PAPI-Reg: Patch-to-Pixel Solution for Efficient Cross-Modal Registration between LiDAR Point Cloud and Camera Image

The primary requirement for cross-modal data fusion is the precise alignment of data from different sensors. However, the calibration between LiDAR point clouds and camera images is typically time-consuming and needs external calibration board or specific environmental features. Cross-modal registration effectively solves this problem by aligning the data directly without requiring external calibration. However, due to the domain gap between the point cloud and the image, existing methods rarely achieve satisfactory registration accuracy while maintaining real-time performance. To address this issue, we propose a framework that projects point clouds into several 2D representations for matching with camera images, which not only leverages the geometric characteristic of LiDAR point clouds more effectively but also bridge the domain gap between the point cloud and image. Moreover, to tackle the challenges of cross modal differences and the limited overlap between LiDAR point clouds and images in the image matching task, we introduce a multi-scale feature extraction network to effectively extract features from both camera images and the projection maps of LiDAR point cloud. Additionally, we propose a patch-to-pixel matching network to provide more effective supervision and achieve higher accuracy. We validate the performance of our model through experiments on the KITTI and nuScenes datasets. Our network achieves real-time performance and extremely high registration accuracy. On the KITTI dataset, our model achieves a registration accuracy rate of over 99\%.

EdgeRegNet: Edge Feature-based Multimodal Registration Network between Images and LiDAR Point Clouds

Cross-modal data registration has long been a critical task in computer vision, with extensive applications in autonomous driving and robotics. Accurate and robust registration methods are essential for aligning data from different modalities, forming the foundation for multimodal sensor data fusion and enhancing perception systems' accuracy and reliability. The registration task between 2D images captured by cameras and 3D point clouds captured by Light Detection and Ranging (LiDAR) sensors is usually treated as a visual pose estimation problem. High-dimensional feature similarities from different modalities are leveraged to identify pixel-point correspondences, followed by pose estimation techniques using least squares methods. However, existing approaches often resort to downsampling the original point cloud and image data due to computational constraints, inevitably leading to a loss in precision. Additionally, high-dimensional features extracted using different feature extractors from various modalities require specific techniques to mitigate cross-modal differences for effective matching. To address these challenges, we propose a method that uses edge information from the original point clouds and images for cross-modal registration. We retain crucial information from the original data by extracting edge points and pixels, enhancing registration accuracy while maintaining computational efficiency. The use of edge points and edge pixels allows us to introduce an attention-based feature exchange block to eliminate cross-modal disparities. Furthermore, we incorporate an optimal matching layer to improve correspondence identification. We validate the accuracy of our method on the KITTI and nuScenes datasets, demonstrating its state-of-the-art performance.

EEPNet: Efficient Edge Pixel-based Matching Network for Cross-Modal Dynamic Registration between LiDAR and Camera

Multisensor fusion is essential for autonomous vehicles to accurately perceive, analyze, and plan their trajectories within complex environments. This typically involves the integration of data from LiDAR sensors and cameras, which necessitates high-precision and real-time registration. Current methods for registering LiDAR point clouds with images face significant challenges due to inherent modality differences and computational overhead. To address these issues, we propose EEPNet, an advanced network that leverages reflectance maps obtained from point cloud projections to enhance registration accuracy. The introduction of point cloud projections substantially mitigates cross-modality differences at the network input level, while the inclusion of reflectance data improves performance in scenarios with limited spatial information of point cloud within the camera's field of view. Furthermore, by employing edge pixels for feature matching and incorporating an efficient matching optimization layer, EEPNet markedly accelerates real-time registration tasks. Experimental validation demonstrates that EEPNet achieves superior accuracy and efficiency compared to state-of-the-art methods. Our contributions offer significant advancements in autonomous perception systems, paving the way for robust and efficient sensor fusion in real-world applications.
