Grounded Language Design for Lightweight Diagramming for Formal Methods

Model finding, as embodied by SAT solvers and similar tools, is used widely, both in embedding settings and as a tool in its own right. For instance, tools like Alloy target SAT to enable users to incrementally define, explore, verify, and diagnose sophisticated specifications for a large number of complex systems. These tools critically include a visualizer that lets users graphically explore these generated models. As we show, however, default visualizers, which know nothing about the domain, are unhelpful and even actively violate presentational and cognitive principles. At the other extreme, full-blown visualizations require significant effort as well as knowledge a specifier might not possess; they can also exhibit bad failure modes (including silent failure). Instead, we need a language to capture essential domain information for lightweight diagramming. We ground our language design in both the cognitive science literature on diagrams and on a large number of example custom visualizations. This identifies the key elements of lightweight diagrams. We distill these into a small set of orthogonal primitives. We extend an Alloy-like tool to support these primitives. We evaluate the effectiveness of the produced diagrams, finding them good for reasoning. We then compare this against many other drawing languages and tools to show that this work defines a new niche that is lightweight, effective, and driven by sound principles.

Large-Scale Intelligent Microservices

Deploying Machine Learning (ML) algorithms within databases is a challenge due to the varied computational footprints of modern ML algorithms and the myriad of database technologies each with their own restrictive syntax. We introduce an Apache Spark-based micro-service orchestration framework that extends database operations to include web service primitives. Our system can orchestrate web services across hundreds of machines and takes full advantage of cluster, thread, and asynchronous parallelism. Using this framework, we provide large scale clients for intelligent services such as speech, vision, search, anomaly detection, and text analysis. This allows users to integrate ready-to-use intelligence into any datastore with an Apache Spark connector. To eliminate the majority of overhead from network communication, we also introduce a low-latency containerized version of our architecture. Finally, we demonstrate that the services we investigate are competitive on a variety of benchmarks, and present two applications of this framework to create intelligent search engines, and real time auto race analytics systems.
