Performance of a deep learning system for detection of referable diabetic retinopathy in real clinical settings

Background: To determine the ability of a commercially available deep learning system, RetCAD v.1.3.1 (Thirona, Nijmegen, The Netherlands) for the automatic detection of referable diabetic retinopathy (DR) on a dataset of colour fundus images acquired during routine clinical practice in a tertiary hospital screening program, analyzing the reduction of workload that can be released incorporating this artificial intelligence-based technology. Methods: Evaluation of the software was performed on a dataset of 7195 nonmydriatic fundus images from 6325 eyes of 3189 diabetic patients attending our screening program between February to December of 2019. The software generated a DR severity score for each colour fundus image which was combined into an eye-level score. This score was then compared with a reference standard as set by a human expert using receiver operating characteristic (ROC) curve analysis. Results: The artificial intelligence (AI) software achieved an area under the ROC curve (AUC) value of 0.988 [0.981:0.993] for the detection of referable DR. At the proposed operating point, the sensitivity of the RetCAD software for DR is 90.53% and specificity is 97.13%. A workload reduction of 96% could be achieved at the cost of only 6 false negatives. Conclusions: The AI software correctly identified the vast majority of referable DR cases, with a workload reduction of 96% of the cases that would need to be checked, while missing almost no true cases, so it may therefore be used as an instrument for triage.

Evaluation of a deep learning system for the joint automated detection of diabetic retinopathy and age-related macular degeneration

Purpose: To validate the performance of a commercially-available, CE-certified deep learning (DL) system, RetCAD v.1.3.0 (Thirona, Nijmegen, The Netherlands), for the joint automatic detection of diabetic retinopathy (DR) and age-related macular degeneration (AMD) in color fundus (CF) images on a dataset with mixed presence of eye diseases. Methods: Evaluation of joint detection of referable DR and AMD was performed on a DR-AMD dataset with 600 images acquired during routine clinical practice, containing referable and non-referable cases of both diseases. Each image was graded for DR and AMD by an experienced ophthalmologist to establish the reference standard (RS), and by four independent observers for comparison with human performance. Validation was furtherly assessed on Messidor (1200 images) for individual identification of referable DR, and the Age-Related Eye Disease Study (AREDS) dataset (133821 images) for referable AMD, against the corresponding RS. Results: Regarding joint validation on the DR-AMD dataset, the system achieved an area under the ROC curve (AUC) of 95.1% for detection of referable DR (SE=90.1%, SP=90.6%). For referable AMD, the AUC was 94.9% (SE=91.8%, SP=87.5%). Average human performance for DR was SE=61.5% and SP=97.8%; for AMD, SE=76.5% and SP=96.1%. Regarding detection of referable DR in Messidor, AUC was 97.5% (SE=92.0%, SP=92.1%); for referable AMD in AREDS, AUC was 92.7% (SE=85.8%, SP=86.0%). Conclusions: The validated system performs comparably to human experts at simultaneous detection of DR and AMD. This shows that DL systems can facilitate access to joint screening of eye diseases and become a quick and reliable support for ophthalmological experts.
