Affine invariant triangulations

We study affine invariant 2D triangulation methods. That is, methods that produce the same triangulation for a point set $S$ for any (unknown) affine transformation of $S$. Our work is based on a method by Nielson [A characterization of an affine invariant triangulation. Geom. Mod, 191-210. Springer, 1993] that uses the inverse of the covariance matrix of $S$ to define an affine invariant norm, denoted $A_{S}$, and an affine invariant triangulation, denoted ${DT}_{A_{S}}[S]$. We revisit the $A_{S}$-norm from a geometric perspective, and show that ${DT}_{A_{S}}[S]$ can be seen as a standard Delaunay triangulation of a transformed point set based on $S$. We prove that it retains all of its well-known properties such as being 1-tough, containing a perfect matching, and being a constant spanner of the complete geometric graph of $S$. We show that the $A_{S}$-norm extends to a hierarchy of related geometric structures such as the minimum spanning tree, nearest neighbor graph, Gabriel graph, relative neighborhood graph, and higher order versions of these graphs. In addition, we provide different affine invariant sorting methods of a point set $S$ and of the vertices of a polygon $P$ that can be combined with known algorithms to obtain other affine invariant triangulation methods of $S$ and of $P$.

The Shadows of a Cycle Cannot All Be Paths

A "shadow" of a subset $S$ of Euclidean space is an orthogonal projection of $S$ into one of the coordinate hyperplanes. In this paper we show that it is not possible for all three shadows of a cycle (i.e., a simple closed curve) in $\mathbb R^3$ to be paths (i.e., simple open curves). We also show two contrasting results: the three shadows of a path in $\mathbb R^3$ can all be cycles (although not all convex) and, for every $d\geq 1$, there exists a $d$-sphere embedded in $\mathbb R^{d+2}$ whose $d+2$ shadows have no holes (i.e., they deformation-retract onto a point).
