Guidelines for the Regularization of Gammas in Batch Normalization for Deep Residual Networks

L2 regularization for weights in neural networks is widely used as a standard training trick. However, L2 regularization for gamma, a trainable parameter of batch normalization, remains an undiscussed mystery and is applied in different ways depending on the library and practitioner. In this paper, we study whether L2 regularization for gamma is valid. To explore this issue, we consider two approaches: 1) variance control to make the residual network behave like identity mapping and 2) stable optimization through the improvement of effective learning rate. Through two analyses, we specify the desirable and undesirable gamma to apply L2 regularization and propose four guidelines for managing them. In several experiments, we observed the increase and decrease in performance caused by applying L2 regularization to gamma of four categories, which is consistent with our four guidelines. Our proposed guidelines were validated through various tasks and architectures, including variants of residual networks and transformers.

Improved Robustness of Vision Transformer via PreLayerNorm in Patch Embedding

Vision transformers (ViTs) have recently demonstrated state-of-the-art performance in a variety of vision tasks, replacing convolutional neural networks (CNNs). Meanwhile, since ViT has a different architecture than CNN, it may behave differently. To investigate the reliability of ViT, this paper studies the behavior and robustness of ViT. We compared the robustness of CNN and ViT by assuming various image corruptions that may appear in practical vision tasks. We confirmed that for most image transformations, ViT showed robustness comparable to CNN or more improved. However, for contrast enhancement, severe performance degradations were consistently observed in ViT. From a detailed analysis, we identified a potential problem: positional embedding in ViT's patch embedding could work improperly when the color scale changes. Here we claim the use of PreLayerNorm, a modified patch embedding structure to ensure scale-invariant behavior of ViT. ViT with PreLayerNorm showed improved robustness in various corruptions including contrast-varying environments.

Dead Pixel Test Using Effective Receptive Field

Deep neural networks have been used in various fields, but their internal behavior is not well known. In this study, we discuss two counterintuitive behaviors of convolutional neural networks (CNNs). First, we evaluated the size of the receptive field. Previous studies have attempted to increase or control the size of the receptive field. However, we observed that the size of the receptive field does not describe the classification accuracy. The size of the receptive field would be inappropriate for representing superiority in performance because it reflects only depth or kernel size and does not reflect other factors such as width or cardinality. Second, using the effective receptive field, we examined the pixels contributing to the output. Intuitively, each pixel is expected to equally contribute to the final output. However, we found that there exist pixels in a partially dead state with little contribution to the output. We reveal that the reason for this lies in the architecture of CNN and discuss solutions to reduce the phenomenon. Interestingly, for general classification tasks, the existence of dead pixels improves the training of CNNs. However, in a task that captures small perturbation, dead pixels degrade the performance. Therefore, the existence of these dead pixels should be understood and considered in practical applications of CNN.
