End-to-End Hybrid Refractive-Diffractive Lens Design with Differentiable Ray-Wave Model

Hybrid refractive-diffractive lenses combine the light efficiency of refractive lenses with the information encoding power of diffractive optical elements (DOE), showing great potential as the next generation of imaging systems. However, accurately simulating such hybrid designs is generally difficult, and in particular, there are no existing differentiable image formation models for hybrid lenses with sufficient accuracy. In this work, we propose a new hybrid ray-tracing and wave-propagation (ray-wave) model for accurate simulation of both optical aberrations and diffractive phase modulation, where the DOE is placed between the last refractive surface and the image sensor, i.e. away from the Fourier plane that is often used as a DOE position. The proposed ray-wave model is fully differentiable, enabling gradient back-propagation for end-to-end co-design of refractive-diffractive lens optimization and the image reconstruction network. We validate the accuracy of the proposed model by comparing the simulated point spread functions (PSFs) with theoretical results, as well as simulation experiments that show our model to be more accurate than solutions implemented in commercial software packages like Zemax. We demonstrate the effectiveness of the proposed model through real-world experiments and show significant improvements in both aberration correction and extended depth-of-field (EDoF) imaging. We believe the proposed model will motivate further investigation into a wide range of applications in computational imaging, computational photography, and advanced optical design. Code will be released upon publication.

Image Quality Is Not All You Want: Task-Driven Lens Design for Image Classification

In computer vision, it has long been taken for granted that high-quality images obtained through well-designed camera lenses would lead to superior results. However, we find that this common perception is not a "one-size-fits-all" solution for diverse computer vision tasks. We demonstrate that task-driven and deep-learned simple optics can actually deliver better visual task performance. The Task-Driven lens design approach, which relies solely on a well-trained network model for supervision, is proven to be capable of designing lenses from scratch. Experimental results demonstrate the designed image classification lens (``TaskLens'') exhibits higher accuracy compared to conventional imaging-driven lenses, even with fewer lens elements. Furthermore, we show that our TaskLens is compatible with various network models while maintaining enhanced classification accuracy. We propose that TaskLens holds significant potential, particularly when physical dimensions and cost are severely constrained.

Aberration-Aware Depth-from-Focus

Computer vision methods for depth estimation usually use simple camera models with idealized optics. For modern machine learning approaches, this creates an issue when attempting to train deep networks with simulated data, especially for focus-sensitive tasks like Depth-from-Focus. In this work, we investigate the domain gap caused by off-axis aberrations that will affect the decision of the best-focused frame in a focal stack. We then explore bridging this domain gap through aberration-aware training (AAT). Our approach involves a lightweight network that models lens aberrations at different positions and focus distances, which is then integrated into the conventional network training pipeline. We evaluate the generality of pretrained models on both synthetic and real-world data. Our experimental results demonstrate that the proposed AAT scheme can improve depth estimation accuracy without fine-tuning the model or modifying the network architecture.

Curriculum Learning for ab initio Deep Learned Refractive Optics

Deep lens optimization has recently emerged as a new paradigm for designing computational imaging systems, however it has been limited to either simple optical systems consisting of a single DOE or metalens, or the fine-tuning of compound lenses from good initial designs. Here we present a deep lens design method based on curriculum learning, which is able to learn optical designs of compound lenses ab initio from randomly initialized surfaces, therefore overcoming the need for a good initial design. We demonstrate this approach with the fully-automatic design of an extended depth-of-field computational camera in a cellphone-style form factor, highly aspherical surfaces, and a short back focal length.
