Capsule Networks for Protein Structure Classification and Prediction

Capsule Networks have great potential to tackle problems in structural biology because of their attention to hierarchical relationships. This paper describes the implementation and application of a Capsule Network architecture to the classification of RAS protein family structures on GPU-based computational resources. The proposed Capsule Network trained on 2D and 3D structural encodings can successfully classify HRAS and KRAS structures. The Capsule Network can also classify a protein-based dataset derived from a PSI-BLAST search on sequences of KRAS and HRAS mutations. Our results show an accuracy improvement compared to traditional convolutional networks, while improving interpretability through visualization of activation vectors.

A Spatial Mapping Algorithm with Applications in Deep Learning-Based Structure Classification

Convolutional Neural Network (CNN)-based machine learning systems have made breakthroughs in feature extraction and image recognition tasks in two dimensions (2D). Although there is significant ongoing work to apply CNN technology to domains involving complex 3D data, the success of such efforts has been constrained, in part, by limitations in data representation techniques. Most current approaches rely upon low-resolution 3D models, strategic limitation of scope in the 3D space, or the application of lossy projection techniques to allow for the use of 2D CNNs. To address this issue, we present a mapping algorithm that converts 3D structures to 2D and 1D data grids by mapping a traversal of a 3D space-filling curve to the traversal of corresponding 2D and 1D curves. We explore the performance of 2D and 1D CNNs trained on data encoded with our method versus comparable volumetric CNNs operating upon raw 3D data from a popular benchmarking dataset. Our experiments demonstrate that both 2D and 1D representations of 3D data generated via our method preserve a significant proportion of the 3D data's features in forms learnable by CNNs. Furthermore, we demonstrate that our method of encoding 3D data into lower-dimensional representations allows for decreased CNN training time cost, increased original 3D model rendering resolutions, and supports increased numbers of data channels when compared to purely volumetric approaches. This demonstration is accomplished in the context of a structural biology classification task wherein we train 3D, 2D, and 1D CNNs on examples of two homologous branches within the Ras protein family. The essential contribution of this paper is the introduction of a dimensionality-reduction method that may ease the application of powerful deep learning tools to domains characterized by complex structural data.
