HeGMN: Heterogeneous Graph Matching Network for Learning Graph Similarity

Graph similarity learning (GSL), also referred to as graph matching in many scenarios, is a fundamental problem in computer vision, pattern recognition, and graph learning. However, previous GSL methods assume that graphs are homogeneous and struggle to maintain their performance on heterogeneous graphs. To address this problem, this paper proposes a Heterogeneous Graph Matching Network (HeGMN), which is an end-to-end graph similarity learning framework composed of a two-tier matching mechanism. Firstly, a heterogeneous graph isomorphism network is proposed as the encoder, which reinvents graph isomorphism network for heterogeneous graphs by perceiving different semantic relationships during aggregation. Secondly, a graph-level and node-level matching modules are designed, both employing type-aligned matching principles. The former conducts graph-level matching by node type alignment, and the latter computes the interactions between the cross-graph nodes with the same type thus reducing noise interference and computational overhead. Finally, the graph-level and node-level matching features are combined and fed into fully connected layers for predicting graph similarity scores. In experiments, we propose a heterogeneous graph resampling method to construct heterogeneous graph pairs and define the corresponding heterogeneous graph edit distance, filling the gap in missing datasets. Extensive experiments demonstrate that HeGMN consistently achieves advanced performance on graph similarity prediction across all datasets.

SEGMN: A Structure-Enhanced Graph Matching Network for Graph Similarity Learning

Graph similarity computation (GSC) aims to quantify the similarity score between two graphs. Although recent GSC methods based on graph neural networks (GNNs) take advantage of intra-graph structures in message passing, few of them fully utilize the structures presented by edges to boost the representation of their connected nodes. Moreover, previous cross-graph node embedding matching lacks the perception of the overall structure of the graph pair, due to the fact that the node representations from GNNs are confined to the intra-graph structure, causing the unreasonable similarity score. Intuitively, the cross-graph structure represented in the assignment graph is helpful to rectify the inappropriate matching. Therefore, we propose a structure-enhanced graph matching network (SEGMN). Equipped with a dual embedding learning module and a structure perception matching module, SEGMN achieves structure enhancement in both embedding learning and cross-graph matching. The dual embedding learning module incorporates adjacent edge representation into each node to achieve a structure-enhanced representation. The structure perception matching module achieves cross-graph structure enhancement through assignment graph convolution. The similarity score of each cross-graph node pair can be rectified by aggregating messages from structurally relevant node pairs. Experimental results on benchmark datasets demonstrate that SEGMN outperforms the state-of-the-art GSC methods in the GED regression task, and the structure perception matching module is plug-and-play, which can further improve the performance of the baselines by up to 25%.
