Nonlinear Modes as a Tool for Comparing the Mathematical Structure of Dynamic Models of Soft Robots

Continuum soft robots are nonlinear mechanical systems with theoretically infinite degrees of freedom (DoFs) that exhibit complex behaviors. Achieving motor intelligence under dynamic conditions necessitates the development of control-oriented reduced-order models (ROMs), which employ as few DoFs as possible while still accurately capturing the core characteristics of the theoretically infinite-dimensional dynamics. However, there is no quantitative way to measure if the ROM of a soft robot has succeeded in this task. In other fields, like structural dynamics or flexible link robotics, linear normal modes are routinely used to this end. Yet, this theory is not applicable to soft robots due to their nonlinearities. In this work, we propose to use the recent nonlinear extension in modal theory -- called eigenmanifolds -- as a means to evaluate control-oriented models for soft robots and compare them. To achieve this, we propose three similarity metrics relying on the projection of the nonlinear modes of the system into a task space of interest. We use this approach to compare quantitatively, for the first time, ROMs of increasing order generated under the piecewise constant curvature (PCC) hypothesis with a high-dimensional finite element (FE)-like model of a soft arm. Results show that by increasing the order of the discretization, the eigenmanifolds of the PCC model converge to those of the FE model.

Unified Inverse Dynamics of Modular Serial Mechanical Systems with Application to Soft Robotics

The robotic field has been witnessing a progressive departure from classic robotic systems composed of serial/stiff links interconnected by simple rigid joints. Novel robotic concepts, e.g., soft robots, often maintain a series-like structure, but their mechanical modules exhibit complex and unconventional articulation patterns. Research in efficient recursive formulations of the dynamic models for subclasses of these systems has been extremely active in the past decade. Yet, as of today, no single recursive inverse dynamics algorithm can describe the behavior of all these systems. This paper addresses this challenge by proposing a new iterative formulation based on Kane equations. Its computational complexity is optimal, i.e., linear with the number of modules. While the proposed formulation is not claimed to be necessarily more efficient than state-of-the-art techniques for specific subclasses of robots, we illustrate its usefulness in the modeling of different complex systems. We propose two new models of soft robots: (i) a class of pneumatically actuated soft arms that deform along their cross-sectional area, and (ii) a piecewise strain model with Gaussian functions.

On the Collocated Form with Input Decoupling of Lagrangian Systems

Suitable representations of dynamical systems can simplify their analysis and control. On this line of thought, this paper considers the input decoupling problem for input-affine Lagrangian dynamics, namely the problem of finding a transformation of the generalized coordinates that decouples the input channels. We identify a class of systems for which this problem is solvable. Such systems are called collocated because the decoupling variables correspond to the coordinates on which the actuators directly perform work. Under mild conditions on the input matrix, a simple test is presented to verify whether a system is collocated or not. By exploiting power invariance, it is proven that a change of coordinates decouples the input channels if and only if the dynamics is collocated. We illustrate the theoretical results by considering several Lagrangian systems, focusing on underactuated mechanical systems, for which novel controllers that exploit input decoupling are designed.
