uses reinforcement learning to infer a sequence of swap actions while ignoring robotic motion details. At the motion level, the framework accepts the swapping action sequences inferred by task-level agents and plans the detailed robotic pick-and-place motion. The task and motion-level planning form a closed loop with the help of a condition set maintained for each rack slot, which allows the framework to perform replanning and effectively find solutions in the presence of low-level failures. Particularly for reinforcement learning, the framework leverages a distributed deep Q-learning structure with the Dueling Double Deep Q Network (D3QN) to acquire near-optimal policies and uses an A${}^\star$-based post-processing technique to amplify the collected training data. The D3QN and distributed learning help increase training efficiency. The post-processing helps complete unfinished action sequences and remove redundancy, thus making the training data more effective. We carry out both simulations and real-world studies to understand the performance of the proposed framework. The results verify the performance of the RL and post-processing and show that the closed-loop combination improves robustness. The framework is ready to incorporate various sensory feedback. The real-world studies also demonstrated the incorporation.

Many-Objective-Optimized Semi-Automated Robotic Disassembly Sequences

This study tasckles the problem of many-objective sequence optimization for semi-automated robotic disassembly operations. To this end, we employ a many-objective genetic algorithm (MaOGA) algorithm inspired by the Non-dominated Sorting Genetic Algorithm (NSGA)-III, along with robotic-disassembly-oriented constraints and objective functions derived from geometrical and robot simulations using 3-dimensional (3D) geometrical information stored in a 3D Computer-Aided Design (CAD) model of the target product. The MaOGA begins by generating a set of initial chromosomes based on a contact and connection graph (CCG), rather than random chromosomes, to avoid falling into a local minimum and yield repeatable convergence. The optimization imposes constraints on feasibility and stability as well as objective functions regarding difficulty, efficiency, prioritization, and allocability to generate a sequence that satisfies many preferred conditions under mandatory requirements for semi-automated robotic disassembly. The NSGA-III-inspired MaOGA also utilizes non-dominated sorting and niching with reference lines to further encourage steady and stable exploration and uniformly lower the overall evaluation values. Our sequence generation experiments for a complex product (36 parts) demonstrated that the proposed method can consistently produce feasible and stable sequences with a 100% success rate, bringing the multiple preferred conditions closer to the optimal solution required for semi-automated robotic disassembly operations.

In-Rack Test Tube Pose Estimation Using RGB-D Data

Accurate robotic manipulation of test tubes in biology and medical industries is becoming increasingly important to address workforce shortages and improve worker safety. The detection and localization of test tubes are essential for the robots to successfully manipulate test tubes. In this paper, we present a framework to detect and estimate poses for the in-rack test tubes using color and depth data. The methodology involves the utilization of a YOLO object detector to effectively classify and localize both the test tubes and the tube racks within the provided image data. Subsequently, the pose of the tube rack is estimated through point cloud registration techniques. During the process of estimating the poses of the test tubes, we capitalize on constraints derived from the arrangement of rack slots. By employing an optimization-based algorithm, we effectively evaluate and refine the pose of the test tubes. This strategic approach ensures the robustness of pose estimation, even when confronted with noisy and incomplete point cloud data.

A Closed-Loop Bin Picking System for Entangled Wire Harnesses using Bimanual and Dynamic Manipulation

This paper addresses the challenge of industrial bin picking using entangled wire harnesses. Wire harnesses are essential in manufacturing but poses challenges in automation due to their complex geometries and propensity for entanglement. Our previous work tackled this issue by proposing a quasi-static pulling motion to separate the entangled wire harnesses. However, it still lacks sufficiency and generalization to various shapes and structures. In this paper, we deploy a dual-arm robot that can grasp, extract and disentangle wire harnesses from dense clutter using dynamic manipulation. The robot can swing to dynamically discard the entangled objects and regrasp to adjust the undesirable grasp pose. To improve the robustness and accuracy of the system, we leverage a closed-loop framework that uses haptic feedback to detect entanglement in real-time and flexibly adjust system parameters. Our bin picking system achieves an overall success rate of 91.2% in the real-world experiments using two different types of long wire harnesses. It demonstrates the effectiveness of our system in handling various wire harnesses for industrial bin picking.
