Optimal Robot Formations: Balancing Range-Based Observability and User-Defined Configurations

This paper introduces a set of customizable and novel cost functions that enable the user to easily specify desirable robot formations, such as a ``high-coverage'' infrastructure-inspection formation, while maintaining high relative pose estimation accuracy. The overall cost function balances the need for the robots to be close together for good ranging-based relative localization accuracy and the need for the robots to achieve specific tasks, such as minimizing the time taken to inspect a given area. The formations found by minimizing the aggregated cost function are evaluated in a coverage path planning task in simulation and experiment, where the robots localize themselves and unknown landmarks using a simultaneous localization and mapping algorithm based on the extended Kalman filter. Compared to an optimal formation that maximizes ranging-based relative localization accuracy, these formations significantly reduce the time to cover a given area with minimal impact on relative pose estimation accuracy.

navlie: A Python Package for State Estimation on Lie Groups

The ability to rapidly test a variety of algorithms for an arbitrary state estimation task is valuable in the prototyping phase of navigation systems. Lie group theory is now mainstream in the robotics community, and hence estimation prototyping tools should allow state definitions that belong to manifolds. A new package, called navlie, provides a framework that allows a user to model a large class of problems by implementing a set of classes complying with a generic interface. Once accomplished, navlie provides a variety of on-manifold estimation algorithms that can run directly on these classes. The package also provides a built-in library of common models, as well as many useful utilities. The open-source project can be found at https://github.com/decargroup/navlie.

IMU Preintegration for Multi-Robot Systems in the Presence of Bias and Communication Constraints

This document is in supplement to the paper titled "Multi-Robot Relative Pose Estimation and IMU Preintegration Using Passive UWB Transceivers", available at [1]. The purpose of this document is to show how IMU biases can be incorporated into the framework presented in [1], while maintaining the differential Sylvester equation form of the process model.

Multi-Robot Relative Pose Estimation and IMU Preintegration Using Passive UWB Transceivers

Ultra-wideband (UWB) systems are becoming increasingly popular as a means of inter-robot ranging and communication. A major constraint associated with UWB is that only one pair of UWB transceivers can range at a time to avoid interference, hence hindering the scalability of UWB-based localization. In this paper, a ranging protocol is proposed that allows all robots to passively listen on neighbouring communicating robots without any hierarchical restrictions on the role of the robots. This is utilized to allow each robot to obtain more range measurements and to broadcast preintegrated inertial measurement unit (IMU) measurements for relative extended pose state estimation directly on SE_2(3). Consequently, a simultaneous clock-synchronization and relative-pose estimator (CSRPE) is formulated using an on-manifold extended Kalman filter (EKF) and is evaluated in simulation using Monte-Carlo runs for up to 7 robots. The ranging protocol is implemented in C on custom-made UWB boards fitted to 3 quadcopters, and the proposed filter is evaluated over multiple experimental trials, yielding up to 56% improvement in localization accuracy.

On-manifold Decentralized State Estimation using Pseudomeasurements and Preintegration

This paper addresses the problem of decentralized, collaborative state estimation in robotic teams. In particular, this paper considers problems where individual robots estimate similar physical quantities, such as each other's position relative to themselves. The use of pseudomeasurements is introduced as a means of modelling such relationships between robots' state estimates, and is shown to be a tractable way to approach the decentralized state estimation problem. Moreover, this formulation easily leads to a general-purpose observability test that simultaneously accounts for measurements that robots collect from their own sensors, as well as the communication structure within the team. Finally, input preintegration is proposed as a communication-efficient way of sharing odometry information between robots, and the entire theory is appropriate for both vector-space and Lie-group state definitions. The proposed framework is evaluated on three different simulated problems, and one experiment involving three quadcopters.

Reducing Two-Way Ranging Variance by Signal-Timing Optimization

Time-of-flight-based range measurements among transceivers with different clocks requires ranging protocols that accommodate for the varying rates of the clocks. Double-sided two-way ranging (DS-TWR) has recently been widely adopted as a standard protocol due to its accuracy; however, the precision of DS-TWR has not been clearly addressed. In this paper, an analytical model of the variance of DS-TWR is derived as a function of the user-programmed response delays. Consequently, this allows formulating an optimization problem over the response delays in order to maximize the information gained from range measurements by addressing the effect of varying the response delays on the precision and frequency of the measurements. The derived analytical variance model and proposed optimization formulation are validated experimentally with 2 ranging UWB transceivers, where 29 million range measurements are collected.

Calibration and Uncertainty Characterization for Ultra-Wideband Two-Way-Ranging Measurements

Ultra-Wideband (UWB) systems are becoming increasingly popular for indoor localization, where range measurements are obtained by measuring the time-of-flight of radio signals. However, the range measurements typically suffer from a systematic error or bias that must be corrected for high-accuracy localization. In this paper, a ranging protocol is proposed alongside a robust and scalable antenna-delay calibration procedure to accurately and efficiently calibrate antenna delays for many UWB tags. Additionally, the bias and uncertainty of the measurements are modelled as a function of the received-signal power. The full calibration procedure is presented using experimental training data of 3 aerial robots fitted with 2 UWB tags each, and then evaluated on 2 test experiments. A localization problem is then formulated on the experimental test data, and the calibrated measurements and their modelled uncertainty are fed into an extended Kalman filter (EKF). The proposed calibration is shown to yield an average of 46% improvement in localization accuracy. Lastly, the paper is accompanied by an open-source UWB-calibration Python library, which can be found at https://github.com/decarsg/uwb_calibration.

Optimal Multi-robot Formations for Relative Pose Estimation Using Range Measurements

In multi-robot missions, relative position and attitude information between agents is valuable for a variety of tasks such as mapping, planning, and formation control. In this paper, the problem of estimating relative poses from a set of inter-agent range measurements is investigated. Specifically, it is shown that the estimation accuracy is highly dependent on the true relative poses themselves, which prompts the desire to find multi-agent formations that provide the best estimation performance. By direct maximization of Fischer information, it is shown in simulation and experiment that large improvements in estimation accuracy can be obtained by optimizing the formation geometry of a team of robots.

Ultra-Wideband Teach and Repeat

Autonomously retracing a manually-taught path is desirable for many applications, and Teach and Repeat (T&R) algorithms present an approach that is suitable for long-range autonomy. In this paper, ultra-wideband (UWB) ranging-based T&R is proposed for vehicles with limited resources. By fixing single UWB transceivers at far-apart unknown locations in an indoor environment, a robot with 3 UWB transceivers builds a locally consistent map during the teach pass by fusing the range measurements under a custom ranging protocol with an on-board IMU and height measurements. The robot then uses information from the teach pass to retrace the same trajectory autonomously. The proposed ranging protocol and T&R algorithm are validated in simulation, where it is shown that the robot can successfully retrace the taught trajectory with sub-metre tracking error.
