Co-Designing Binarized Transformer and Hardware Accelerator for Efficient End-to-End Edge Deployment

Transformer models have revolutionized AI tasks, but their large size hinders real-world deployment on resource-constrained and latency-critical edge devices. While binarized Transformers offer a promising solution by significantly reducing model size, existing approaches suffer from algorithm-hardware mismatches with limited co-design exploration, leading to suboptimal performance on edge devices. Hence, we propose a co-design method for efficient end-to-end edge deployment of Transformers from three aspects: algorithm, hardware, and joint optimization. First, we propose BMT, a novel hardware-friendly binarized Transformer with optimized quantization methods and components, and we further enhance its model accuracy by leveraging the weighted ternary weight splitting training technique. Second, we develop a streaming processor mixed binarized Transformer accelerator, namely BAT, which is equipped with specialized units and scheduling pipelines for efficient inference of binarized Transformers. Finally, we co-optimize the algorithm and hardware through a design space exploration approach to achieve a global trade-off between accuracy, latency, and robustness for real-world deployments. Experimental results show our co-design achieves up to 2.14-49.37x throughput gains and 3.72-88.53x better energy efficiency over state-of-the-art Transformer accelerators, enabling efficient end-to-end edge deployment.

BETA: Binarized Energy-Efficient Transformer Accelerator at the Edge

Existing binary Transformers are promising in edge deployment due to their compact model size, low computational complexity, and considerable inference accuracy. However, deploying binary Transformers faces challenges on prior processors due to inefficient execution of quantized matrix multiplication (QMM) and the energy consumption overhead caused by multi-precision activations. To tackle the challenges above, we first develop a computation flow abstraction method for binary Transformers to improve QMM execution efficiency by optimizing the computation order. Furthermore, a binarized energy-efficient Transformer accelerator, namely BETA, is proposed to boost the efficient deployment at the edge. Notably, BETA features a configurable QMM engine, accommodating diverse activation precisions of binary Transformers and offering high-parallelism and high-speed for QMMs with impressive energy efficiency. Experimental results evaluated on ZCU102 FPGA show BETA achieves an average energy efficiency of 174 GOPS/W, which is 1.76~21.92x higher than prior FPGA-based accelerators, showing BETA's good potential for edge Transformer acceleration.
