Modeling Basic Aspects of Cyber-Physical Systems, Part II

We continue to consider the question of what language features are needed to effectively model cyber-physical systems (CPS). In previous work, we proposed using a core language as a way to study this question, and showed how several basic aspects of CPS can be modeled clearly in a language with a small set of constructs. This paper reports on the result of our analysis of two, more complex, case studies from the domain of rigid body dynamics. The first one, a quadcopter, illustrates that previously proposed core language can support larger, more interesting systems than previously shown. The second one, a serial robot, provides a concrete example of why we should add language support for static partial derivatives, namely that it would significantly improve the way models of rigid body dynamics can be expressed.

Modeling Basic Aspects of Cyber-Physical Systems

Designing novel cyber-physical systems entails significant, costly physical experimentation. Simulation tools can enable the virtualization of experiments. Unfortunately, current tools have shortcomings that limit their utility for virtual experimentation. Language research can be especially helpful in addressing many of these problems. As a first step in this direction, we consider the question of determining what language features are needed to model cyber-physical systems. Using a series of elementary examples of cyber-physical systems, we reflect on the extent to which a small, experimental domain-specific formalism called Acumen suffices for this purpose.
