Flexible fast-convolution processing for cellular radio evolution

Orthogonal frequency-division multiplexing (OFDM) has been selected as a baseline waveform for long-term evolution (LTE) and fifth-generation new radio (5G NR). Fast-convolution (FC)-based frequency-domain signal processing has been considered recently as an effective tool for spectrum enhancement of OFDM-based waveforms. FC-based filtering approximates linear convolution by effective fast Fourier transform (FFT)-based circular convolutions using partly overlapping processing blocks. In earlier work, we have shown that FC-based filtering is a very flexible and efficient tool for filtered-OFDM signal generation and receiver side subband filtering. In this paper, we present a symbol-synchronous FC-processing scheme flexibly allowing filter re-configuration time resolution equal to one OFDM symbol while supporting tight carrier-wise filtering for 5G NR in mixed-numerology scenarios with adjustable subcarrier spacings, center frequencies, and subband bandwidths as well as providing co-exitence with LTE. The proposed scheme is demonstrated to support envisioned use cases of 5G NR and provide flexible starting point for sixth generation development.

Phase Noise Resilient Three-Level Continuous-Phase Modulation for DFT-Spread OFDM

A novel OFDM-based waveform with low peak-to-average power ratio (PAPR) and high robustness against phase noise (PN) is presented. It follows the discrete Fourier transform spread orthogonal frequency division multiplexing (DFT-s-OFDM) signal model. 3MSK, is inspired by continuous-phase frequency shift keying (FSK), but it uses three frequencies in the baseband model -- specifically, 0 and $\pm f_{symbol}/4$, where $f_{symbol}$ is the symbol rate -- which effectively constrains the phase transitions between consecutive symbols to 0 and $\pm \pi/2$ rad. Motivated by the phase controlled model of modulation, different degrees of phase continuity can be achieved, while supporting receiver processing with low complexity. The signal characteristics are improved by generating an initial time-domain nearly constant envelope signal at higher than the symbol rate. This helps to reach smooth phase transitions between 3MSK symbols. Also the possibility of using excess bandwidth is investigated by transmitting additional non-zero subcarriers outside active subcarriers of the basic DFT-s-OFDM model, which provides the capability to greatly reduce the PAPR. Due to the fact that the information is encoded in the phase transitions, a receiver model that tracks the phase variations without needing reference signals is developed. To this end, it is shown that this new modulation is well-suited for non-coherent receivers, even under strong phase noise (PN) conditions, thus allowing to reduce the overhead of reference signals. Evaluations of this physical-layer modulation and waveform scheme are performed in terms of transmitter metrics such as PAPR, OOB emissions and achievable output power after the power amplifier (PA). Finally, coded radio link evaluations are also shown and provided, demonstrating that 3MSK has a similar BER performance as that of traditional QPSK.

Joint Positioning and Tracking via NR Sidelink in 5G-Empowered Industrial IoT

The fifth generation (5G) mobile networks with enhanced connectivity and positioning capabilities play an increasingly important role in the development of autonomous and other advanced industrial systems. In this article, we address the prospects of 5G New Radio (NR) sidelink based ad-hoc networks and their applicability for increasing the situational awareness, in terms of continuous tracking of moving connected machines and vehicles, in industrial systems. For increased system flexibility and fast deployments, we assume that the locations of the so-called anchor nodes are unknown, and describe an extended Kalman filter-based joint positioning and tracking framework in which the locations of both the anchor nodes and the target nodes can be estimated simultaneously. We assess and demonstrate the achievable 3D positioning and tracking performance in the context of a realistic industrial warehouse facility, through extensive ray-tracing based evaluations at the 26 GHz NR band. Our findings show that when both angle-based and time-based measurements are utilized, reaching sub-1 meter accuracy is realistic and that the system is also relatively robust against different node geometries. Finally, several research challenges towards achieving robust, high-performance and cost-efficient positioning solutions are outlined and discussed, identifying various potential directions for future work.
