Joint Uplink-Downlink Capacity and Coverage Optimization via Site-Specific Learning of Antenna Settings

We propose a novel framework for optimizing antenna parameter settings in a heterogeneous cellular network. We formulate an optimization problem for both coverage and capacity - in both the downlink (DL) and uplink (UL) - which configures the tilt angle, vertical half-power beamwidth (HPBW), and horizontal HPBW of each cell's antenna array across the network. The novel data-driven framework proposed for this non-convex problem, inspired by Bayesian optimization (BO) and differential evolution algorithms, is sample-efficient and converges quickly, while being scalable to large networks. By jointly optimizing DL and UL performance, we take into account the different signal power and interference characteristics of these two links, allowing a graceful trade-off between coverage and capacity in each one. Our experiments on a state-of-the-art 5G NR cellular system-level simulator developed by AT&T Labs show that the proposed algorithm consistently and significantly outperforms the 3GPP default settings, random search, and conventional BO. In one realistic setting, and compared to conventional BO, our approach increases the average sum-log-rate by over 60% while decreasing the outage probability by over 80%. Compared to the 3GPP default settings, the gains from our approach are considerably larger. The results also indicate that the practically important combination of DL throughput and UL coverage can be greatly improved by joint UL-DL optimization.

Spatial and Statistical Modeling of Multi-Panel Millimeter Wave Self-Interference

Characterizing self-interference is essential to the design and evaluation of in-band full-duplex communication systems. Until now, little has been understood about this coupling in full-duplex systems operating at millimeter wave (mmWave) frequencies, and it has been shown that highly-idealized models proposed for such do not align with practice. This work presents the first spatial and statistical model of multi-panel mmWave self-interference backed by measurements, enabling engineers to draw realizations that exhibit the large-scale and small-scale spatial characteristics observed in our nearly 6.5 million measurements. Core to our model is its use of system and model parameters having real-world meaning, which facilitates the extension of our model to systems beyond our own phased array platform through proper parameterization. We demonstrate this by collecting nearly 13 million additional measurements to show that our model can generalize to two other system configurations. We assess our model by comparing it against actual measurements to confirm its ability to align spatially and in distribution with real-world self-interference. In addition, using both measurements and our model of self-interference, we evaluate an existing beamforming-based full-duplex mmWave solution to illustrate that our model can be reliably used to design new solutions and validate the performance improvements they may offer.

STEER: Beam Selection for Full-Duplex Millimeter Wave Communication Systems

Modern millimeter wave (mmWave) communication systems rely on beam alignment to deliver sufficient beamforming gain to close the link between devices. We present a novel beam selection methodology for multi-panel, full-duplex mmWave systems, which we call STEER, that delivers high beamforming gain while significantly reducing the full-duplex self-interference coupled between the transmit and receive beams. STEER does not necessitate changes to conventional beam alignment methodologies nor additional over-the-air feedback, making it compatible with existing cellular standards. Instead, STEER uses conventional beam alignment to identify the general directions beams should be steered, and then it makes use of a minimal number of self-interference measurements to jointly select transmit and receive beams that deliver high gain in these directions while coupling low self-interference. We implement STEER on an industry-grade 28 GHz phased array platform and use further simulation to show that full-duplex operation with beams selected by STEER can notably outperform both half-duplex and full-duplex operation with beams chosen via conventional beam selection. For instance, STEER can reliably reduce self-interference by more than 20 dB and improve SINR by more than 10 dB, compared to conventional beam selection. Our experimental results highlight that beam alignment can be used not only to deliver high beamforming gain in full-duplex mmWave systems but also to mitigate self-interference to levels near or below the noise floor, rendering additional self-interference cancellation unnecessary with STEER.

Beamformed Self-Interference Measurements at 28 GHz: Spatial Insights and Angular Spread

We present measurements and analysis of self-interference in multi-panel millimeter wave (mmWave) full-duplex communication systems at 28 GHz. In an anechoic chamber, we measure the self-interference power between the input of a transmitting phased array and the output of a colocated receiving phased array, each of which is electronically steered across a number of directions in azimuth and elevation. These self-interference power measurements shed light on the potential for a full-duplex communication system to successfully receive a desired signal while transmitting in-band. Our nearly 6.5 million measurements illustrate that more self-interference tends to be coupled when the transmitting and receiving phased arrays steer their beams toward one another but that slight shifts in steering direction (on the order of one degree) can lead to significant fluctuations in self-interference power. We analyze these measurements to characterize the spatial variability of self-interference to better quantify and statistically model this sensitivity. Our analyses and statistical results can be useful references when developing and evaluating mmWave full-duplex systems and motivate a variety of future topics including beam selection, beamforming codebook design, and self-interference channel modeling.

28 GHz Phased Array-Based Self-Interference Measurements for Millimeter Wave Full-Duplex

We present measurements of the 28 GHz self-interference channel for full-duplex sectorized multi-panel millimeter wave (mmWave) systems, such as integrated access and backhaul. We measure the isolation between the input of a transmitting phased array panel and the output of a co-located receiving phased array panel, each of which is electronically steered across a number of directions in azimuth and elevation. In total, nearly 6.5 million measurements were taken in an anechoic chamber to densely inspect the directional nature of the coupling between 256-element phased arrays. We observe that highly directional mmWave beams do not necessarily offer widespread high isolation between transmitting and receiving arrays. Rather, our measurements indicate that steering the transmitter or receiver away from the other tends to offer higher isolation but even slight steering changes can lead to drastic variations in isolation. These measurements can be useful references when developing mmWave full-duplex solutions and can motivate a variety of future topics including beam/user selection and beamforming codebook design.
