Low-Complexity Detection of Multiple Preambles in the Presence of Mobility and Delay Spread

Current wireless infrastructure is optimized to support downlink applications. This paper anticipates the emergence of applications where engineering focus shifts from downlink to uplink. The current paradigm of scheduling users on reserved uplink resources is not able to deal efficiently with unpredictable traffic patterns. As a result, 3GPP introduced the 2-step RACH as a mechanism to enable grant-free (random) initial access. The first of the two steps is preamble detection in a RACH slot, and in this paper we describe a low-complexity algorithm for simultaneous detection of multiple preambles in the presence of mobility and delay spread. We provide a pathway to standards adoption by choosing ZC sequences as preambles, as ZC sequences already appear in 5G standards. We construct preambles by using the discrete Zak transform to pass from a ZC sequence of length MN in the TD to a quasi-periodic MxN array in the DD domain. There are MN quasi-periodic Dirac pulses, each corresponding to a Zak-OTFS carrier waveform, and the ZC preamble is simply the corresponding sum of Zak-OTFS carrier waveforms. We detect multiple preambles in the presence of mobility and delay spread by sampling the received signal on the MxN period grid in the DD domain. We approach detection as a compressed sensing problem. We represent a preamble as a column of length MN in the DD domain and apply discrete shifts in delay and Doppler to produce a block with O(MN) columns in the compressed sensing matrix. The superposition of multiple preambles determines a block sparse sum of columns in the sensing matrix. The correlation properties of ZC sequences result in a highly structured compressed sensing matrix, making it possible to identify constituent preambles using OST, which has complexity O(M^3N^3). In this paper, we describe an algorithm with complexity that is O(M^2N^2) in the size of an individual column.

Delay-Doppler Signal Processing with Zadoff-Chu Sequences

Much of the engineering behind current wireless systems has focused on designing an efficient and high-throughput downlink to support human-centric communication such as video streaming and internet browsing. This paper looks ahead to design of the uplink, anticipating the emergence of machine-type communication (MTC) and the confluence of sensing, communication, and distributed learning. We demonstrate that grant-free multiple access is possible even in the presence of highly time-varying channels. Our approach provides a pathway to standards adoption, since it is built on enhancing the 2-step random access procedure which is already part of the 5GNR standard. This 2-step procedure uses Zadoff-Chu (ZC) sequences as preambles that point to radio resources which are then used to upload data. We also use ZC sequences as preambles / pilots, but we process signals in the Delay-Doppler (DD) domain rather than the time-domain. We demonstrate that it is possible to detect multiple preambles in the presence of mobility and delay spread using a receiver with no knowledge of the channel other than the worst case delay and Doppler spreads. Our approach depends on the mathematical properties of ZC sequences in the DD domain. We derive a closed form expression for ZC pilots in the DD domain, we characterize the possible self-ambiguity functions, and we determine the magnitude of the possible cross-ambiguity functions. These mathematical properties enable detection of multiple pilots through solution of a compressed sensing problem. The columns of the compressed sensing matrix are the translates of individual ZC pilots in delay and Doppler. We show that columns in the design matrix satisfy a coherence property that makes it possible to detect multiple preambles in a single Zak-OTFS subframe using One-Step Thresholding (OST), which is an algorithm with low complexity.

On the Bit Error Performance of OTFS Modulation using Discrete Zak Transform

In orthogonal time frequency space (OTFS) modulation, Zak transform approach is a natural approach for converting information symbols multiplexed in the DD domain directly to time domain for transmission, and vice versa at the receiver. Past research on OTFS has primarily considered a two-step approach where DD domain symbols are first converted to time-frequency domain which are then converted to time domain for transmission, and vice versa at the receiver. The Zak transform approach can offer performance and complexity benefits compared to the two-step approach. This paper presents an early investigation on the bit error performance of OTFS realized using discrete Zak transform (DZT). We develop a compact DD domain input-output relation for DZT-OTFS using matrix decomposition that is valid for both integer and fractional delay-Dopplers. We analyze the bit error performance of DZT-OTFS using pairwise error probability analysis and simulations. Simulation results show that 1) both DZT-OTFS and two-step OTFS perform better than OFDM, and 2) DZT-OTFS achieves better performance compared to two-step OTFS over a wide range of Doppler spreads.

Learning based Channel Estimation and Phase Noise Compensation in Doubly-Selective Channels

In this letter, we propose a learning based channel estimation scheme for orthogonal frequency division multiplexing (OFDM) systems in the presence of phase noise in doubly-selective fading channels. Two-dimensional (2D) convolutional neural networks (CNNs) are employed for effective training and tracking of channel variation in both frequency as well as time domain. The proposed network learns and estimates the channel coefficients in the entire time-frequency (TF) grid based on pilots sparsely populated in the TF grid. In order to make the network robust to phase noise (PN) impairment, a novel training scheme where the training data is rotated by random phases before being fed to the network is employed. Further, using the estimated channel coefficients, a simple and effective PN estimation and compensation scheme is devised. Numerical results demonstrate that the proposed network and PN compensation scheme achieve robust OFDM performance in the presence of phase noise.

Deep Channel Prediction: A DNN Framework for Receiver Design in Time-Varying Fading Channels

In time-varying fading channels, channel coefficients are estimated using pilot symbols that are transmitted every coherence interval. For channels with high Doppler spread, the rapid channel variations over time will require considerable bandwidth for pilot transmission, leading to poor throughput. In this paper, we propose a novel receiver architecture using deep recurrent neural networks (RNNs) that learns the channel variations and thereby reduces the number of pilot symbols required for channel estimation. Specifically, we design and train an RNN to learn the correlation in the time-varying channel and predict the channel coefficients into the future with good accuracy over a wide range of Dopplers and signal-to-noise ratios (SNR). The proposed training methodology enables accurate channel prediction through the use of techniques such as teacher-force training, early-stop, and reduction of learning rate on plateau. Also, the robustness of prediction for different Dopplers and SNRs is achieved by adapting the number of predictions into the future based on the Doppler and SNR. Numerical results show that good bit error performance is achieved by the proposed receiver in time-varying fading channels. We also propose a data decision driven receiver architecture using RNNs that further reduces the pilot overhead while maintaining good bit error performance.
