Low-Complexity Detection of Multiple Preambles in the Presence of Mobility and Delay Spread

Current wireless infrastructure is optimized to support downlink applications. This paper anticipates the emergence of applications where engineering focus shifts from downlink to uplink. The current paradigm of scheduling users on reserved uplink resources is not able to deal efficiently with unpredictable traffic patterns. As a result, 3GPP introduced the 2-step RACH as a mechanism to enable grant-free (random) initial access. The first of the two steps is preamble detection in a RACH slot, and in this paper we describe a low-complexity algorithm for simultaneous detection of multiple preambles in the presence of mobility and delay spread. We provide a pathway to standards adoption by choosing ZC sequences as preambles, as ZC sequences already appear in 5G standards. We construct preambles by using the discrete Zak transform to pass from a ZC sequence of length MN in the TD to a quasi-periodic MxN array in the DD domain. There are MN quasi-periodic Dirac pulses, each corresponding to a Zak-OTFS carrier waveform, and the ZC preamble is simply the corresponding sum of Zak-OTFS carrier waveforms. We detect multiple preambles in the presence of mobility and delay spread by sampling the received signal on the MxN period grid in the DD domain. We approach detection as a compressed sensing problem. We represent a preamble as a column of length MN in the DD domain and apply discrete shifts in delay and Doppler to produce a block with O(MN) columns in the compressed sensing matrix. The superposition of multiple preambles determines a block sparse sum of columns in the sensing matrix. The correlation properties of ZC sequences result in a highly structured compressed sensing matrix, making it possible to identify constituent preambles using OST, which has complexity O(M^3N^3). In this paper, we describe an algorithm with complexity that is O(M^2N^2) in the size of an individual column.

Delay-Doppler Signal Processing with Zadoff-Chu Sequences

Much of the engineering behind current wireless systems has focused on designing an efficient and high-throughput downlink to support human-centric communication such as video streaming and internet browsing. This paper looks ahead to design of the uplink, anticipating the emergence of machine-type communication (MTC) and the confluence of sensing, communication, and distributed learning. We demonstrate that grant-free multiple access is possible even in the presence of highly time-varying channels. Our approach provides a pathway to standards adoption, since it is built on enhancing the 2-step random access procedure which is already part of the 5GNR standard. This 2-step procedure uses Zadoff-Chu (ZC) sequences as preambles that point to radio resources which are then used to upload data. We also use ZC sequences as preambles / pilots, but we process signals in the Delay-Doppler (DD) domain rather than the time-domain. We demonstrate that it is possible to detect multiple preambles in the presence of mobility and delay spread using a receiver with no knowledge of the channel other than the worst case delay and Doppler spreads. Our approach depends on the mathematical properties of ZC sequences in the DD domain. We derive a closed form expression for ZC pilots in the DD domain, we characterize the possible self-ambiguity functions, and we determine the magnitude of the possible cross-ambiguity functions. These mathematical properties enable detection of multiple pilots through solution of a compressed sensing problem. The columns of the compressed sensing matrix are the translates of individual ZC pilots in delay and Doppler. We show that columns in the design matrix satisfy a coherence property that makes it possible to detect multiple preambles in a single Zak-OTFS subframe using One-Step Thresholding (OST), which is an algorithm with low complexity.

Zak-OTFS and LDPC Codes

Orthogonal Time Frequency Space (OTFS) is a framework for communications and active sensing that processes signals in the delay-Doppler (DD) domain. It is informed by 6G propagation environments, where Doppler spreads measured in kHz make it more and more difficult to estimate channels, and the standard model-dependent approach to wireless communication is starting to break down. We consider Zak-OTFS where inverse Zak transform converts information symbols mounted on DD domain pulses to the time domain for transmission. Zak-OTFS modulation is parameterized by a delay period $\tau_{p}$ and a Doppler period $\nu_{p}$, where the product $\tau_{p}\nu_{p}=1$. When the channel spread is less than the delay period, and the Doppler spread is less than the Doppler period, the Zak-OTFS input-output relation can be predicted from the response to a single pilot symbol. The highly reliable channel estimates concentrate around the pilot location, and we configure low-density parity-check (LDPC) codes that take advantage of this prior information about reliability. It is advantageous to allocate information symbols to more reliable bins in the DD domain. We report simulation results for a Veh-A channel model where it is not possible to resolve all the paths, showing that LDPC coding extends the range of Doppler spreads for which reliable model-free communication is possible. We show that LDPC coding reduces sensitivity to the choice of transmit filter, making bandwidth expansion less necessary. Finally, we compare BER performance of Zak-OTFS to that of a multicarrier approximation (MC-OTFS), showing LDPC coding amplifies the gains previously reported for uncoded transmission.

Spectral Efficiency of OTFS Based Orthogonal Multiple Access with Rectangular Pulses

In this paper we consider Orthogonal Time Frequency Space (OTFS) modulation based multiple-access (MA). We specifically consider Orthogonal MA methods (OMA) where the user terminals (UTs) are allocated non-overlapping physical resource in the delay-Doppler (DD) and/or time-frequency (TF) domain. To the best of our knowledge, in prior literature, the performance of OMA methods have been reported only for ideal transmit and receive pulses. In [20] and [21], OMA methods were proposed which were shown to achieve multi-user interference (MUI) free communication with ideal pulses. Since ideal pulses are not realizable, in this paper we study the spectral efficiency (SE) performance of these OMA methods with practical rectangular pulses. For these OMA methods, we derive the expression for the received DD domain symbols at the base station (BS) receiver and the effective DD domain channel matrix when rectangular pulses are used. We then derive the expression for the achievable sum SE. These expressions are also derived for another well known OMA method where guard bands (GB) are used to reduce MUI (called as the GB based MA methods) [19]. Through simulations, we observe that with rectangular pulses the sum SE achieved by the method in [21] is almost invariant of the Doppler shift and is higher than that achieved by the methods in [19], [20] at practical values of the received signal-to-noise ratio.
