GSG: A Granary Soft Gripper with Mechanical Force Sensing via 3-Dimensional Snap-Through Structure

Grasping is an essential capability for most robots in practical applications. Soft robotic grippers are considered as a critical part of robotic grasping and have attracted considerable attention in terms of the advantages of the high compliance and robustness to variance in object geometry; however, they are still limited by the corresponding sensing capabilities and actuation mechanisms. We propose a novel soft gripper that looks like a granary with a compliant snap-through bistable mechanism fabricated by integrated mold technology, achieving sensing and actuation purely mechanically. In particular, the snap-through bistable structure in the proposed gripper allows us to reduce the complexity of the mechanism, control, sensing designs since the grasping and sensing behaviors are completely passive. The grasping behaviors are automatically motivated once the trigger position of the gripper touches an object and applies sufficient force. To grasp objects with various profiles, the proposed granary soft gripper (GSG) is designed to be capable of enveloping, pinching and caging grasps. The gripper consists of a chamber palm, a palm cap and three fingers. First, the design of the gripper is analyzed. Then, after the theoretical model is constructed, finite element (FE) simulations are conducted to verify the built model. Finally, a series of grasping experiments is carried out to assess the snap-through behavior of the proposed gripper on grasping and sensing. The experimental results illustrate that the proposed gripper can manipulate a variety of soft and rigid objects and remain stable even though it undertakes external disturbances.

Index Modulation with Circularly-Shifted Chirps for Dual-Function Radar and Communications

In this study, we propose index modulation (IM) with circularly-shifted chirps (CSCs) (CSC-IM) for dual-function radar and communication (DFRC) systems. The proposed scheme encodes the information bits with the CSC indices and the phase-shift keying (PSK) symbols. It allows the receiver to exploit the frequency selectivity naturally in fading channels by combining IM and wideband CSCs. It also leverages the fact that a CSC is a constant-envelope signal to achieve a controllable peak-to-mean envelope power ratio (PMEPR). For radar functionality, CSC-IM maintains the good autocorrelation (AC) properties of a chirp by ensuring that the transmitted CSCs are separated apart sufficiently in the time domain through index separation (IS). We investigate the impact of IS on spectral efficiency (SE) and obtain the corresponding mapping functions. For theoretical results, we derive the union bound (UB) of the block error rate (BLER) for arbitrary chirps and the Cramer-Rao lower bounds (CRLBs) for the range and reflection coefficients for the matched filter (MF)-based estimation. We also prove that complementary sequences (CSs) can be constructed through CSCs by linearly combining the Fourier series of CSCs. Finally, through comprehensive comparisons, we demonstrate the efficacy of the proposed scheme for DFRC scenarios.
