Increasing the scalability of graph convolution for FPGA-implemented event-based vision

Event cameras are becoming increasingly popular as an alternative to traditional frame-based vision sensors, especially in mobile robotics. Taking full advantage of their high temporal resolution, high dynamic range, low power consumption and sparsity of event data, which only reflects changes in the observed scene, requires both an efficient algorithm and a specialised hardware platform. A recent trend involves using Graph Convolutional Neural Networks (GCNNs) implemented on a heterogeneous SoC FPGA. In this paper we focus on optimising hardware modules for graph convolution to allow flexible selection of the FPGA resource (BlockRAM, DSP and LUT) for their implementation. We propose a ''two-step convolution'' approach that utilises additional BRAM buffers in order to reduce up to 94% of LUT usage for multiplications. This method significantly improves the scalability of GCNNs, enabling the deployment of models with more layers, larger graphs sizes and their application for more dynamic scenarios.

PowerYOLO: Mixed Precision Model for Hardware Efficient Object Detection with Event Data

The performance of object detection systems in automotive solutions must be as high as possible, with minimal response time and, due to the often battery-powered operation, low energy consumption. When designing such solutions, we therefore face challenges typical for embedded vision systems: the problem of fitting algorithms of high memory and computational complexity into small low-power devices. In this paper we propose PowerYOLO - a mixed precision solution, which targets three essential elements of such application. First, we propose a system based on a Dynamic Vision Sensor (DVS), a novel sensor, that offers low power requirements and operates well in conditions with variable illumination. It is these features that may make event cameras a preferential choice over frame cameras in some applications. Second, to ensure high accuracy and low memory and computational complexity, we propose to use 4-bit width Powers-of-Two (PoT) quantisation for convolution weights of the YOLO detector, with all other parameters quantised linearly. Finally, we embrace from PoT scheme and replace multiplication with bit-shifting to increase the efficiency of hardware acceleration of such solution, with a special convolution-batch normalisation fusion scheme. The use of specific sensor with PoT quantisation and special batch normalisation fusion leads to a unique system with almost 8x reduction in memory complexity and vast computational simplifications, with relation to a standard approach. This efficient system achieves high accuracy of mAP 0.301 on the GEN1 DVS dataset, marking the new state-of-the-art for such compressed model.

Event-based vision on FPGAs -- a survey

In recent years there has been a growing interest in event cameras, i.e. vision sensors that record changes in illumination independently for each pixel. This type of operation ensures that acquisition is possible in very adverse lighting conditions, both in low light and high dynamic range, and reduces average power consumption. In addition, the independent operation of each pixel results in low latency, which is desirable for robotic solutions. Nowadays, Field Programmable Gate Arrays (FPGAs), along with general-purpose processors (GPPs/CPUs) and programmable graphics processing units (GPUs), are popular architectures for implementing and accelerating computing tasks. In particular, their usefulness in the embedded vision domain has been repeatedly demonstrated over the past 30 years, where they have enabled fast data processing (even in real-time) and energy efficiency. Hence, the combination of event cameras and reconfigurable devices seems to be a good solution, especially in the context of energy-efficient real-time embedded systems. This paper gives an overview of the most important works, where FPGAs have been used in different contexts to process event data. It covers applications in the following areas: filtering, stereovision, optical flow, acceleration of AI-based algorithms (including spiking neural networks) for object classification, detection and tracking, and applications in robotics and inspection systems. Current trends and challenges for such systems are also discussed.

Embedded Graph Convolutional Networks for Real-Time Event Data Processing on SoC FPGAs

The utilisation of event cameras represents an important and swiftly evolving trend aimed at addressing the constraints of traditional video systems. Particularly within the automotive domain, these cameras find significant relevance for their integration into embedded real-time systems due to lower latency and energy consumption. One effective approach to ensure the necessary throughput and latency for event processing systems is through the utilisation of graph convolutional networks (GCNs). In this study, we introduce a series of hardware-aware optimisations tailored for PointNet++, a GCN architecture designed for point cloud processing. The proposed techniques result in more than a 100-fold reduction in model size compared to Asynchronous Event-based GNN (AEGNN), one of the most recent works in the field, with a relatively small decrease in accuracy (2.3% for N-Caltech101 classification, 1.7% for N-Cars classification), thus following the TinyML trend. Based on software research, we designed a custom EFGCN (Event-Based FPGA-accelerated Graph Convolutional Network) and we implemented it on ZCU104 SoC FPGA platform, achieving a throughput of 13.3 million events per second (MEPS) and real-time partially asynchronous processing with a latency of 4.47 ms. We also address the scalability of the proposed hardware model to improve the obtained accuracy score. To the best of our knowledge, this study marks the first endeavour in accelerating PointNet++ networks on SoC FPGAs, as well as the first hardware architecture exploration of graph convolutional networks implementation for real-time continuous event data processing. We publish both software and hardware source code in an open repository: https://github.com/vision-agh/*** (will be published upon acceptance).

Optimising Graph Representation for Hardware Implementation of Graph Convolutional Networks for Event-based Vision

Event-based vision is an emerging research field involving processing data generated by Dynamic Vision Sensors (neuromorphic cameras). One of the latest proposals in this area are Graph Convolutional Networks (GCNs), which allow to process events in its original sparse form while maintaining high detection and classification performance. In this paper, we present the hardware implementation of a~graph generation process from an event camera data stream, taking into account both the advantages and limitations of FPGAs. We propose various ways to simplify the graph representation and use scaling and quantisation of values. We consider both undirected and directed graphs that enable the use of PointNet convolution. The results obtained show that by appropriately modifying the graph representation, it is possible to create a~hardware module for graph generation. Moreover, the proposed modifications have no significant impact on object detection performance, only 0.08% mAP less for the base model and the N-Caltech data set.Finally, we describe the proposed hardware architecture of the graph generation module.

Memory-Efficient Graph Convolutional Networks for Object Classification and Detection with Event Cameras

Recent advances in event camera research emphasize processing data in its original sparse form, which allows the use of its unique features such as high temporal resolution, high dynamic range, low latency, and resistance to image blur. One promising approach for analyzing event data is through graph convolutional networks (GCNs). However, current research in this domain primarily focuses on optimizing computational costs, neglecting the associated memory costs. In this paper, we consider both factors together in order to achieve satisfying results and relatively low model complexity. For this purpose, we performed a comparative analysis of different graph convolution operations, considering factors such as execution time, the number of trainable model parameters, data format requirements, and training outcomes. Our results show a 450-fold reduction in the number of parameters for the feature extraction module and a 4.5-fold reduction in the size of the data representation while maintaining a classification accuracy of 52.3%, which is 6.3% higher compared to the operation used in state-of-the-art approaches. To further evaluate performance, we implemented the object detection architecture and evaluated its performance on the N-Caltech101 dataset. The results showed an accuracy of 53.7 % mAP@0.5 and reached an execution rate of 82 graphs per second.

LiDAR-based drone navigation with reinforcement learning

Reinforcement learning is of increasing importance in the field of robot control and simulation plays a~key role in this process. In the unmanned aerial vehicles (UAVs, drones), there is also an increase in the number of published scientific papers involving this approach. In this work, an autonomous drone control system was prepared to fly forward (according to its coordinates system) and pass the trees encountered in the forest based on the data from a rotating LiDAR sensor. The Proximal Policy Optimization (PPO) algorithm, an example of reinforcement learning (RL), was used to prepare it. A custom simulator in the Python language was developed for this purpose. The Gazebo environment, integrated with the Robot Operating System (ROS), was also used to test the resulting control algorithm. Finally, the prepared solution was implemented in the Nvidia Jetson Nano eGPU and verified in the real tests scenarios. During them, the drone successfully completed the set task and was able to repeatably avoid trees and fly through the forest.

High-definition event frame generation using SoC FPGA devices

In this paper we have addressed the implementation of the accumulation and projection of high-resolution event data stream (HD -1280 x 720 pixels) onto the image plane in FPGA devices. The results confirm the feasibility of this approach, but there are a number of challenges, limitations and trade-offs to be considered. The required hardware resources of selected data representations, such as binary frame, event frame, exponentially decaying time surface and event frequency, were compared with those available on several popular platforms from AMD Xilinx. The resulting event frames can be used for typical vision algorithms, such as object classification and detection, using both classical and deep neural network methods.

Implementation of a perception system for autonomous vehicles using a detection-segmentation network in SoC FPGA

Perception and control systems for autonomous vehicles are an active area of scientific and industrial research. These solutions should be characterised by high efficiency in recognising obstacles and other environmental elements in different road conditions, real-time capability, and energy efficiency. Achieving such functionality requires an appropriate algorithm and a suitable computing platform. In this paper, we have used the MultiTaskV3 detection-segmentation network as the basis for a perception system that can perform both functionalities within a single architecture. It was appropriately trained, quantised, and implemented on the AMD Xilinx Kria KV260 Vision AI embedded platform. By using this device, it was possible to parallelise and accelerate the computations. Furthermore, the whole system consumes relatively little power compared to a CPU-based implementation (an average of 5 watts, compared to the minimum of 55 watts for weaker CPUs, and the small size (119mm x 140mm x 36mm) of the platform allows it to be used in devices where the amount of space available is limited. It also achieves an accuracy higher than 97% of the mAP (mean average precision) for object detection and above 90% of the mIoU (mean intersection over union) for image segmentation. The article also details the design of the Mecanum wheel vehicle, which was used to test the proposed solution in a mock-up city.

Comparative study of subset selection methods for rapid prototyping of 3D object detection algorithms

Object detection in 3D is a crucial aspect in the context of autonomous vehicles and drones. However, prototyping detection algorithms is time-consuming and costly in terms of energy and environmental impact. To address these challenges, one can check the effectiveness of different models by training on a subset of the original training set. In this paper, we present a comparison of three algorithms for selecting such a subset - random sampling, random per class sampling, and our proposed MONSPeC (Maximum Object Number Sampling per Class). We provide empirical evidence for the superior effectiveness of random per class sampling and MONSPeC over basic random sampling. By replacing random sampling with one of the more efficient algorithms, the results obtained on the subset are more likely to transfer to the results on the entire dataset. The code is available at: https://github.com/vision-agh/monspec.
