SODA: Site Object Detection dAtaset for Deep Learning in Construction

Computer vision-based deep learning object detection algorithms have been developed sufficiently powerful to support the ability to recognize various objects. Although there are currently general datasets for object detection, there is still a lack of large-scale, open-source dataset for the construction industry, which limits the developments of object detection algorithms as they tend to be data-hungry. Therefore, this paper develops a new large-scale image dataset specifically collected and annotated for the construction site, called Site Object Detection dAtaset (SODA), which contains 15 kinds of object classes categorized by workers, materials, machines, and layout. Firstly, more than 20,000 images were collected from multiple construction sites in different site conditions, weather conditions, and construction phases, which covered different angles and perspectives. After careful screening and processing, 19,846 images including 286,201 objects were then obtained and annotated with labels in accordance with predefined categories. Statistical analysis shows that the developed dataset is advantageous in terms of diversity and volume. Further evaluation with two widely-adopted object detection algorithms based on deep learning (YOLO v3/ YOLO v4) also illustrates the feasibility of the dataset for typical construction scenarios, achieving a maximum mAP of 81.47%. In this manner, this research contributes a large-scale image dataset for the development of deep learning-based object detection methods in the construction industry and sets up a performance benchmark for further evaluation of corresponding algorithms in this area.
