A WINNER+ Based 3-D Non-Stationary Wideband MIMO Channel Model

In this paper, a three-dimensional (3-D) non-stationary wideband multiple-input multiple-output (MIMO) channel model based on the WINNER+ channel model is proposed. The angular distributions of clusters in both the horizontal and vertical planes are jointly considered. The receiver and clusters can be moving, which makes the model more general. Parameters including number of clusters, powers, delays, azimuth angles of departure (AAoDs), azimuth angles of arrival (AAoAs), elevation angles of departure (EAoDs), and elevation angles of arrival (EAoAs) are time-variant. The cluster time evolution is modeled using a birth-death process. Statistical properties, including spatial cross-correlation function (CCF), temporal autocorrelation function (ACF), Doppler power spectrum density (PSD), level-crossing rate (LCR), average fading duration (AFD), and stationary interval are investigated and analyzed. The LCR, AFD, and stationary interval of the proposed channel model are validated against the measurement data. Numerical and simulation results show that the proposed channel model has the ability to reproduce the main properties of real non-stationary channels. Furthermore, the proposed channel model can be adapted to various communication scenarios by adjusting different parameter values.

A General 3D Non-Stationary Wireless Channel Model for 5G and Beyond

In this paper, a novel three-dimensional (3D) non-stationary geometry-based stochastic model (GBSM) for the fifth generation (5G) and beyond 5G (B5G) systems is proposed. The proposed B5G channel model (B5GCM) is designed to capture various channel characteristics in (B)5G systems such as space-time-frequency (STF) non-stationarity, spherical wavefront (SWF), high delay resolution, time-variant velocities and directions of motion of the transmitter, receiver, and scatterers, spatial consistency, etc. By combining different channel properties into a general channel model framework, the proposed B5GCM is able to be applied to multiple frequency bands and multiple scenarios, including massive multiple-input multiple-output (MIMO), vehicle-to-vehicle (V2V), high-speed train (HST), and millimeter wave-terahertz (mmWave-THz) communication scenarios. Key statistics of the proposed B5GCM are obtained and compared with those of standard 5G channel models and corresponding measurement data, showing the generalization and usefulness of the proposed model.
