Orbital-Angular-Momentum Embedded Massive MIMO: Achieving Multiplicative Spectrum-Efficiency for mmWave Communications

By enabling very high bandwidth for radio communications, the millimeter-wave (mmWave), which can easily be integrated with massive-multiple-input-multiple-output (massive-MIMO) due to small antenna size, has been attracting growing attention as a candidate for the fifth-generation (5G) and 5G-beyond wireless communications networks. On the other hand, the communication over the orthogonal states/modes of orbital angular momentum (OAM) is a subset of the solutions offered by massive-MIMO communications. Traditional massive-MIMO based mmWave communications did not concern the potential spectrum-efficiency-gain (SE-gain) offered by orthogonal states of OAM. However, the highly expecting maximum SE-gain for OAM and massive-MIMO communications is the product of SE-gains offered by OAM and multiplexing-MIMO. In this paper, we propose the OAM-embedded-MIMO (OEM) communication framework to obtain the multiplicative SE-gain for joint OAM and massive-MIMO based mmWave wireless communications. We design the parabolic antenna for each uniform circular array antenna to converge OAM signals. Then, we develop the mode-decomposition and multiplexing-detection scheme to obtain the transmit signal on each OAM-mode of each transmit antenna. Also, we develop the OEM-water-filling power allocation policy to achieve the maximum multiplicative SE-gain for OEM communications. The extensive simulations obtained validate and evaluate our developed parabolic antenna based converging method, mode-decomposition and multiplexing-detection scheme, and OEM-water-filling policy, showing that our proposed OEM mmWave communications can significantly increase the spectrum-efficiency as compared with traditional massive-MIMO based mmWave communications.

Rate Maximization for RIS-Assisted OAM Multiuser Wireless Communications

Conventional multiple-input multiple-out (MIMO) technologies have encountered bottlenecks of significantly increasing spectrum efficiencies of wireless communications due to the low degrees of freedom in practical line-of-sight scenarios and severe path loss of high frequency carriers. Orbital angular momentum (OAM) has shown the potential for high spectrum efficiencies in radio frequency domains. To investigate the advantage of OAM in multiuser communications, in this paper we propose the reconfigurable intelligence surface (RIS) assisted OAM multiuser (MU) wireless communication schemes, where RIS is deployed to establish the direct links blocked by obstacles between the OAM transmitter and users, to significantly increase the achievable sum rate (ASR) of MU systems. To maximize the ASR, we develop the alternative optimization algorithm to jointly optimize the transmit power and phase shifts of RIS. The numerical outcomes demonstrate the superiority of our proposed scheme compared to existing methods in terms of ASR.

Air-to-Ground Cooperative OAM Communications

For users in hotspot region, orbital angular momentum (OAM) can realize multifold increase of spectrum efficiency (SE), and the flying base station (FBS) can rapidly support the real-time communication demand. However, the hollow divergence and alignment requirement impose crucial challenges for users to achieve air-to-ground OAM communications, where there exists the line-of-sight path. Therefore, we propose the air-to-ground cooperative OAM communication (ACOC) scheme, which can realize OAM communications for users with size-limited devices. The waist radius is adjusted to guarantee the maximum intensity at the cooperative users (CUs). We derive the closed-form expression of the optimal FBS position, which satisfies the antenna alignment for two cooperative user groups (CUGs). Furthermore, the selection constraint is given to choose two CUGs composed of four CUs. Simulation results are provided to validate the optimal FBS position and the SE superiority of the proposed ACOC scheme.

Cooperative Orbital Angular Momentum Wireless Communications

Orbital angular momentum (OAM) mode multiplexing has the potential to achieve high spectrum-efficiency communications at the same time and frequency by using orthogonal mode resource. However, the vortex wave hollow divergence characteristic results in the requirement of the large-scale receive antenna, which makes users hardly receive the OAM signal by size-limited equipment. To promote the OAM application in the next 6G communications, this paper proposes the cooperative OAM wireless (COW) communication scheme, which can select the cooperative users (CUs) to form the aligned antennas by size-limited user equipment. First, we derive the feasible radial radius and selective waist radius to choose the CUs in the same circle with the origin at the base station. Then, based on the locations of CUs, the waist radius is adjusted to form the receive antennas and ensure the maximum intensity for the CUs. Finally, the cooperative formation probability is derived in the closed-form solution, which can depict the feasibility of the proposed COW communication scheme. Furthermore, OAM beam steering is used to expand the feasible CU region, thus achieving higher cooperative formation probability. Simulation results demonstrate that the derived cooperative formation probability in mathematical analysis is very close to the statistical probability of cooperative formation, and the proposed COW communication scheme can obtain higher spectrum efficiency than the traditional scheme due to the effective reception of the OAM signal.

Orbital Angular Momentum Active Anti-Jamming in Radio Wireless Communications

Orbital angular momentum (OAM), providing the orthogonality among different OAM modes, has attracted much attention to significantly increase spectrum efficiencies (SEs) and enhance the anti-jamming results of wireless communications. However, the SE of wireless communications is severely degraded under co-frequency and co-mode hostile jamming. Focused on this issue, we propose a novel OAM active anti-jamming scheme to significantly enhance the anti-jamming results of wireless communications under broadband hostile jamming. Specifically, the OAM transmitter with energy detection senses jamming signals to identify which OAM modes are jammed and unjammed. Based on the recognition of OAM modes, useful signals are modulated by reflecting the received co-frequency and co-mode jamming signals with the assistance of a programmable gain amplifier (PGA) to the OAM receiver, thus utilizing both the OAM modes jammed by hostile attacks and the energy of jamming signals. Meanwhile, the unjammed OAM modes allocated with total transmit power are multiplexed for useful signal transmission. Numerical results demonstrate that our proposed OAM active anti-jamming scheme can achieve high OAM mode utilization and significantly increase the SEs.

Mode Hopping with OAM-Based Index Modulation

Orbital angular momentum (OAM) based mode hopping (MH) scheme is expected to be a potential anti-jamming technology in radio vortex wireless communications. However, it only uses one OAM-mode for hopping, thus resulting in low spectrum efficiency (SE). Index modulation offers a trade-off balance between the SE and performance reliability. In this paper, we propose an MH with OAM-based index modulation scheme, where several OAM-modes are activated for hopping, to achieve high SE at a given bit error rate in radio vortex wireless communications. Based on the proposed scheme, we derive the upper bound and lower bound of achievable SEs. Furthermore, in order to take advantage of index information, we derive the optimal hopped OAM-modes to achieve the maximum SE. Numerical results show that our proposed MH with index modulation scheme can achieve high SE while satisfying a certain reliability of radio vortex wireless communications.

Joint OAM Multiplexing and OFDM in Sparse Multipath Environments

The emerging orbital angular momentum (OAM) based wireless communication is expected to be a high spectrum-efficiency communication paradigm to solve the growing transmission data rate and limited bandwidth problem. Academic researchers mainly concentrate on the OAM-based line-of-sight (LoS) communications. However, there exist some surroundings around the transceiver in most practical wireless communication scenarios, thus forming multipath transmission. In this paper, a hybrid orthogonal division multiplexing (HODM) scheme by using OAM multiplexing and orthogonal frequency division multiplexing (OFDM) in conjunction is proposed to achieve high-capacity wireless communications in sparse multipath environments, where the scatterers are sparse. We first build the OAM-based wireless channel in a LoS path and several reflection paths combined sparse multipath environments. We concentrate on less than or equal to three-time reflection paths because of the severe energy attenuation. The phase difference among the channel amplitude gains of the LoS and reflection paths, which is caused by the reflection paths, makes it difficult to decompose the OAM signals. We propose the phase difference compensation to handle this problem and then calculate the corresponding capacity in radio vortex wireless communications. Numerical results illustrate that the capacity of wireless communications by using our proposed HODM scheme can be drastically increased in sparse multipath environments.

Mode Hopping for Anti-Jamming in Radio Vortex Wireless Communications

Frequency hopping (FH) has been widely used as a powerful technique for antijamming in wireless communications. However, as the wireless spectrum is becoming more and more crowded, it is very difficult to achieve efficient antijamming results with FH-based schemes. Orbital angular momentum (OAM), which provides the new angular/mode dimension for wireless communications, offers an intriguing way for antijamming. In this paper, we propose to use the orthogonality of OAM-modes for antijamming in wireless communications. In particular, we propose the mode hopping (MH) scheme for antijamming within the narrow frequency band. We derive the closed-form expression of bit error rate (BER) for multiple users scenario with our developed MH scheme. Our developed MH scheme can achieve the same antijamming results within the narrow frequency band as compared with the conventional wideband FH scheme. Furthermore, we propose mode-frequency hopping (MFH) scheme, which jointly uses our developed MH scheme and the conventional FH scheme to further decrease the BER for wireless communication. Numerical results are presented to show that the BER of our developed MH scheme within the narrow frequency band is the same with that of the conventional wideband FH scheme. Moreover, the BER of our developed MFH schemes is much smaller than that of the conventional FH schemes for wireless communications.

Index Modulation Embedded Mode Hopping for Anti-Jamming

Due to the crowded spectrum, frequency hopping (FH) techniques are now very difficult to achieve efficient antijamming and increase spectrum efficiency (SE) for wireless communications. The emerging orbital angular momentum (OAM), which is a property describing the helical phase fronts of electromagnetic waves, offers the potential to improve reliability and increase SE in wireless communications. To achieve efficient anti-jamming and increase SE of wireless communications with slight computational complexity cost, in this paper we propose an index-modulation embedded mode-hopping (IM-MH) scheme, which simultaneously activates several OAM-modes for hopping along with additional index information and signal information transmission. We analyze the average bit error rates (ABERs) for our proposed IM-MH scheme with perfect channel state information (CSI) and imperfect CSI, respectively. We also propose the index-modulation embedded double-serial MH (IMDSMH) scheme, which randomly activates one OAM-mode as the serial second hop to transmit the hopping signals in the IM-MH scheme, to further decrease the ABER of wireless communications. Extensive numerical results demonstrate that our proposed schemes within a narrowband can achieve the low ABER and significantly increase the SE. Also, the ABERs of our proposed IM-MH and IM-DSMH schemes are around 25% and 10%, respectively, compared with that of the mode hopping scheme.

Integrated Sensing and Communication for Anti-Jamming with OAM

The spectrum share and open nature of wireless channels enable integrated sensing and communication (ISAC) susceptible to hostile jamming attacks. Due to the intrinsic orthogonality and rich azimuth angle information of orbital angular momentum (OAM), vortex electromagnetic waves with helical phase fronts have shown great potential to achieve high-resolution imaging and strong anti-jamming capability of wireless communication. Focusing on significantly enhancing the anti-jamming results of ISAC systems with limited bandwidth under hostile jamming, in this paper we propose a novel ISAC for anti-jamming with OAM scheme, where the OAM legitimate transmitter can simultaneously sense the position of jammers with dynamic behavior and send data to multiple OAM legitimate users. Specifically, the OAM modes for sensing and communications are respectively hopped according to pre-set index modulation information to suppress jamming. To acquire the position of the jammer, we develop the enhanced multiple-signal-classification-based three-dimension position estimation scheme with continuous sensing in both frequency and angular domains, where the OAM transmitter is designed with the concentric uniform-circular-array mono-static method, to significantly increase the azimuthal resolution. Then, based on the acquired jamming channel state information, we develop the joint transmit-receive beamforming and power allocation scheme, where the transmit and receive beamforming matrices are dynamically adjusted to mitigate the mixed interference containing inter-mode interference, inter-user interference, and jamming, thus maximizing the achievable sum rates (ASRs) of all users. Numerical results demonstrate that our proposed scheme can significantly increase the ASR under broadband jamming attacks and achieve high detection accuracy of targets .
