Coexistence of Mobile Broadband IMT Systems and UWB Keyless Entry Systems above 6.5 GHz

The ever-increasing need for spectrum for mobile broadband systems has led to the recent allocation of spectral resources for International Mobile Telecommunication (IMT) services in the upper mid band (6.425 - 7.125 GHz) at the World Radio Conference (WRC-23) as well as to the creation of an agenda item on identifying future IMT bands in the frequency region 7.125 - 10.5 GHz at WRC-27. The severity of the impact of these frequency allocations on existing UWB systems, which have been using this part of the spectrum as a sub-secondary user for many years, is still subject to controversial discussions. This paper contributes a study on the impact of IMT on a real-world vehicular UWB keyless entry system to this discussion. It is shown that both the car's wireless on-board unit and a nearby basestation may drastically affect the system's performance.

Antenna De-Embedding in FDTD Using Spherical Wave Functions by Exploiting Orthogonality

De-embedding antennas from the channel using Spherical Wave Functions (SWF) is a useful method to reduce the numerical effort in the simulation of wearable antennas. In this paper an analytical solution to the De-embedding problem is presented in form of surface integrals. This new integral solution is helpful on a theoretical level to derive insights and is also well suited for implementation in Finite Difference Time Domain (FDTD) numerical software. The spherical wave function coefficients are calculated directly from near-field values. Furthermore, the presence of a near-field scatterer in the de-embedding problem is discussed on a theoretical level based on the Huygens Equivalence Theorem. This makes it possible to exploit the degrees of freedom in such a way that it is sufficient to only use out-going spherical wave functions and still obtain correct results.

Antenna Optimization for WBAN Based on Spherical Wave Functions De-Embedding

Antennas for wireless body area networks (WBAN) need to be modeled with adapted methods because the coupling with the body tissue does not allow for a clear separation between antenna and channel. Especially for dynamically varying on-body channels due to changing body poses, e.g. with head-worn antennas, modeling is challenging and design goals for optimal antennas are difficult to determine. Therefore, in this paper, the modeling of WBAN channels using spherical wave functions (SWF) is utilized for antenna de-embedding and for deriving optimal antenna characteristics that maximize the transmission coefficient for the respective channel. It is evaluated how typical factors influencing WBAN channels (different body anatomies, body postures, and varying positions of the communication nodes), can be modeled statistically with SWF. An optimized antenna design is developed based on the derived optimization method, specifically adapted to the channel of on-body links with eye-wear applications. The results with the optimized antenna are compared to other standard antenna designs and validated against measurements.
