Deep Sea Robotic Imaging Simulator for UUV Development

Nowadays underwater vision systems are being widely applied in ocean research. However, the largest portion of the ocean - the deep sea - still remains mostly unexplored. Only relatively few images sets have been taken from the deep sea due to the physical limitations caused by technical challenges and enormous costs. The shortage of deep sea images and the corresponding ground truth data for evaluation and training is becoming a bottleneck for the development of underwater computer vision methods. Thus this paper presents a physical model-based image simulation solution which uses in-air and depth information as inputs to generate underwater images for robotics in deep ocean scenarios. Compared to shallow water conditions, active lighting is required to illuminate the scene in deep sea. Our radiometric image formation model considers both attenuation and scattering effects with co-moving light sources in the dark. Additionally, we also incorporate geometric distortion (refraction), which is caused by thick glass housings commonly employed in deep sea conditions. By detailed analysis and evaluation of the underwater image formation model, we propose a 3D lookup table structure in combination with a novel rendering strategy to improve simulation performance, which enables us to integrate and implement interactive deep sea robotic vision simulation in the Gazebo-based Unmanned Underwater Vehicles simulator.

Light Pose Calibration for Camera-light Vision Systems

Illuminating a scene with artificial light is a prerequisite for seeing in dark environments. However, nonuniform and dynamic illumination can deteriorate or even break computer vision approaches, for instance when operating a robot with headlights in the darkness. This paper presents a novel light calibration approach by taking multi-view and -distance images of a reference plane in order to provide pose information of the employed light sources to the computer vision system. By following a physical light propagation approach, under consideration of energy preservation, the estimation of light poses is solved by minimizing of the differences between real and rendered pixel intensities. During the evaluation we show the robustness and consistency of this method by statistically analyzing the light pose estimation results with different setups. Although the results are demonstrated using a rotationally-symmetric non-isotropic light, the method is suited also for non-symmetric lights.
