Benchmarking Convolutional Neural Network and Graph Neural Network based Surrogate Models on a Real-World Car External Aerodynamics Dataset

Aerodynamic optimization is crucial for developing eco-friendly, aerodynamic, and stylish cars, which requires close collaboration between aerodynamicists and stylists, a collaboration impaired by the time-consuming nature of aerodynamic simulations. Surrogate models offer a viable solution to reduce this overhead, but they are untested in real-world aerodynamic datasets. We present a comparative evaluation of two surrogate modeling approaches for predicting drag on a real-world dataset: a Convolutional Neural Network (CNN) model that uses a signed distance field as input and a commercial tool based on Graph Neural Networks (GNN) that directly processes a surface mesh. In contrast to previous studies based on datasets created from parameterized geometries, our dataset comprises 343 geometries derived from 32 baseline vehicle geometries across five distinct car projects, reflecting the diverse, free-form modifications encountered in the typical vehicle development process. Our results show that the CNN-based method achieves a mean absolute error of 2.3 drag counts, while the GNN-based method achieves 3.8. Both methods achieve approximately 77% accuracy in predicting the direction of drag change relative to the baseline geometry. While both methods effectively capture the broader trends between baseline groups (set of samples derived from a single baseline geometry), they struggle to varying extents in capturing the finer intra-baseline group variations. In summary, our findings suggest that aerodynamicists can effectively use both methods to predict drag in under two minutes, which is at least 600 times faster than performing a simulation. However, there remains room for improvement in capturing the finer details of the geometry.

Hybrid neural network reduced order modelling for turbulent flows with geometric parameters

Geometrically parametrized Partial Differential Equations are nowadays widely used in many different fields as, for example, shape optimization processes or patient specific surgery studies. The focus of this work is on some advances for this topic, capable of increasing the accuracy with respect to previous approaches while relying on a high cost-benefit ratio performance. The main scope of this paper is the introduction of a new technique mixing up a classical Galerkin-projection approach together with a data-driven method to obtain a versatile and accurate algorithm for the resolution of geometrically parametrized incompressible turbulent Navier-Stokes problems. The effectiveness of this procedure is demonstrated on two different test cases: a classical academic back step problem and a shape deformation Ahmed body application. The results show into details the properties of the architecture we developed while exposing possible future perspectives for this work.
