Upper Mid-Band Channel Measurements and Characterization at 6.75 GHz FR1(C) and 16.95 GHz FR3 in an Indoor Factory Scenario

This paper presents detailed radio propagation measurements for an indoor factory (InF) environment at 6.75 GHz and 16.95 GHz using a 1 GHz bandwidth channel sounder. Conducted at the NYU MakerSpace in the NYU Tandon School of Engineering campus in Brooklyn, NY, USA, our measurement campaign characterizes a representative small factory with diverse machinery and open workspaces across 12 locations, comprising 5 line-of-sight (LOS) and 7 non-line-of-sight (NLOS) scenarios. Analysis using the close-in (CI) path loss model with a 1 m reference distance reveals path loss exponents (PLE) below 2 in LOS at 6.75 GHz and 16.95 GHz, while in NLOS PLE is similar to free-space propagation. The RMS delay spread (DS) decreases at higher frequencies with a clear frequency dependence. Similarly, RMS angular spread (AS) measurements show wider spreads in NLOS compared to LOS at both frequency bands, with a decreasing trend as frequency increases. These observations in a dense-scatterer environment demonstrate frequency-dependent behavior that deviate from existing industry-standard models. Our findings provide crucial insights into complex propagation mechanisms in factory environments, essential for designing robust industrial wireless networks at upper mid-band frequencies.

Statistical Radar Cross Section Characterization for Indoor Factory Targets

In this work, we statistically analyze the radar cross section (RCS) of different test targets present in an indoor factory (InF) scenario specified by 3rd Generation Partnership Project considering bistatic configuration. The test targets that we consider are drones, humans, quadruped robot and a robotic arm. We consider two drones of different sizes and five human subjects for RCS characterization. For the drones, we measure the RCS when they are are flying over a given point and while they are rotating over the same point. For human subjects, we measure the RCS while standing still, sitting still and walking. For quadruped robot and robotic arm, we consider a continuous random motion emulating different tasks which they are supposed to perfom in typical InF scenario. We employ different distributions, such as Normal, Lognormal, Gamma, Rician, Weibull, Rayleigh and Exponential to fit the measurement data. From the statistical analysis, we gather that Lognormal distribution can fit all the considered targets in the InF scenario.

Urban Outdoor Propagation Measurements and Channel Models at 6.75 GHz FR1(C) and 16.95 GHz FR3 Upper Mid-Band Spectrum for 5G and 6G

Global allocations in the upper mid-band spectrum (4-24 GHz) necessitate a comprehensive exploration of the propagation behavior to meet the promise of coverage and capacity. This paper presents an extensive Urban Microcell (UMi) outdoor propagation measurement campaign at 6.75 GHz and 16.95 GHz conducted in Downtown Brooklyn, USA, using a 1 GHz bandwidth sliding correlation channel sounder over 40-880 m propagation distance, encompassing 6 Line of Sight (LOS) and 14 Non-Line of Sight (NLOS) locations. Analysis of the path loss (PL) reveals lower directional and omnidirectional PL exponents compared to mmWave and sub-THz frequencies in the UMi environment, using the close-in PL model with a 1 m reference distance. Additionally, a decreasing trend in root mean square (RMS) delay spread (DS) and angular spread (AS) with increasing frequency was observed. The NLOS RMS DS and RMS AS mean values are obtained consistently lower compared to 3GPP model predictions. Point data for all measured statistics at each TX-RX location are provided to supplement the models and results. The spatio-temporal statistics evaluated here offer valuable insights for the design of next-generation wireless systems and networks.

Propagation measurements and channel models in Indoor Environment at 6.75 GHz FR1(C) and 16.95 GHz FR3 Upper-mid band Spectrum for 5G and 6G

New spectrum allocations in the 4--8 GHz FR1(C) and 7--24 GHz FR3 mid-band frequency spectrum are being considered for 5G/6G cellular deployments. This paper presents results from the world's first comprehensive indoor hotspot (InH) propagation measurement campaign at 6.75 GHz and 16.95 GHz in the NYU WIRELESS Research Center using a 1 GHz wideband channel sounder system over distances from 11 to 97 m in line-of-sight (LOS) and non-LOS (NLOS). Analysis of directional and omnidirectional path loss (PL) using the close-in free space 1 m reference distance model shows a familiar waveguiding effect in LOS with an omnidirectional path loss exponent (PLE) of 1.40 at 6.75 GHz and 1.32 at 16.95 GHz. Compared to mmWave frequencies, the directional NLOS PLEs are lower at FR3 and FR1(C), while omnidirectional NLOS PLEs are similar, suggesting better propagation distances at lower frequencies for links with omnidirectional antennas at both ends of the links, but also, importantly, showing that higher gain antennas will offer better coverage at higher frequencies when antenna apertures are kept same over all frequencies. Comparison of the omnidirectional and directional RMS delay spread (DS) at FR1(C) and FR3 with mmWave frequencies indicates a clear decrease with increasing frequency. The mean spatial lobe and omnidirectional RMS angular spread (AS) is found to be wider at 6.75 GHz compared to 16.95 GHz indicating more multipath components are found in the azimuthal spatial domain at lower frequencies.

Wideband Penetration Loss through Building Materials and Partitions at 6.75 GHz in FR1(C) and 16.95 GHz in the FR3 Upper Mid-band spectrum

The 4--8 GHz FR1(C) and 7--24 GHz upper mid-band FR3 spectrum are promising new 6G spectrum allocations being considered by the International Telecommunications Union (ITU) and major governments around the world. There is an urgent need to understand the propagation behavior and radio coverage, outage, and material penetration for the global mobile wireless industry in both indoor and outdoor environments in these emerging frequency bands. This work presents measurements and models that describe the penetration loss in co-polarized and cross-polarized antenna configurations, exhibited by common materials found inside buildings and on building perimeters, including concrete, low-emissivity glass, wood, doors, drywall, and whiteboard at 6.75 GHz and 16.95 GHz. Measurement results show consistent lower penetration loss at 6.75 GHz compared to 16.95 GHz for all ten materials measured for co and cross-polarized antennas at incidence. For instance, the low-emissivity glass wall presents 33.7 dB loss at 6.75 GHz, while presenting 42.3 dB loss at 16.95 GHz. Penetration loss at these frequencies is contrasted with measurements at sub-6 GHz, mmWave and sub-THz frequencies along with 3GPP material penetration loss models. The results provide critical knowledge for future 5G and 6G cellular system deployments as well as refinements for the 3GPP material penetration models.

Waste Factor: A New Metric for Evaluating Power Efficiency in any Cascade

In this paper, we expand upon a new metric called the Waste Factor ($W$), a mathematical framework used to evaluate power efficiency in cascaded communication systems, by accounting for power wasted in individual components along a cascade. We show that the derivation of the Waste Factor, a unifying metric for defining wasted power along the signal path of any cascade, is similar to the mathematical approach used by H. Friis in 1944 to develop the Noise Factor ($F$), which has since served as a unifying metric for quantifying additive noise power in a cascade. Furthermore, the mathematical formulation of $W$ can be utilized in artificial intelligence (AI) and machine learning (ML) design and control for enhanced power efficiency. We consider the power usage effectiveness (PUE), which is a widely used energy efficiency metric for data centers, to evaluate $W$ for the data center as a whole. The use of $W$ allows easy comparison of power efficiency between data centers and their components. Our study further explores how insertion loss of components in a cascaded communication system influences $W$ at 28 GHz and 142 GHz along with the data rate performance, evaluated using the consumption efficiency factor (CEF). We observe CEF's marked sensitivity, particularly to phase shifter insertion loss changes. Notably, CEF variations are more prominent in uplink transmissions, whereas downlink transmissions offer relative CEF stability. Our exploration also covers the effects of varying User Equipment (UE) and Base Station (BS) deployment density on CEF in cellular networks. This work underscores the enhanced energy efficiency at 142 GHz, compared to 28 GHz, as UE and BS numbers escalate.

A Sub-Terahertz Sliding Correlator Channel Sounder with Absolute Timing using Precision Time Protocol over Wi-Fi

Radio channels at mmWave and sub-THz frequencies for 5G and 6G communications offer large channel bandwidths (hundreds of MHz to several GHz) to achieve multi-Gbps data rates. Accurate modeling of the radio channel for these wide bandwidths requires capturing the absolute timing of multipath component (MPC) propagation delays with sub-nanosecond accuracy. Achieving such timing accuracy is challenging due to clock drift in untethered transmitter (TX) and receiver (RX) clocks used in time-domain channel sounders, yet will become vital in many future 6G applications. This paper proposes a novel solution utilizing precision time protocol (PTP) and periodic drift correction to achieve absolute timing for MPCs in power delay profiles (PDPs) --captured as discrete samples using sliding correlation channel sounders. Two RaspberryPi computers are programmed to implement PTP over a dedicated Wi-Fi link and synchronize the TX and RX Rubidium clocks continuously every second. This synchronization minimizes clock drift, reducing PDP sample drift to 150 samples/hour, compared to several thousand samples/hour without synchronization. Additionally, a periodic drift correction algorithm is applied to eliminate PDP sample drift and achieve sub-nanosecond timing accuracy for MPC delays. The achieved synchronicity eliminates the need for tedious and sometimes inaccurate ray tracing to synthesize omnidirectional PDPs from directional measurements. The presented solution shows promise in myriad applications, including precise position location and distributed systems that require sub-nanosecond timing accuracy and synchronization among components.
