Solving combinational optimization problems with evolutionary single-pixel imaging

Single-pixel imaging (SPI) is a novel optical imaging technique by replacing the pixelated sensor array in a conventional camera with a single-pixel detector. In previous works, SPI is usually used for capturing object images or performing image processing tasks. In this work, we propose a SPI scheme for processing other types of data in addition to images. An Ising machine model is implemented optically with SPI for solving combinational optimization problems including number partition and graph maximum cut. Simulated and experimental results show that our proposed scheme can optimize the Hamiltonian function with evolutionary illumination patterns.

Playing Tic-Tac-Toe Games with Intelligent Single-pixel Imaging

Single-pixel imaging (SPI) is a novel optical imaging technique by replacing a two-dimensional pixelated sensor with a single-pixel detector and pattern illuminations. SPI have been extensively used for various tasks related to image acquisition and processing. In this work, a novel non-image-based task of playing Tic-Tac-Toe games interactively is merged into the framework of SPI. An optoelectronic artificial intelligent (AI) player with minimal digital computation can detect the game states, generate optimal moves and display output results mainly by pattern illumination and single-pixel detection. Simulated and experimental results demonstrate the feasibility of proposed scheme and its unbeatable performance against human players.

Ptychographic sensor for large-scale lensless microbial monitoring with high spatiotemporal resolution

Traditional microbial detection methods often rely on the overall property of microbial cultures and cannot resolve individual growth event at high spatiotemporal resolution. As a result, they require bacteria to grow to confluence and then interpret the results. Here, we demonstrate the application of an integrated ptychographic sensor for lensless cytometric analysis of microbial cultures over a large scale and with high spatiotemporal resolution. The reported device can be placed within a regular incubator or used as a standalone incubating unit for long-term microbial monitoring. For longitudinal study where massive data are acquired at sequential time points, we report a new temporal-similarity constraint to increase the temporal resolution of ptychographic reconstruction by 7-fold. With this strategy, the reported device achieves a centimeter-scale field of view, a half-pitch spatial resolution of 488 nm, and a temporal resolution of 15-second intervals. For the first time, we report the direct observation of bacterial growth in a 15-second interval by tracking the phase wraps of the recovered images, with high phase sensitivity like that in interferometric measurements. We also characterize cell growth via longitudinal dry mass measurement and perform rapid bacterial detection at low concentrations. For drug-screening application, we demonstrate proof-of-concept antibiotic susceptibility testing and perform single-cell analysis of antibiotic-induced filamentation. The combination of high phase sensitivity, high spatiotemporal resolution, and large field of view is unique among existing microscopy techniques. As a quantitative and miniaturized platform, it can improve studies with microorganisms and other biospecimens at resource-limited settings.

High-throughput lensless whole slide imaging via continuous height-varying modulation of tilted sensor

We report a new lensless microscopy configuration by integrating the concepts of transverse translational ptychography and defocus multi-height phase retrieval. In this approach, we place a tilted image sensor under the specimen for linearly-increasing phase modulation along one lateral direction. Similar to the operation of ptychography, we laterally translate the specimen and acquire the diffraction images for reconstruction. Since the axial distance between the specimen and the sensor varies at different lateral positions, laterally translating the specimen effectively introduces defocus multi-height measurements while eliminating axial scanning. Lateral translation further introduces sub-pixel shift for pixel super-resolution imaging and naturally expands the field of view for rapid whole slide imaging. We show that the equivalent height variation can be precisely estimated from the lateral shift of the specimen, thereby addressing the challenge of precise axial positioning in conventional multi-height phase retrieval. Using a sensor with a 1.67-micron pixel size, our low-cost and field-portable prototype can resolve 690-nm linewidth on the resolution target. We show that a whole slide image of a blood smear with a 120-mm^2 field of view can be acquired in 18 seconds. We also demonstrate accurate automatic white blood cell counting from the recovered image. The reported approach may provide a turnkey solution for addressing point-of-care- and telemedicine-related challenges.

Fast Fourier single-pixel imaging using binary illumination

Fourier single-pixel imaging (FSI) has proven capable of reconstructing high-quality two-dimensional and three-dimensional images. The utilization of the sparsity of natural images in Fourier domain allows high-resolution images to be reconstructed from far fewer measurements than effective image pixels. However, applying original FSI in digital micro-mirror device (DMD) based high-speed imaging system turns out to be challenging, because the original FSI uses grayscale Fourier basis patterns for illumination while DMDs generate grayscale patterns at a relatively low rate. DMDs are a binary device which can only generate a black-and-white pattern at each instance. In this paper, we adopt binary Fourier patterns for illumination to achieve DMD-based high-speed single-pixel imaging. Binary Fourier patterns are generated by upsampling and then applying error diffusion based dithering to the grayscale patterns. Experiments demonstrate the proposed technique able to achieve static imaging with high quality and dynamic imaging in real time. The proposed technique potentially allows high-quality and high-speed imaging over broad wavebands.
