An Experimental Study of Reduced-Voltage Operation in Modern FPGAs for Neural Network Acceleration

We empirically evaluate an undervolting technique, i.e., underscaling the circuit supply voltage below the nominal level, to improve the power-efficiency of Convolutional Neural Network (CNN) accelerators mapped to Field Programmable Gate Arrays (FPGAs). Undervolting below a safe voltage level can lead to timing faults due to excessive circuit latency increase. We evaluate the reliability-power trade-off for such accelerators. Specifically, we experimentally study the reduced-voltage operation of multiple components of real FPGAs, characterize the corresponding reliability behavior of CNN accelerators, propose techniques to minimize the drawbacks of reduced-voltage operation, and combine undervolting with architectural CNN optimization techniques, i.e., quantization and pruning. We investigate the effect of environmental temperature on the reliability-power trade-off of such accelerators. We perform experiments on three identical samples of modern Xilinx ZCU102 FPGA platforms with five state-of-the-art image classification CNN benchmarks. This approach allows us to study the effects of our undervolting technique for both software and hardware variability. We achieve more than 3X power-efficiency (GOPs/W) gain via undervolting. 2.6X of this gain is the result of eliminating the voltage guardband region, i.e., the safe voltage region below the nominal level that is set by FPGA vendor to ensure correct functionality in worst-case environmental and circuit conditions. 43% of the power-efficiency gain is due to further undervolting below the guardband, which comes at the cost of accuracy loss in the CNN accelerator. We evaluate an effective frequency underscaling technique that prevents this accuracy loss, and find that it reduces the power-efficiency gain from 43% to 25%.

TauRieL: Targeting Traveling Salesman Problem with a deep reinforcement learning inspired architecture

In this paper, we propose TauRieL and target Traveling Salesman Problem (TSP) since it has broad applicability in theoretical and applied sciences. TauRieL utilizes an actor-critic inspired architecture that adopts ordinary feedforward nets to obtain a policy update vector $v$. Then, we use $v$ to improve the state transition matrix from which we generate the policy. Also, the state transition matrix allows the solver to initialize from precomputed solutions such as nearest neighbors. In an online learning setting, TauRieL unifies the training and the search where it can generate near-optimal results in seconds. The input to the neural nets in the actor-critic architecture are raw 2-D inputs, and the design idea behind this decision is to keep neural nets relatively smaller than the architectures with wide embeddings with the tradeoff of omitting any distributed representations of the embeddings. Consequently, TauRieL generates TSP solutions two orders of magnitude faster per TSP instance as compared to state-of-the-art offline techniques with a performance impact of 6.1\% in the worst case.

Evaluating Built-in ECC of FPGA on-chip Memories for the Mitigation of Undervolting Faults

Voltage underscaling below the nominal level is an effective solution for improving energy efficiency in digital circuits, e.g., Field Programmable Gate Arrays (FPGAs). However, further undervolting below a safe voltage level and without accompanying frequency scaling leads to timing related faults, potentially undermining the energy savings. Through experimental voltage underscaling studies on commercial FPGAs, we observed that the rate of these faults exponentially increases for on-chip memories, or Block RAMs (BRAMs). To mitigate these faults, we evaluated the efficiency of the built-in Error-Correction Code (ECC) and observed that more than 90% of the faults are correctable and further 7% are detectable (but not correctable). This efficiency is the result of the single-bit type of these faults, which are then effectively covered by the Single-Error Correction and Double-Error Detection (SECDED) design of the built-in ECC. Finally, motivated by the above experimental observations, we evaluated an FPGA-based Neural Network (NN) accelerator under low-voltage operations, while built-in ECC is leveraged to mitigate undervolting faults and thus, prevent NN significant accuracy loss. In consequence, we achieve 40% of the BRAM power saving through undervolting below the minimum safe voltage level, with a negligible NN accuracy loss, thanks to the substantial fault coverage by the built-in ECC.
