Efficient Reprogramming of Memristive Crossbars for DNNs: Weight Sorting and Bit Stucking

We introduce a novel approach to reduce the number of times required for reprogramming memristors on bit-sliced compute-in-memory crossbars for deep neural networks (DNNs). Our idea addresses the limited non-volatile memory endurance, which restrict the number of times they can be reprogrammed. To reduce reprogramming demands, we employ two techniques: (1) we organize weights into sorted sections to schedule reprogramming of similar crossbars, maximizing memristor state reuse, and (2) we reprogram only a fraction of randomly selected memristors in low-order columns, leveraging their bit-level distribution and recognizing their relatively small impact on model accuracy. We evaluate our approach for state-of-the-art models on the ImageNet-1K dataset. We demonstrate a substantial reduction in crossbar reprogramming by 3.7x for ResNet-50 and 21x for ViT-Base, while maintaining model accuracy within a 1% margin.

Sorted Weight Sectioning for Energy-Efficient Unstructured Sparse DNNs on Compute-in-Memory Crossbars

We introduce $\textit{sorted weight sectioning}$ (SWS): a weight allocation algorithm that places sorted deep neural network (DNN) weight sections on bit-sliced compute-in-memory (CIM) crossbars to reduce analog-to-digital converter (ADC) energy consumption. Data conversions are the most energy-intensive process in crossbar operation. SWS effectively reduces this cost leveraging (1) small weights and (2) zero weights (weight sparsity). DNN weights follow bell-shaped distributions, with most weights near zero. Using SWS, we only need low-order crossbar columns for sections with low-magnitude weights. This reduces the quantity and resolution of ADCs used, exponentially decreasing ADC energy costs without significantly degrading DNN accuracy. Unstructured sparsification further sharpens the weight distribution with small accuracy loss. However, it presents challenges in hardware tracking of zeros: we cannot switch zero rows to other layer weights in unsorted crossbars without index matching. SWS efficiently addresses unstructured sparse models using offline remapping of zeros into earlier sections, which reveals full sparsity potential and maximizes energy efficiency. Our method reduces ADC energy use by 89.5% on unstructured sparse BERT models. Overall, this paper introduces a novel algorithm to promote energy-efficient CIM crossbars for unstructured sparse DNN workloads.

Tiny Reinforcement Learning for Quadruped Locomotion using Decision Transformers

Resource-constrained robotic platforms are particularly useful for tasks that require low-cost hardware alternatives due to the risk of losing the robot, like in search-and-rescue applications, or the need for a large number of devices, like in swarm robotics. For this reason, it is crucial to find mechanisms for adapting reinforcement learning techniques to the constraints imposed by lower computational power and smaller memory capacities of these ultra low-cost robotic platforms. We try to address this need by proposing a method for making imitation learning deployable onto resource-constrained robotic platforms. Here we cast the imitation learning problem as a conditional sequence modeling task and we train a decision transformer using expert demonstrations augmented with a custom reward. Then, we compress the resulting generative model using software optimization schemes, including quantization and pruning. We test our method in simulation using Isaac Gym, a realistic physics simulation environment designed for reinforcement learning. We empirically demonstrate that our method achieves natural looking gaits for Bittle, a resource-constrained quadruped robot. We also run multiple simulations to show the effects of pruning and quantization on the performance of the model. Our results show that quantization (down to 4 bits) and pruning reduce model size by around 30\% while maintaining a competitive reward, making the model deployable in a resource-constrained system.
