PATO: Producibility-Aware Topology Optimization using Deep Learning for Metal Additive Manufacturing

In this paper, we propose PATO-a producibility-aware topology optimization (TO) framework to help efficiently explore the design space of components fabricated using metal additive manufacturing (AM), while ensuring manufacturability with respect to cracking. Specifically, parts fabricated through Laser Powder Bed Fusion are prone to defects such as warpage or cracking due to high residual stress values generated from the steep thermal gradients produced during the build process. Maturing the design for such parts and planning their fabrication can span months to years, often involving multiple handoffs between design and manufacturing engineers. PATO is based on the a priori discovery of crack-free designs, so that the optimized part can be built defect-free at the outset. To ensure that the design is crack free during optimization, producibility is explicitly encoded within the standard formulation of TO, using a crack index. Multiple crack indices are explored and using experimental validation, maximum shear strain index (MSSI) is shown to be an accurate crack index. Simulating the build process is a coupled, multi-physics computation and incorporating it in the TO loop can be computationally prohibitive. We leverage the current advances in deep convolutional neural networks and present a high-fidelity surrogate model based on an Attention-based U-Net architecture to predict the MSSI values as a spatially varying field over the part's domain. Further, we employ automatic differentiation to directly compute the gradient of maximum MSSI with respect to the input design variables and augment it with the performance-based sensitivity field to optimize the design while considering the trade-off between weight, manufacturability, and functionality. We demonstrate the effectiveness of the proposed method through benchmark studies in 3D as well as experimental validation.

Exploring Feasible Design Spaces for Heterogeneous Constraints

We demonstrate an approach of exploring design spaces to simultaneously satisfy kinematics- and physics-based requirements. We present a classification of constraints and solvers to enable postponing optimization as far down the design workflow as possible. The solvers are organized into two broad classes of design space 'pruning' and 'exploration' by considering the types of constraints they can satisfy. We show that pointwise constraints define feasible design subspaces that can be represented and computed as first-class entities by their maximal feasible elements. The design space is pruned upfront by intersecting maximal elements, without premature optimization. To solve for other constraints, we apply topology optimization (TO), starting from the pruned feasible space. The optimization is steered by a topological sensitivity field (TSF) that measures the global changes in violation of constraints with respect to local topological punctures. The TSF for global objective functions is augmented with TSF for global constraints, and penalized/filtered to incorporate local constraints, including set constraints converted to differentiable (in)equality constraints. We demonstrate application of the proposed workflow to nontrivial examples in design and manufacturing. Among other examples, we show how to explore pruned design spaces via TO to simultaneously satisfy physics-based constraints (e.g., minimize compliance and mass) as well as kinematics-based constraints (e.g., maximize accessibility for machining).

Automatic Support Removal for Additive Manufacturing Post Processing

An additive manufacturing (AM) process often produces a {\it near-net} shape that closely conforms to the intended design to be manufactured. It sometimes contains additional support structure (also called scaffolding), which has to be removed in post-processing. We describe an approach to automatically generate process plans for support removal using a multi-axis machining instrument. The goal is to fracture the contact regions between each support component and the part, and to do it in the most cost-effective order while avoiding collisions with evolving near-net shape, including the remaining support components. A recursive algorithm identifies a maximal collection of support components whose connection regions to the part are accessible as well as the orientations at which they can be removed at a given round. For every such region, the accessible orientations appear as a 'fiber' in the collision-free space of the evolving near-net shape and the tool assembly. To order the removal of accessible supports, the algorithm constructs a search graph whose edges are weighted by the Riemannian distance between the fibers. The least expensive process plan is obtained by solving a traveling salesman problem (TSP) over the search graph. The sequence of configurations obtained by solving TSP is used as the input to a motion planner that finds collision free paths to visit all accessible features. The resulting part without the support structure can then be finished using traditional machining to produce the intended design. The effectiveness of the method is demonstrated through benchmark examples in 3D.

Automated Process Planning for Turning: A Feature-Free Approach

Turning is the most commonly available and least expensive machining operation, in terms of both machine-hour rates and tool insert prices. A practical CNC process planner has to maximize the utilization of turning, not only to attain precision requirements for turnable surfaces, but also to minimize the machining cost, while non-turnable features can be left for other processes such as milling. Most existing methods rely on separation of surface features and lack guarantees when analyzing complex parts with interacting features. In a previous study, we demonstrated successful implementation of a feature-free milling process planner based on configuration space methods used for spatial reasoning and AI search for planning. This paper extends the feature-free method to include turning process planning. It opens up the opportunity for seamless integration of turning actions into a mill-turn process planner that can handle arbitrarily complex shapes with or without a priori knowledge of feature semantics.

Automated Process Planning for Hybrid Manufacturing

Hybrid manufacturing (HM) technologies combine additive and subtractive manufacturing (AM/SM) capabilities, leveraging AM's strengths in fabricating complex geometries and SM's precision and quality to produce finished parts. We present a systematic approach to automated computer-aided process planning (CAPP) for HM that can identify non-trivial, qualitatively distinct, and cost-optimal combinations of AM/SM modalities. A multimodal HM process plan is represented by a finite Boolean expression of AM and SM manufacturing primitives, such that the expression evaluates to an 'as-manufactured' artifact. We show that primitives that respect spatial constraints such as accessibility and collision avoidance may be constructed by solving inverse configuration space problems on the 'as-designed' artifact and manufacturing instruments. The primitives generate a finite Boolean algebra (FBA) that enumerates the entire search space for planning. The FBA's canonical intersection terms (i.e., 'atoms') provide the complete domain decomposition to reframe manufacturability analysis and process planning into purely symbolic reasoning, once a subcollection of atoms is found to be interchangeable with the design target. The approach subsumes unimodal (all-AM or all-SM) process planning as special cases. We demonstrate the practical potency of our framework and its computational efficiency when applied to process planning of complex 3D parts with dramatically different AM and SM instruments.

Recognizing Abnormal Heart Sounds Using Deep Learning

The work presented here applies deep learning to the task of automated cardiac auscultation, i.e. recognizing abnormalities in heart sounds. We describe an automated heart sound classification algorithm that combines the use of time-frequency heat map representations with a deep convolutional neural network (CNN). Given the cost-sensitive nature of misclassification, our CNN architecture is trained using a modified loss function that directly optimizes the trade-off between sensitivity and specificity. We evaluated our algorithm at the 2016 PhysioNet Computing in Cardiology challenge where the objective was to accurately classify normal and abnormal heart sounds from single, short, potentially noisy recordings. Our entry to the challenge achieved a final specificity of 0.95, sensitivity of 0.73 and overall score of 0.84. We achieved the greatest specificity score out of all challenge entries and, using just a single CNN, our algorithm differed in overall score by only 0.02 compared to the top place finisher, which used an ensemble approach.
