Modeling the Energy Consumption of HEVC Intra Decoding

Battery life is one of the major limitations to mobile device use, which makes research on energy efficient soft- and hardware an important task. This paper investigates the energy required by a CPU when decoding compressed bitstream videos on mobile platforms. A model is derived that describes the energy consumption of the new HEVC decoder for intra coded videos. We show that the relative estimation error of the model is smaller than 3.2% and that the model can be used to build encoders aiming at minimizing decoding energy.

Modeling the Energy Consumption of the HEVC Decoding Process

In this paper, we present a bit stream feature based energy model that accurately estimates the energy required to decode a given HEVC-coded bit stream. Therefore, we take a model from literature and extend it by explicitly modeling the inloop filters, which was not done before. Furthermore, to prove its superior estimation performance, it is compared to seven different energy models from literature. By using a unified evaluation framework we show how accurately the required decoding energy for different decoding systems can be approximated. We give thorough explanations on the model parameters and explain how the model variables are derived. To show the modeling capabilities in general, we test the estimation performance for different decoding software and hardware solutions, where we find that the proposed model outperforms the models from literature by reaching frame-wise mean estimation errors of less than 7% for software and less than 15% for hardware based systems.
