Introducing Learning Rate Adaptation CMA-ES into Rigid 2D/3D Registration for Robotic Navigation in Spine Surgery

The covariance matrix adaptive evolution strategy (CMA-ES) has been widely used in the field of 2D/3D registration in recent years. This optimization method exhibits exceptional robustness and usability for complex surgical scenarios. However, due to the inherent ill-posed nature of the 2D/3D registration task and the presence of numerous local minima in the landscape of similarity measures. Evolution strategies often require a larger population size in each generation in each generation to ensure the stability of registration and the globality and effectiveness of search, which makes the entire process computationally expensive. In this paper, we build a 2D/3D registration framework based on a learning rate adaptation CMA-ES manner. The framework employs a fixed and small population size, leading to minimized runtime and optimal utilization of computing resources. We conduct experimental comparisons between the proposed framework and other intensity-based baselines using a substantial volume of synthetic data. The results suggests that our method demonstrates superiority in both registration accuracy and running time. Code is available at github.com/m1nhengChen/CMAES-reg.

An Optimization-based Baseline for Rigid 2D/3D Registration Applied to Spine Surgical Navigation Using CMA-ES

A robust and efficient optimization-based 2D/3D registration framework is crucial for the navigation system of orthopedic surgical robots. It can provide precise position information of surgical instruments and implants during surgery. While artificial intelligence technology has advanced rapidly in recent years, traditional optimization-based registration methods remain indispensable in the field of 2D/3D registration.he exceptional precision of this method enables it to be considered as a post-processing step of the learning-based methods, thereby offering a reliable assurance for registration. In this paper, we present a coarse-to-fine registration framework based on the CMA-ES algorithm. We conducted intensive testing of our method using data from different parts of the spine. The results shows the effectiveness of the proposed framework on real orthopedic spine surgery clinical data. This work can be viewed as an additional extension that complements the optimization-based methods employed in our previous studies.

Fully Differentiable Correlation-driven 2D/3D Registration for X-ray to CT Image Fusion

Image-based rigid 2D/3D registration is a critical technique for fluoroscopic guided surgical interventions. In recent years, some learning-based fully differentiable methods have produced beneficial outcomes while the process of feature extraction and gradient flow transmission still lack controllability and interpretability. To alleviate these problems, in this work, we propose a novel fully differentiable correlation-driven network using a dual-branch CNN-transformer encoder which enables the network to extract and separate low-frequency global features from high-frequency local features. A correlation-driven loss is further proposed for low-frequency feature and high-frequency feature decomposition based on embedded information. Besides, a training strategy that learns to approximate a convex-shape similarity function is applied in our work. We test our approach on a in-house datasetand show that it outperforms both existing fully differentiable learning-based registration approaches and the conventional optimization-based baseline.

Embedded Feature Similarity Optimization with Specific Parameter Initialization for 2D/3D Registration

We present a novel deep learning-based framework: Embedded Feature Similarity Optimization with Specific Parameter Initialization (SOPI) for 2D/3D registration which is a most challenging problem due to the difficulty such as dimensional mismatch, heavy computation load and lack of golden evaluating standard. The framework we designed includes a parameter specification module to efficiently choose initialization pose parameter and a fine-registration network to align images. The proposed framework takes extracting multi-scale features into consideration using a novel composite connection encoder with special training techniques. The method is compared with both learning-based methods and optimization-based methods to further evaluate the performance. Our experiments demonstrate that the method in this paper has improved the registration performance, and thereby outperforms the existing methods in terms of accuracy and running time. We also show the potential of the proposed method as an initial pose estimator.
