ARTEMIS: A Mixed Analog-Stochastic In-DRAM Accelerator for Transformer Neural Networks

Transformers have emerged as a powerful tool for natural language processing (NLP) and computer vision. Through the attention mechanism, these models have exhibited remarkable performance gains when compared to conventional approaches like recurrent neural networks (RNNs) and convolutional neural networks (CNNs). Nevertheless, transformers typically demand substantial execution time due to their extensive computations and large memory footprint. Processing in-memory (PIM) and near-memory computing (NMC) are promising solutions to accelerating transformers as they offer high compute parallelism and memory bandwidth. However, designing PIM/NMC architectures to support the complex operations and massive amounts of data that need to be moved between layers in transformer neural networks remains a challenge. We propose ARTEMIS, a mixed analog-stochastic in-DRAM accelerator for transformer models. Through employing minimal changes to the conventional DRAM arrays, ARTEMIS efficiently alleviates the costs associated with transformer model execution by supporting stochastic computing for multiplications and temporal analog accumulations using a novel in-DRAM metal-on-metal capacitor. Our analysis indicates that ARTEMIS exhibits at least 3.0x speedup, 1.8x lower energy, and 1.9x better energy efficiency compared to GPU, TPU, CPU, and state-of-the-art PIM transformer hardware accelerators.

HEANA: A Hybrid Time-Amplitude Analog Optical Accelerator with Flexible Dataflows for Energy-Efficient CNN Inference

Several photonic microring resonators (MRRs) based analog accelerators have been proposed to accelerate the inference of integer-quantized CNNs with remarkably higher throughput and energy efficiency compared to their electronic counterparts. However, the existing analog photonic accelerators suffer from three shortcomings: (i) severe hampering of wavelength parallelism due to various crosstalk effects, (ii) inflexibility of supporting various dataflows other than the weight-stationary dataflow, and (iii) failure in fully leveraging the ability of photodetectors to perform in-situ accumulations. These shortcomings collectively hamper the performance and energy efficiency of prior accelerators. To tackle these shortcomings, we present a novel Hybrid timE Amplitude aNalog optical Accelerator, called HEANA. HEANA employs hybrid time-amplitude analog optical multipliers (TAOMs) that increase the flexibility of HEANA to support multiple dataflows. A spectrally hitless arrangement of TAOMs significantly reduces the crosstalk effects, thereby increasing the wavelength parallelism in HEANA. Moreover, HEANA employs our invented balanced photo-charge accumulators (BPCAs) that enable buffer-less, in-situ, temporal accumulations to eliminate the need to use reduction networks in HEANA, relieving it from related latency and energy overheads. Our evaluation for the inference of four modern CNNs indicates that HEANA provides improvements of atleast 66x and 84x in frames-per-second (FPS) and FPS/W (energy-efficiency), respectively, for equal-area comparisons, on gmean over two MRR-based analog CNN accelerators from prior work.

A Comparative Analysis of Microrings Based Incoherent Photonic GEMM Accelerators

Several microring resonator (MRR) based analog photonic architectures have been proposed to accelerate general matrix-matrix multiplications (GEMMs) in deep neural networks with exceptional throughput and energy efficiency. To implement GEMM functions, these MRR-based architectures, in general, manipulate optical signals in five different ways: (i) Splitting (copying) of multiple optical signals to achieve a certain fan-out, (ii) Aggregation (multiplexing) of multiple optical signals to achieve a certain fan-in, (iii) Modulation of optical signals to imprint input values onto analog signal amplitude, (iv) Weighting of modulated optical signals to achieve analog input-weight multiplication, (v) Summation of optical signals. The MRR-based GEMM accelerators undertake the first four ways of signal manipulation in an arbitrary order ignoring the possible impact of the order of these manipulations on their performance. In this paper, we conduct a detailed analysis of accelerator organizations with three different orders of these manipulations: (1) Modulation-Aggregation-Splitting-Weighting (MASW), (2) Aggregation-Splitting-Modulation-Weighting (ASMW), and (3) Splitting-Modulation-Weighting-Aggregation (SMWA). We show that these organizations affect the crosstalk noise and optical signal losses in different magnitudes, which renders these organizations with different levels of processing parallelism at the circuit level, and different magnitudes of throughput and energy-area efficiency at the system level. Our evaluation results for four CNN models show that SMWA organization achieves up to 4.4$\times$, 5$\times$, and 5.2$\times$ better throughput, energy efficiency, and area-energy efficiency, respectively, compared to ASMW and MASW organizations on average.

High-Speed and Energy-Efficient Non-Binary Computing with Polymorphic Electro-Optic Circuits and Architectures

In this paper, we present microring resonator (MRR) based polymorphic E-O circuits and architectures that can be employed for high-speed and energy-efficient non-binary reconfigurable computing. Our polymorphic E-O circuits can be dynamically programmed to implement different logic and arithmetic functions at different times. They can provide compactness and polymorphism to consequently improve operand handling, reduce idle time, and increase amortization of area and static power overheads. When combined with flexible photodetectors with the innate ability to accumulate a high number of optical pulses in situ, our circuits can support energy-efficient processing of data in non-binary formats such as stochastic/unary and high-dimensional reservoir formats. Furthermore, our polymorphic E-O circuits enable configurable E-O computing accelerator architectures for processing binarized and integer quantized convolutional neural networks (CNNs). We compare our designed polymorphic E-O circuits and architectures to several circuits and architectures from prior works in terms of area, latency, and energy consumption.

A Bit-Parallel Deterministic Stochastic Multiplier

This paper presents a novel bit-parallel deterministic stochastic multiplier, which improves the area-energy-latency product by up to 10.6$\times$10$^4$, while improving the computational error by 32.2\%, compared to three prior stochastic multipliers.

SCONNA: A Stochastic Computing Based Optical Accelerator for Ultra-Fast, Energy-Efficient Inference of Integer-Quantized CNNs

The acceleration of a CNN inference task uses convolution operations that are typically transformed into vector-dot-product (VDP) operations. Several photonic microring resonators (MRRs) based hardware architectures have been proposed to accelerate integer-quantized CNNs with remarkably higher throughput and energy efficiency compared to their electronic counterparts. However, the existing photonic MRR-based analog accelerators exhibit a very strong trade-off between the achievable input/weight precision and VDP operation size, which severely restricts their achievable VDP operation size for the quantized input/weight precision of 4 bits and higher. The restricted VDP operation size ultimately suppresses computing throughput to severely diminish the achievable performance benefits. To address this shortcoming, we for the first time present a merger of stochastic computing and MRR-based CNN accelerators. To leverage the innate precision flexibility of stochastic computing, we invent an MRR-based optical stochastic multiplier (OSM). We employ multiple OSMs in a cascaded manner using dense wavelength division multiplexing, to forge a novel Stochastic Computing based Optical Neural Network Accelerator (SCONNA). SCONNA achieves significantly high throughput and energy efficiency for accelerating inferences of high-precision quantized CNNs. Our evaluation for the inference of four modern CNNs at 8-bit input/weight precision indicates that SCONNA provides improvements of up to 66.5x, 90x, and 91x in frames-per-second (FPS), FPS/W and FPS/W/mm2, respectively, on average over two photonic MRR-based analog CNN accelerators from prior work, with Top-1 accuracy drop of only up to 0.4% for large CNNs and up to 1.5% for small CNNs. We developed a transaction-level, event-driven python-based simulator for the evaluation of SCONNA and other accelerators (https://github.com/uky-UCAT/SC_ONN_SIM.git).

An Optical XNOR-Bitcount Based Accelerator for Efficient Inference of Binary Neural Networks

Binary Neural Networks (BNNs) are increasingly preferred over full-precision Convolutional Neural Networks(CNNs) to reduce the memory and computational requirements of inference processing with minimal accuracy drop. BNNs convert CNN model parameters to 1-bit precision, allowing inference of BNNs to be processed with simple XNOR and bitcount operations. This makes BNNs amenable to hardware acceleration. Several photonic integrated circuits (PICs) based BNN accelerators have been proposed. Although these accelerators provide remarkably higher throughput and energy efficiency than their electronic counterparts, the utilized XNOR and bitcount circuits in these accelerators need to be further enhanced to improve their area, energy efficiency, and throughput. This paper aims to fulfill this need. For that, we invent a single-MRR-based optical XNOR gate (OXG). Moreover, we present a novel design of bitcount circuit which we refer to as Photo-Charge Accumulator (PCA). We employ multiple OXGs in a cascaded manner using dense wavelength division multiplexing (DWDM) and connect them to the PCA, to forge a novel Optical XNOR-Bitcount based Binary Neural Network Accelerator (OXBNN). Our evaluation for the inference of four modern BNNs indicates that OXBNN provides improvements of up to 62x and 7.6x in frames-per-second (FPS) and FPS/W (energy efficiency), respectively, on geometric mean over two PIC-based BNN accelerators from prior work. We developed a transaction-level, event-driven python-based simulator for evaluation of accelerators (https://github.com/uky-UCAT/B_ONN_SIM).

Silicon Photonic Microring Based Chip-Scale Accelerator for Delayed Feedback Reservoir Computing

To perform temporal and sequential machine learning tasks, the use of conventional Recurrent Neural Networks (RNNs) has been dwindling due to the training complexities of RNNs. To this end, accelerators for delayed feedback reservoir computing (DFRC) have attracted attention in lieu of RNNs, due to their simple hardware implementations. A typical implementation of a DFRC accelerator consists of a delay loop and a single nonlinear neuron, together acting as multiple virtual nodes for computing. In prior work, photonic DFRC accelerators have shown an undisputed advantage of fast computation over their electronic counterparts. In this paper, we propose a more energy-efficient chip-scale DFRC accelerator that employs a silicon photonic microring (MR) based nonlinear neuron along with on-chip photonic waveguides-based delayed feedback loop. Our evaluations show that, compared to a well-known photonic DFRC accelerator from prior work, our proposed MR-based DFRC accelerator achieves 35% and 98.7% lower normalized root mean square error (NRMSE), respectively, for the prediction tasks of NARMA10 and Santa Fe time series. In addition, our MR-based DFRC accelerator achieves 58.8% lower symbol error rate (SER) for the Non-Linear Channel Equalization task. Moreover, our MR-based DFRC accelerator has 98% and 93% faster training time, respectively, compared to an electronic and a photonic DFRC accelerators from prior work.
