A9 Intersection Dataset: All You Need for Urban 3D Camera-LiDAR Roadside Perception

Intelligent Transportation Systems (ITS) allow a drastic expansion of the visibility range and decrease occlusions for autonomous driving. To obtain accurate detections, detailed labeled sensor data for training is required. Unfortunately, high-quality 3D labels of LiDAR point clouds from the infrastructure perspective of an intersection are still rare. Therefore, we provide the A9 Intersection Dataset, which consists of labeled LiDAR point clouds and synchronized camera images. Here, we recorded the sensor output from two roadside cameras and LiDARs mounted on intersection gantry bridges. The point clouds were labeled in 3D by experienced annotators. Furthermore, we provide calibration data between all sensors, which allow the projection of the 3D labels into the camera images and an accurate data fusion. Our dataset consists of 4.8k images and point clouds with more than 57.4k manually labeled 3D boxes. With ten object classes, it has a high diversity of road users in complex driving maneuvers, such as left and right turns, overtaking, and U-turns. In experiments, we provided multiple baselines for the perception tasks. Overall, our dataset is a valuable contribution to the scientific community to perform complex 3D camera-LiDAR roadside perception tasks. Find data, code, and more information at https://a9-dataset.com.

InfraDet3D: Multi-Modal 3D Object Detection based on Roadside Infrastructure Camera and LiDAR Sensors

Current multi-modal object detection approaches focus on the vehicle domain and are limited in the perception range and the processing capabilities. Roadside sensor units (RSUs) introduce a new domain for perception systems and leverage altitude to observe traffic. Cameras and LiDARs mounted on gantry bridges increase the perception range and produce a full digital twin of the traffic. In this work, we introduce InfraDet3D, a multi-modal 3D object detector for roadside infrastructure sensors. We fuse two LiDARs using early fusion and further incorporate detections from monocular cameras to increase the robustness and to detect small objects. Our monocular 3D detection module uses HD maps to ground object yaw hypotheses, improving the final perception results. The perception framework is deployed on a real-world intersection that is part of the A9 Test Stretch in Munich, Germany. We perform several ablation studies and experiments and show that fusing two LiDARs with two cameras leads to an improvement of +1.90 mAP compared to a camera-only solution. We evaluate our results on the A9 infrastructure dataset and achieve 68.48 mAP on the test set. The dataset and code will be available at https://a9-dataset.com to allow the research community to further improve the perception results and make autonomous driving safer.
