Integrated Sensing and Communications with Joint Beam Squint and Beam Split for Massive MIMO

Integrated sensing and communications (ISAC) has attracted tremendous attention for the future 6G wireless communication systems. To improve the transmission rates and sensing accuracy, massive multi-input multi-output (MIMO) technique is leveraged with large transmission bandwidth. However, the growing size of transmission bandwidth and antenna array results in the beam squint effect, which hampers the communications. Moreover, the time overhead of the traditional sensing algorithm is prohibitive for practical systems. In this paper, instead of alleviating the wideband beam squint effect, we take advantage of joint beam squint and beam split effect and propose a novel user directions sensing method integrated with massive MIMO orthogonal frequency division multiplexing (OFDM) systems. Specifically, with the beam squint effect, the BS utilizes the true-time-delay (TTD) lines to steer the beams of different OFDM subcarriers towards different directions simultaneously. The users feedback the subcarrier frequency with the maximum array gain to the BS. Then, the BS calculates the direction based on the subcarrier frequency feedback. Futhermore, the beam split effect introduced by enlarging the inter-antenna spacing is exploited to expand the sensing range. The proposed sensing method operates over frequency-domain, and the intended sensing range is covered by all the subcarriers simultaneously, which reduces the time overhead of the conventional sensing significantly. Simulation results have demonstrated the effectiveness as well as the superior performance of the proposed ISAC scheme.

Joint Channel Estimation and Mixed-ADCs Allocation for Massive MIMO via Deep Learning

Millimeter wave (mmWave) multi-user massive multi-input multi-output (MIMO) is a promising technique for the next generation communication systems. However, the hardware cost and power consumption grow significantly as the number of radio frequency (RF) components increases, which hampers the deployment of practical massive MIMO systems. To address this issue and further facilitate the commercialization of massive MIMO, mixed analog-to-digital converters (ADCs) architecture has been considered, where parts of conventionally assumed full-resolution ADCs are replaced by one-bit ADCs. In this paper, we first propose a deep learning-based (DL) joint pilot design and channel estimation method for mixed-ADCs mmWave massive MIMO. Specifically, we devise a pilot design neural network whose weights directly represent the optimized pilots, and develop a Runge-Kutta model-driven densely connected network as the channel estimator. Instead of randomly assigning the mixed-ADCs, we then design a novel antenna selection network for mixed-ADCs allocation to further improve the channel estimation accuracy. Moreover, we adopt an autoencoder-inspired end-to-end architecture to jointly optimize the pilot design, channel estimation and mixed-ADCs allocation networks. Simulation results show that the proposed DL-based methods have advantages over the traditional channel estimators as well as the state-of-the-art networks.

Model Aided Deep Learning Based MIMO OFDM Receiver With Nonlinear Power Amplifiers

Multi-input multi-output orthogonal frequency division multiplexing (MIMO OFDM) is a key technology for mobile communication systems. However, due to the issue of high peak-to-average power ratio (PAPR), the OFDM symbols may suffer from nonlinear distortions of the power amplifier (PA) at the transmitters, which degrades the channel estimation and detection performances of the receivers. To mitigate the clipping distortions at the receivers end, we leverage deep learning (DL) and devise a DL based receiver which is aided by the traditional least square (LS) channel estimation and the zero-forcing (ZF) equalization models. Moreover, a data driven DL based receiver without explicit channel estimation is proposed and combined with the model aided DL based receiver to further improve the performance. Simulation results showcase that the proposed model aided DL based receiver has superior performance of bit error rate and has robustness over different levels of clipping distortions.
