Reducing ADC Front-end Costs During Training of On-sensor Printed Multilayer Perceptrons

Printed electronics technology offers a cost-effectiveand fully-customizable solution to computational needs beyondthe capabilities of traditional silicon technologies, offering ad-vantages such as on-demand manufacturing and conformal, low-cost hardware. However, the low-resolution fabrication of printedelectronics, which results in large feature sizes, poses a challengefor integrating complex designs like those of machine learn-ing (ML) classification systems. Current literature optimizes onlythe Multilayer Perceptron (MLP) circuit within the classificationsystem, while the cost of analog-to-digital converters (ADCs)is overlooked. Printed applications frequently require on-sensorprocessing, yet while the digital classifier has been extensivelyoptimized, the analog-to-digital interfacing, specifically the ADCs,dominates the total area and energy consumption. In this work,we target digital printed MLP classifiers and we propose thedesign of customized ADCs per MLP's input which involvesminimizing the distinct represented numbers for each input,simplifying thus the ADC's circuitry. Incorporating this ADCoptimization in the MLP training, enables eliminating ADC levelsand the respective comparators, while still maintaining highclassification accuracy. Our approach achieves 11.2x lower ADCarea for less than 5% accuracy drop across varying MLPs.

Design and In-training Optimization of Binary Search ADC for Flexible Classifiers

Flexible Electronics (FE) offer distinct advantages, including mechanical flexibility and low process temperatures, enabling extremely low-cost production. To address the demands of applications such as smart sensors and wearables, flexible devices must be small and operate at low supply voltages. Additionally, target applications often require classifiers to operate directly on analog sensory input, necessitating the use of Analog to Digital Converters (ADCs) to process the sensory data. However, ADCs present serious challenges, particularly in terms of high area and power consumption, especially when considering stringent area and energy budget. In this work, we target common classifiers in this domain such as MLPs and SVMs and present a holistic approach to mitigate the elevated overhead of analog to digital interfacing in FE. First, we propose a novel design for Binary Search ADC that reduces area overhead 2X compared with the state-of-the-art Binary design and up to 5.4X compared with Flash ADC. Next, we present an in-training ADC optimization in which we keep the bare-minimum representations required and simplifying ADCs by removing unnecessary components. Our in-training optimization further reduces on average the area in terms of transistor count of the required ADCs by 5X for less than 1% accuracy loss.

TransAxx: Efficient Transformers with Approximate Computing

Vision Transformer (ViT) models which were recently introduced by the transformer architecture have shown to be very competitive and often become a popular alternative to Convolutional Neural Networks (CNNs). However, the high computational requirements of these models limit their practical applicability especially on low-power devices. Current state-of-the-art employs approximate multipliers to address the highly increased compute demands of DNN accelerators but no prior research has explored their use on ViT models. In this work we propose TransAxx, a framework based on the popular PyTorch library that enables fast inherent support for approximate arithmetic to seamlessly evaluate the impact of approximate computing on DNNs such as ViT models. Using TransAxx we analyze the sensitivity of transformer models on the ImageNet dataset to approximate multiplications and perform approximate-aware finetuning to regain accuracy. Furthermore, we propose a methodology to generate approximate accelerators for ViT models. Our approach uses a Monte Carlo Tree Search (MCTS) algorithm to efficiently search the space of possible configurations using a hardware-driven hand-crafted policy. Our evaluation demonstrates the efficacy of our methodology in achieving significant trade-offs between accuracy and power, resulting in substantial gains without compromising on performance.

Embedding Hardware Approximations in Discrete Genetic-based Training for Printed MLPs

Printed Electronics (PE) stands out as a promisingtechnology for widespread computing due to its distinct attributes, such as low costs and flexible manufacturing. Unlike traditional silicon-based technologies, PE enables stretchable, conformal,and non-toxic hardware. However, PE are constrained by larger feature sizes, making it challenging to implement complex circuits such as machine learning (ML) classifiers. Approximate computing has been proven to reduce the hardware cost of ML circuits such as Multilayer Perceptrons (MLPs). In this paper, we maximize the benefits of approximate computing by integrating hardware approximation into the MLP training process. Due to the discrete nature of hardware approximation, we propose and implement a genetic-based, approximate, hardware-aware training approach specifically designed for printed MLPs. For a 5% accuracy loss, our MLPs achieve over 5x area and power reduction compared to the baseline while outperforming state of-the-art approximate and stochastic printed MLPs.

Bespoke Approximation of Multiplication-Accumulation and Activation Targeting Printed Multilayer Perceptrons

Printed Electronics (PE) feature distinct and remarkable characteristics that make them a prominent technology for achieving true ubiquitous computing. This is particularly relevant in application domains that require conformal and ultra-low cost solutions, which have experienced limited penetration of computing until now. Unlike silicon-based technologies, PE offer unparalleled features such as non-recurring engineering costs, ultra-low manufacturing cost, and on-demand fabrication of conformal, flexible, non-toxic, and stretchable hardware. However, PE face certain limitations due to their large feature sizes, that impede the realization of complex circuits, such as machine learning classifiers. In this work, we address these limitations by leveraging the principles of Approximate Computing and Bespoke (fully-customized) design. We propose an automated framework for designing ultra-low power Multilayer Perceptron (MLP) classifiers which employs, for the first time, a holistic approach to approximate all functions of the MLP's neurons: multiplication, accumulation, and activation. Through comprehensive evaluation across various MLPs of varying size, our framework demonstrates the ability to enable battery-powered operation of even the most intricate MLP architecture examined, significantly surpassing the current state of the art.

Hardware-Aware DNN Compression via Diverse Pruning and Mixed-Precision Quantization

Deep Neural Networks (DNNs) have shown significant advantages in a wide variety of domains. However, DNNs are becoming computationally intensive and energy hungry at an exponential pace, while at the same time, there is a vast demand for running sophisticated DNN-based services on resource constrained embedded devices. In this paper, we target energy-efficient inference on embedded DNN accelerators. To that end, we propose an automated framework to compress DNNs in a hardware-aware manner by jointly employing pruning and quantization. We explore, for the first time, per-layer fine- and coarse-grained pruning, in the same DNN architecture, in addition to low bit-width mixed-precision quantization for weights and activations. Reinforcement Learning (RL) is used to explore the associated design space and identify the pruning-quantization configuration so that the energy consumption is minimized whilst the prediction accuracy loss is retained at acceptable levels. Using our novel composite RL agent we are able to extract energy-efficient solutions without requiring retraining and/or fine tuning. Our extensive experimental evaluation over widely used DNNs and the CIFAR-10/100 and ImageNet datasets demonstrates that our framework achieves $39\%$ average energy reduction for $1.7\%$ average accuracy loss and outperforms significantly the state-of-the-art approaches.

On-sensor Printed Machine Learning Classification via Bespoke ADC and Decision Tree Co-Design

Printed electronics (PE) technology provides cost-effective hardware with unmet customization, due to their low non-recurring engineering and fabrication costs. PE exhibit features such as flexibility, stretchability, porosity, and conformality, which make them a prominent candidate for enabling ubiquitous computing. Still, the large feature sizes in PE limit the realization of complex printed circuits, such as machine learning classifiers, especially when processing sensor inputs is necessary, mainly due to the costly analog-to-digital converters (ADCs). To this end, we propose the design of fully customized ADCs and present, for the first time, a co-design framework for generating bespoke Decision Tree classifiers. Our comprehensive evaluation shows that our co-design enables self-powered operation of on-sensor printed classifiers in all benchmark cases.

Model-to-Circuit Cross-Approximation For Printed Machine Learning Classifiers

Printed electronics (PE) promises on-demand fabrication, low non-recurring engineering costs, and sub-cent fabrication costs. It also allows for high customization that would be infeasible in silicon, and bespoke architectures prevail to improve the efficiency of emerging PE machine learning (ML) applications. Nevertheless, large feature sizes in PE prohibit the realization of complex ML models in PE, even with bespoke architectures. In this work, we present an automated, cross-layer approximation framework tailored to bespoke architectures that enable complex ML models, such as Multi-Layer Perceptrons (MLPs) and Support Vector Machines (SVMs), in PE. Our framework adopts cooperatively a hardware-driven coefficient approximation of the ML model at algorithmic level, a netlist pruning at logic level, and a voltage over-scaling at the circuit level. Extensive experimental evaluation on 12 MLPs and 12 SVMs and more than 6000 approximate and exact designs demonstrates that our model-to-circuit cross-approximation delivers power and area optimal designs that, compared to the state-of-the-art exact designs, feature on average 51% and 66% area and power reduction, respectively, for less than 5% accuracy loss. Finally, we demonstrate that our framework enables 80% of the examined classifiers to be battery-powered with almost identical accuracy with the exact designs, paving thus the way towards smart complex printed applications.

Co-Design of Approximate Multilayer Perceptron for Ultra-Resource Constrained Printed Circuits

Printed Electronics (PE) exhibits on-demand, extremely low-cost hardware due to its additive manufacturing process, enabling machine learning (ML) applications for domains that feature ultra-low cost, conformity, and non-toxicity requirements that silicon-based systems cannot deliver. Nevertheless, large feature sizes in PE prohibit the realization of complex printed ML circuits. In this work, we present, for the first time, an automated printed-aware software/hardware co-design framework that exploits approximate computing principles to enable ultra-resource constrained printed multilayer perceptrons (MLPs). Our evaluation demonstrates that, compared to the state-of-the-art baseline, our circuits feature on average 6x (5.7x) lower area (power) and less than 1% accuracy loss.

Approximate Computing and the Efficient Machine Learning Expedition

Approximate computing (AxC) has been long accepted as a design alternative for efficient system implementation at the cost of relaxed accuracy requirements. Despite the AxC research activities in various application domains, AxC thrived the past decade when it was applied in Machine Learning (ML). The by definition approximate notion of ML models but also the increased computational overheads associated with ML applications-that were effectively mitigated by corresponding approximations-led to a perfect matching and a fruitful synergy. AxC for AI/ML has transcended beyond academic prototypes. In this work, we enlighten the synergistic nature of AxC and ML and elucidate the impact of AxC in designing efficient ML systems. To that end, we present an overview and taxonomy of AxC for ML and use two descriptive application scenarios to demonstrate how AxC boosts the efficiency of ML systems.
