Global Precipitation Nowcasting of Integrated Multi-satellitE Retrievals for GPM: A U-Net Convolutional LSTM Architecture

This paper presents a deep learning architecture for nowcasting of precipitation almost globally every 30 min with a 4-hour lead time. The architecture fuses a U-Net and a convolutional long short-term memory (LSTM) neural network and is trained using data from the Integrated MultisatellitE Retrievals for GPM (IMERG) and a few key precipitation drivers from the Global Forecast System (GFS). The impacts of different training loss functions, including the mean-squared error (regression) and the focal-loss (classification), on the quality of precipitation nowcasts are studied. The results indicate that the regression network performs well in capturing light precipitation (below 1.6 mm/hr), but the classification network can outperform the regression network for nowcasting of precipitation extremes (>8 mm/hr), in terms of the critical success index (CSI).. Using the Wasserstein distance, it is shown that the predicted precipitation by the classification network has a closer class probability distribution to the IMERG than the regression network. It is uncovered that the inclusion of the physical variables can improve precipitation nowcasting, especially at longer lead times in both networks. Taking IMERG as a relative reference, a multi-scale analysis in terms of fractions skill score (FSS), shows that the nowcasting machine remains skillful (FSS > 0.5) at the resolution of 10 km compared to 50 km for GFS. For precipitation rates greater than 4~mm/hr, only the classification network remains FSS-skillful on scales greater than 50 km within a 2-hour lead time.

Nowcasting-Nets: Deep Neural Network Structures for Precipitation Nowcasting Using IMERG

Accurate and timely estimation of precipitation is critical for issuing hazard warnings (e.g., for flash floods or landslides). Current remotely sensed precipitation products have a few hours of latency, associated with the acquisition and processing of satellite data. By applying a robust nowcasting system to these products, it is (in principle) possible to reduce this latency and improve their applicability, value, and impact. However, the development of such a system is complicated by the chaotic nature of the atmosphere, and the consequent rapid changes that can occur in the structures of precipitation systems In this work, we develop two approaches (hereafter referred to as Nowcasting-Nets) that use Recurrent and Convolutional deep neural network structures to address the challenge of precipitation nowcasting. A total of five models are trained using Global Precipitation Measurement (GPM) Integrated Multi-satellitE Retrievals for GPM (IMERG) precipitation data over the Eastern Contiguous United States (CONUS) and then tested against independent data for the Eastern and Western CONUS. The models were designed to provide forecasts with a lead time of up to 1.5 hours and, by using a feedback loop approach, the ability of the models to extend the forecast time to 4.5 hours was also investigated. Model performance was compared against the Random Forest (RF) and Linear Regression (LR) machine learning methods, and also against a persistence benchmark (BM) that used the most recent observation as the forecast. Independent IMERG observations were used as a reference, and experiments were conducted to examine both overall statistics and case studies involving specific precipitation events. Overall, the forecasts provided by the Nowcasting-Net models are superior, with the Convolutional Nowcasting Network with Residual Head (CNC-R) achieving 25%, 28%, and 46% improvement in the test ...
