Multi-level, Forming Free, Bulk Switching Trilayer RRAM for Neuromorphic Computing at the Edge

Resistive memory-based reconfigurable systems constructed by CMOS-RRAM integration hold great promise for low energy and high throughput neuromorphic computing. However, most RRAM technologies relying on filamentary switching suffer from variations and noise leading to computational accuracy loss, increased energy consumption, and overhead by expensive program and verify schemes. Low ON-state resistance of filamentary RRAM devices further increases the energy consumption due to high-current read and write operations, and limits the array size and parallel multiply & accumulate operations. High-forming voltages needed for filamentary RRAM are not compatible with advanced CMOS technology nodes. To address all these challenges, we developed a forming-free and bulk switching RRAM technology based on a trilayer metal-oxide stack. We systematically engineered a trilayer metal-oxide RRAM stack and investigated the switching characteristics of RRAM devices with varying thicknesses and oxygen vacancy distributions across the trilayer to achieve reliable bulk switching without any filament formation. We demonstrated bulk switching operation at megaohm regime with high current nonlinearity and programmed up to 100 levels without compliance current. We developed a neuromorphic compute-in-memory platform based on trilayer bulk RRAM crossbars by combining energy-efficient switched-capacitor voltage sensing circuits with differential encoding of weights to experimentally demonstrate high-accuracy matrix-vector multiplication. We showcased the computational capability of bulk RRAM crossbars by implementing a spiking neural network model for an autonomous navigation/racing task. Our work addresses challenges posed by existing RRAM technologies and paves the way for neuromorphic computing at the edge under strict size, weight, and power constraints.

Device and System Level Design Considerations for Analog-Non-Volatile-Memory Based Neuromorphic Architectures

This paper gives an overview of recent progress in the brain inspired computing field with a focus on implementation using emerging memories as electronic synapses. Design considerations and challenges such as requirements and design targets on multilevel states, device variability, programming energy, array-level connectivity, fan-in/fanout, wire energy, and IR drop are presented. Wires are increasingly important in design decisions, especially for large systems, and cycle-to-cycle variations have large impact on learning performance.

Brain-like associative learning using a nanoscale non-volatile phase change synaptic device array

Recent advances in neuroscience together with nanoscale electronic device technology have resulted in huge interests in realizing brain-like computing hardwares using emerging nanoscale memory devices as synaptic elements. Although there has been experimental work that demonstrated the operation of nanoscale synaptic element at the single device level, network level studies have been limited to simulations. In this work, we demonstrate, using experiments, array level associative learning using phase change synaptic devices connected in a grid like configuration similar to the organization of the biological brain. Implementing Hebbian learning with phase change memory cells, the synaptic grid was able to store presented patterns and recall missing patterns in an associative brain-like fashion. We found that the system is robust to device variations, and large variations in cell resistance states can be accommodated by increasing the number of training epochs. We illustrated the tradeoff between variation tolerance of the network and the overall energy consumption, and found that energy consumption is decreased significantly for lower variation tolerance.

Experimental Demonstration of Array-level Learning with Phase Change Synaptic Devices

The computational performance of the biological brain has long attracted significant interest and has led to inspirations in operating principles, algorithms, and architectures for computing and signal processing. In this work, we focus on hardware implementation of brain-like learning in a brain-inspired architecture. We demonstrate, in hardware, that 2-D crossbar arrays of phase change synaptic devices can achieve associative learning and perform pattern recognition. Device and array-level studies using an experimental 10x10 array of phase change synaptic devices have shown that pattern recognition is robust against synaptic resistance variations and large variations can be tolerated by increasing the number of training iterations. Our measurements show that increase in initial variation from 9 % to 60 % causes required training iterations to increase from 1 to 11.
