Necessary and sufficient condition for a generic 3R serial manipulator to be cuspidal

Cuspidal robots can travel from one inverse kinematic solution to another without meeting a singularity. The name cuspidal was coined based on the existence of a cusp point in the workspace of 3R serial robots. The existence of a cusp point was proved to be a necessary and sufficient condition for orthogonal robots to be cuspidal, but it was not possible to extend this condition to non-orthogonal robots. The goal of this paper is to prove that this condition stands for any generic 3R robot. This result would give the designer more flexibility. In the presented work, the geometrical interpretation of the inverse kinematics of 3R robots is revisited and important observations on the nonsingular change of posture are noted. The paper presents a theorem regarding the existence of reduced aspects in any generic 3R serial robot. Based on these observations and on this theorem, we prove that the existence of a cusp point is a necessary and sufficient condition for any 3R generic robot to be cuspidal.

Inverse Kinematics of Some General 6R/P Manipulators

We develop an algorithm that solves the inverse kinematics of general serial 2RP3R, 2R2P2R, 3RP2R and 6R manipulators based on the HuPf algorithm. We identify the workspaces of the 3-subchains of the manipulator with a quasi-projective variety in $\mathbb{P}^7$ via dual quaternions. This allows us to compute linear forms that describe linear spaces containing the workspaces of these 3-subchains. We present numerical examples that illustrate the algorithm and show the real solutions.
