Shadow-Oriented Tracking Method for Multi-Target Tracking in Video-SAR

This work focuses on multi-target tracking in Video synthetic aperture radar. Specifically, we refer to tracking based on targets' shadows. Current methods have limited accuracy as they fail to consider shadows' characteristics and surroundings fully. Shades are low-scattering and varied, resulting in missed tracking. Surroundings can cause interferences, resulting in false tracking. To solve these, we propose a shadow-oriented multi-target tracking method (SOTrack). To avoid false tracking, a pre-processing module is proposed to enhance shadows from surroundings, thus reducing their interferences. To avoid missed tracking, a detection method based on deep learning is designed to thoroughly learn shadows' features, thus increasing the accurate estimation. And further, a recall module is designed to recall missed shadows. We conduct experiments on measured data. Results demonstrate that, compared with other methods, SOTrack achieves much higher performance in tracking accuracy-18.4%. And ablation study confirms the effectiveness of the proposed modules.

A Model-data-driven Network Embedding Multidimensional Features for Tomographic SAR Imaging

Deep learning (DL)-based tomographic SAR imaging algorithms are gradually being studied. Typically, they use an unfolding network to mimic the iterative calculation of the classical compressive sensing (CS)-based methods and process each range-azimuth unit individually. However, only one-dimensional features are effectively utilized in this way. The correlation between adjacent resolution units is ignored directly. To address that, we propose a new model-data-driven network to achieve tomoSAR imaging based on multi-dimensional features. Guided by the deep unfolding methodology, a two-dimensional deep unfolding imaging network is constructed. On the basis of it, we add two 2D processing modules, both convolutional encoder-decoder structures, to enhance multi-dimensional features of the imaging scene effectively. Meanwhile, to train the proposed multifeature-based imaging network, we construct a tomoSAR simulation dataset consisting entirely of simulation data of buildings. Experiments verify the effectiveness of the model. Compared with the conventional CS-based FISTA method and DL-based gamma-Net method, the result of our proposed method has better performance on completeness while having decent imaging accuracy.

Solving 3D Radar Imaging Inverse Problems with a Multi-cognition Task-oriented Framework

This work focuses on 3D Radar imaging inverse problems. Current methods obtain undifferentiated results that suffer task-depended information retrieval loss and thus don't meet the task's specific demands well. For example, biased scattering energy may be acceptable for screen imaging but not for scattering diagnosis. To address this issue, we propose a new task-oriented imaging framework. The imaging principle is task-oriented through an analysis phase to obtain task's demands. The imaging model is multi-cognition regularized to embed and fulfill demands. The imaging method is designed to be general-ized, where couplings between cognitions are decoupled and solved individually with approximation and variable-splitting techniques. Tasks include scattering diagnosis, person screen imaging, and parcel screening imaging are given as examples. Experiments on data from two systems indicate that the pro-posed framework outperforms the current ones in task-depended information retrieval.

Near-filed SAR Image Restoration with Deep Learning Inverse Technique: A Preliminary Study

Benefiting from a relatively larger aperture's angle, and in combination with a wide transmitting bandwidth, near-field synthetic aperture radar (SAR) provides a high-resolution image of a target's scattering distribution-hot spots. Meanwhile, imaging result suffers inevitable degradation from sidelobes, clutters, and noises, hindering the information retrieval of the target. To restore the image, current methods make simplified assumptions; for example, the point spread function (PSF) is spatially consistent, the target consists of sparse point scatters, etc. Thus, they achieve limited restoration performance in terms of the target's shape, especially for complex targets. To address these issues, a preliminary study is conducted on restoration with the recent promising deep learning inverse technique in this work. We reformulate the degradation model into a spatially variable complex-convolution model, where the near-field SAR's system response is considered. Adhering to it, a model-based deep learning network is designed to restore the image. A simulated degraded image dataset from multiple complex target models is constructed to validate the network. All the images are formulated using the electromagnetic simulation tool. Experiments on the dataset reveal their effectiveness. Compared with current methods, superior performance is achieved regarding the target's shape and energy estimation.

3D Super-Resolution Imaging Method for Distributed Millimeter-wave Automotive Radar System

Millimeter-wave (mmW) radar is widely applied to advanced autopilot assistance systems. However, its small antenna aperture causes a low imaging resolution. In this paper, a new distributed mmW radar system is designed to solve this problem. It forms a large sparse virtual planar array to enlarge the aperture, using multiple-input and multiple-output (MIMO) processing. However, in this system, traditional imaging methods cannot apply to the sparse array. Therefore, we also propose a 3D super-resolution imaging method specifically for this system in this paper. The proposed method consists of three steps: (1) using range FFT to get range imaging, (2) using 2D adaptive diagonal loading iterative adaptive approach (ADL-IAA) to acquire 2D super-resolution imaging, which can satisfy this sparsity under single-measurement, (3) using constant false alarm (CFAR) processing to gain final 3D super-resolution imaging. The simulation results show the proposed method can significantly improve imaging resolution under the sparse array and single-measurement.

AETomo-Net: A Novel Deep Learning Network for Tomographic SAR Imaging Based on Multi-dimensional Features

Tomographic synthetic aperture radar (TomoSAR) imaging algorithms based on deep learning can effectively reduce computational costs. The idea of existing researches is to reconstruct the elevation for each range-azimuth cell in one-dimensional using a deep-unfolding network. However, since these methods are commonly sensitive to signal sparsity level, it usually leads to some drawbacks like continuous surface fractures, too many outliers, \textit{et al}. To address them, in this paper, a novel imaging network (AETomo-Net) based on multi-dimensional features is proposed. By adding a U-Net-like structure, AETomo-Net performs reconstruction by each azimuth-elevation slice and adds 2D features extraction and fusion capabilities to the original deep unrolling network. In this way, each azimuth-elevation slice can be reconstructed with richer features and the quality of the imaging results will be improved. Experiments show that the proposed method can effectively solve the above defects while ensuring imaging accuracy and computation speed compared with the traditional ISTA-based method and CV-LISTA.

Constant-Time-Delay Interferences In Near-Field SAR: Analysis And Suppression In Image Domain

Inevitable interferences exist for the SAR system, adversely affecting the imaging quality. However, current analysis and suppression methods mainly focus on the far-field situation. Due to different sources and characteristics of interferences, they are not applicable in the near field. To bridge this gap, in the first time, analysis and the suppression method of interferences in near-field SAR are presented in this work. We find that echoes from both the nadir points and the antenna coupling are the main causes, which have the constant-time-delay feature. To characterize this, we further establish an analytical model. It reveals that their patterns in 1D, 2D and 3D imaging results are all comb-like, while those of targets are point-like. Utilizing these features, a suppression method in image domain is proposed based on low-rank reconstruction. Measured data are used to validate the correctness of our analysis and the effectiveness of the suppression method.

Near-Field SAR Image Restoration Based On Two Dimensional Spatial-Variant Deconvolution

Images of near-field SAR contains spatial-variant sidelobes and clutter, subduing the image quality. Current image restoration methods are only suitable for small observation angle, due to their assumption of 2D spatial-invariant degradation operation. This limits its potential for large-scale objects imaging, like the aircraft. To ease this restriction, in this work an image restoration method based on the 2D spatial-variant deconvolution is proposed. First, the image degradation is seen as a complex convolution process with 2D spatial-variant operations. Then, to restore the image, the process of deconvolution is performed by cyclic coordinate descent algorithm. Experiments on simulation and measured data validate the effectiveness and superiority of the proposed method. Compared with current methods, higher precision estimation of the targets' amplitude and position is obtained.

Complicated Background Suppression of ViSAR Image For Moving Target Shadow Detection

The existing Video Synthetic Aperture Radar (ViSAR) moving target shadow detection methods based on deep neural networks mostly generate numerous false alarms and missing detections, because of the foreground-background indistinguishability. To solve this problem, we propose a method to suppress complicated background of ViSAR for moving target detection. In this work, the proposed method is used to suppress background; then, we use several target detection networks to detect the moving target shadows. The experimental result shows that the proposed method can effectively suppress the interference of complicated back-ground information and improve the accuracy of moving target shadow detection in ViSAR. The existing Video Synthetic Aperture Radar (ViSAR) moving target shadow detection methods based on deep neural networks mostly generate numerous false alarms and missing detections, because of the foreground-background indistinguishability. To solve this problem, we propose a method to suppress complicated background of ViSAR for moving target detection. In this work, the proposed method is used to suppress background; then, we use several target detection networks to detect the moving target shadows. The experimental result shows that the proposed method can effectively suppress the interference of complicated back-ground information and improve the accuracy of moving target shadow detection in ViSAR.

Sar Ship Detection based on Swin Transformer and Feature Enhancement Feature Pyramid Network

With the booming of Convolutional Neural Networks (CNNs), CNNs such as VGG-16 and ResNet-50 widely serve as backbone in SAR ship detection. However, CNN based backbone is hard to model long-range dependencies, and causes the lack of enough high-quality semantic information in feature maps of shallow layers, which leads to poor detection performance in complicated background and small-sized ships cases. To address these problems, we propose a SAR ship detection method based on Swin Transformer and Feature Enhancement Feature Pyramid Network (FEFPN). Swin Transformer serves as backbone to model long-range dependencies and generates hierarchical features maps. FEFPN is proposed to further improve the quality of feature maps by gradually enhancing the semantic information of feature maps at all levels, especially feature maps in shallow layers. Experiments conducted on SAR ship detection dataset (SSDD) reveal the advantage of our proposed methods.
