Soft Two-degree-of-freedom Dielectric Elastomer Position Sensor Exhibiting Linear Behavior

Soft robots could bring robotic systems to new horizons, by enabling safe human-machine interaction. For precise control, these soft structures require high level position feedback that is not easily achieved through conventional one-degree-of-freedom (DOF) sensing apparatus. In this paper, a soft two-DOF dielectric elastomer (DE) sensor is specifically designed to provide accurate position feedback for a soft polymer robotic manipulator. The technology is exemplified on a soft robot intended for MRI-guided prostate interventions. DEs are chosen for their major advantages of softness, high strains, low cost and embedded multiple-DOF sensing capability, providing excellent system integration. A geometrical model of the proposed DE sensor is developed and compared to experimental results in order to understand sensor mechanics. Using a differential measurement approach, a handmade prototype provided linear sensory behavior and 0.2 mm accuracy on two-DOF. This correlates to a 0.7\% error over the sensor's 30 mm x 30 mm planar range, demonstrating the outstanding potential of DE technology for accurate multi-DOF position sensing.

A Soft Electronics-Free robot

Biomimetic entirely soft robots with animal-like behavior and integrated artificial nervous systems will open up totally new perspectives and applications. However, until now all presented studies on soft robots were limited to partly soft designs, since all designs at least needed conventional, stiff, electronics, to sense, process signals and activate actuators. We present the first soft robot with integrated artificial nervous system entirely made of dielectric elastomers - and without any conventional stiff electronic parts. Supplied with only one external DC voltage, the robot autonomously generates all signals necessary to drive its actuators, and translates an in-plane electromechanical oscillation into a crawling locomotion movement. Thereby, all functional parts are made of polymer materials and carbon. Besides the basic design of the world's first entirely soft robot we present prospects to control general behavior of such robots.
