Increasing the scalability of graph convolution for FPGA-implemented event-based vision

Event cameras are becoming increasingly popular as an alternative to traditional frame-based vision sensors, especially in mobile robotics. Taking full advantage of their high temporal resolution, high dynamic range, low power consumption and sparsity of event data, which only reflects changes in the observed scene, requires both an efficient algorithm and a specialised hardware platform. A recent trend involves using Graph Convolutional Neural Networks (GCNNs) implemented on a heterogeneous SoC FPGA. In this paper we focus on optimising hardware modules for graph convolution to allow flexible selection of the FPGA resource (BlockRAM, DSP and LUT) for their implementation. We propose a ''two-step convolution'' approach that utilises additional BRAM buffers in order to reduce up to 94% of LUT usage for multiplications. This method significantly improves the scalability of GCNNs, enabling the deployment of models with more layers, larger graphs sizes and their application for more dynamic scenarios.

Embedded Graph Convolutional Networks for Real-Time Event Data Processing on SoC FPGAs

The utilisation of event cameras represents an important and swiftly evolving trend aimed at addressing the constraints of traditional video systems. Particularly within the automotive domain, these cameras find significant relevance for their integration into embedded real-time systems due to lower latency and energy consumption. One effective approach to ensure the necessary throughput and latency for event processing systems is through the utilisation of graph convolutional networks (GCNs). In this study, we introduce a series of hardware-aware optimisations tailored for PointNet++, a GCN architecture designed for point cloud processing. The proposed techniques result in more than a 100-fold reduction in model size compared to Asynchronous Event-based GNN (AEGNN), one of the most recent works in the field, with a relatively small decrease in accuracy (2.3% for N-Caltech101 classification, 1.7% for N-Cars classification), thus following the TinyML trend. Based on software research, we designed a custom EFGCN (Event-Based FPGA-accelerated Graph Convolutional Network) and we implemented it on ZCU104 SoC FPGA platform, achieving a throughput of 13.3 million events per second (MEPS) and real-time partially asynchronous processing with a latency of 4.47 ms. We also address the scalability of the proposed hardware model to improve the obtained accuracy score. To the best of our knowledge, this study marks the first endeavour in accelerating PointNet++ networks on SoC FPGAs, as well as the first hardware architecture exploration of graph convolutional networks implementation for real-time continuous event data processing. We publish both software and hardware source code in an open repository: https://github.com/vision-agh/*** (will be published upon acceptance).

Optimising Graph Representation for Hardware Implementation of Graph Convolutional Networks for Event-based Vision

Event-based vision is an emerging research field involving processing data generated by Dynamic Vision Sensors (neuromorphic cameras). One of the latest proposals in this area are Graph Convolutional Networks (GCNs), which allow to process events in its original sparse form while maintaining high detection and classification performance. In this paper, we present the hardware implementation of a~graph generation process from an event camera data stream, taking into account both the advantages and limitations of FPGAs. We propose various ways to simplify the graph representation and use scaling and quantisation of values. We consider both undirected and directed graphs that enable the use of PointNet convolution. The results obtained show that by appropriately modifying the graph representation, it is possible to create a~hardware module for graph generation. Moreover, the proposed modifications have no significant impact on object detection performance, only 0.08% mAP less for the base model and the N-Caltech data set.Finally, we describe the proposed hardware architecture of the graph generation module.

Pedestrian detection with high-resolution event camera

Despite the dynamic development of computer vision algorithms, the implementation of perception and control systems for autonomous vehicles such as drones and self-driving cars still poses many challenges. A video stream captured by traditional cameras is often prone to problems such as motion blur or degraded image quality due to challenging lighting conditions. In addition, the frame rate - typically 30 or 60 frames per second - can be a limiting factor in certain scenarios. Event cameras (DVS -- Dynamic Vision Sensor) are a potentially interesting technology to address the above mentioned problems. In this paper, we compare two methods of processing event data by means of deep learning for the task of pedestrian detection. We used a representation in the form of video frames, convolutional neural networks and asynchronous sparse convolutional neural networks. The results obtained illustrate the potential of event cameras and allow the evaluation of the accuracy and efficiency of the methods used for high-resolution (1280 x 720 pixels) footage.

Traffic Sign Detection With Event Cameras and DCNN

In recent years, event cameras (DVS - Dynamic Vision Sensors) have been used in vision systems as an alternative or supplement to traditional cameras. They are characterised by high dynamic range, high temporal resolution, low latency, and reliable performance in limited lighting conditions -- parameters that are particularly important in the context of advanced driver assistance systems (ADAS) and self-driving cars. In this work, we test whether these rather novel sensors can be applied to the popular task of traffic sign detection. To this end, we analyse different representations of the event data: event frame, event frequency, and the exponentially decaying time surface, and apply video frame reconstruction using a deep neural network called FireNet. We use the deep convolutional neural network YOLOv4 as a detector. For particular representations, we obtain a detection accuracy in the range of 86.9-88.9% mAP@0.5. The use of a fusion of the considered representations allows us to obtain a detector with higher accuracy of 89.9% mAP@0.5. In comparison, the detector for the frames reconstructed with FireNet is characterised by an accuracy of 72.67% mAP@0.5. The results obtained illustrate the potential of event cameras in automotive applications, either as standalone sensors or in close cooperation with typical frame-based cameras.

Training dataset generation for bridge game registration

This paper presents a method for automatic generation of a training dataset for a deep convolutional neural network used for playing card detection. The solution allows to skip the time-consuming processes of manual image collecting and labelling recognised objects. The YOLOv4 network trained on the generated dataset achieved an efficiency of 99.8% in the cards detection task. The proposed method is a part of a project that aims to automate the process of broadcasting duplicate bridge competitions using a vision system and neural networks.
